Digital Microscope

Price 2000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Digital Microscope Specification

Focus System
Coaxial coarse and fine focusing mechanism

View Head
30-degree inclined, 360-degree rotatable trinocular head

Spare Parts
Spare bulb, fuse, immersion oil, dust cover, cleaning cloth

Features
Live display, image capture, measurement software, ergonomic design, suitable for laboratory and educational purposes

Theory
Digital imaging utilizing high-resolution CMOS Sensor with real-time image display on external screen.

Drawtube
Trinocular (photo/video port available)

Sensor
CMOS digital sensor

Resolution
5 Megapixel

Interface
USB 2.0 / HDMI

Frame Rate
30 fps (depends on resolution)

Focal Distance
10 mm to infinity (adjustable depending on objectives)

Magnification
40x to 1600x (optical) up to 2000x (digital)

Dimensions
Approx. 370 mm x 250 mm x 370 mm

Focus Range
0 mm 30 mm (coarse and fine adjustments)

Eyepieces
WF10x/18 mm paired (anti-fungus)

Eyepiece Tube
Inclined 30, rotatable 360

Illumination
LED illumination with adjustable brightness, upper and lower light sources

Coarse Adjustment Range
30 mm per rotation

Fine Adjustment Range
0.002 mm per division

Working Stage
Mechanical stage, 125 mm x 115 mm with stage clips and vernier scale

Still Image Capture Resolution
2592 x 1944 pixels (5MP)

Video Capture Resolution
1920 x 1080 pixels (Full HD)

Image Format
JPEG, BMP, AVI (image & video capture capabilities)

Interpupillary Distance
55-75 mm adjustable

Objective Achromatic
4x, 10x, 40x, 100x objectives with color coding

Condenser
NA 1.25 Abbe condenser with iris diaphragm

Light Source
Built-in LED, 3W

Digital Microscope Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Digital Microscope

Digital Microscope

A Robust and stable body.
Objective: All objectives are antifungal coated long barrel at the highest numerical aperture such as(Plan) PL4X NA 0.10, PL 10X NA 0.25, PL40X NA 0.65(S.L.) and PL100X NA 1.25 oil immersion(S.L.) for brilliantlysharp and flatter images.

Eye Pieces: High eye point antifungal and antireglected extra wide field 10x/20mm paired eyepiece.

Trinocular Head : All prism have anti-reflected and antifungal coatings. Having 30 inclination, 360 rotatable.

Nose piece : A reversed type nosepiece running on ball-bearing balls ensures a smooth motion.

Mechanical Stage : Co-axial coarse & fine focusing mechanism based on four steps reduction gears system which runs on ball-bearing guideways, is provided with special tension adjustment rings. Stopper system is provided so that the slides may not get damage.

Condenser : Abbe's condenser NA 1.25, rack & Pinion adjustment.

Light Source : 6V 20W halogen lamp or 3W LED Light with adjustable brightness.

SPECIFICATIONS of Digital Microscopes :

Camera Specifications

Image Sensor: 1/2" 3.0MP CMOS
Valid Pixel: 2048*1536
Pixel Size: 3.18m *3.18m
Digital Output: 24bit (color)
Image Format : Frame Rate-7.5f/s@ 2048*1536:800x600 30f/s
White Balance : Manual/Auto
Output : USB 2.0

System Configuration

LED Size: 10.1" LED Screen with fully touch panel
Processor: Intel Atom 1.66Ghz (Dual Core)
Hard Disk : SATA 32GB
RAM : 2GB DDR2
Operating System : Microsoft Windows 7 and 8
2 USB slots, USB mouse, Wi-Fi, RJ-45 for internet connectivity.
1.3MP front webcam. Easy to use.

Superior Construction and Ergonomics

Crafted with a robust die-cast metal chassis and anti-corrosive finish, this digital microscope promises durability for daily laboratory or classroom use. The ergonomic, 30-degree inclined, 360-degree rotatable trinocular head ensures comfortable prolonged observations, and its mechanical stage allows for highly precise sample navigation using calibrated controls. Maintenance is simplified with included spare parts and an easy-to-clean design.

Versatile Imaging and Measurement Capabilities

Outfitted with a 5MP CMOS digital sensor, this microscope captures vivid still images and full HD videos without lag. The included software supports image measurement, live display, and documentation, all accessible on Windows, MacOS, and Linux. With both optical and digital magnification, complex samples can be studied in exceptional detail for research or classroom demonstration.

Intuitive Operation and Global Compatibility

User-friendly software, available in multiple languages, empowers seamless operation for users worldwide. The universal power supply and long 1.5-meter USB cable facilitate flexible setup. Adjustable LED illumination enables clear viewing across a variety of specimen types, making it ideal for diverse educational and professional applications.

FAQs of Digital Microscope:

Q: How do I connect the digital microscope to my computer or external display?

A: The microscope features USB 2.0 and HDMI interfaces for connectivity. Simply use the provided USB cable or HDMI cable to connect the device to your computer or external monitor. Install the included software (compatible with Windows 7/8/10, MacOS, and Linux) to enable live image display, capture, and measurement functionalities.

Q: What is the process for capturing and saving images or videos with this microscope?

A: Once connected and the software is installed, you can view real-time images. To capture still photos or videos, use the software interface to take snapshots (JPEG, BMP) or record videos (AVI format) at resolutions up to 2592 x 1944 pixels for images and 1920 x 1080 pixels for video.

Q: Where can this digital microscope be effectively used?

A: This microscope is suitable for laboratories, educational institutions, research centers, and industrial quality control settings. Its robust construction and precise optics also make it ideal for exporting, manufacturing, and supply applications.

Q: When should I use the upper versus the lower LED illumination?

A: Use the lower LED light for observing transparent or thin specimens, such as slides of cells or tissue sections. The upper LED is best for examining opaque or thicker samples, including minerals or fabrics, to enhance surface details.

Q: How does the software enhance usability and what languages are supported?

A: The included software offers multilingual support, image measurement, real-time display, and capture features. This facilitates user-friendly operation for global users by enabling them to interact with the software in their preferred language.

Q: What maintenance or spare parts are included with the package?

A: To ensure sustained performance, the package includes a spare bulb, fuse, immersion oil, dust cover, and a cleaning cloth. Regular cleaning and timely replacement of parts, as detailed in the user manual, will keep the microscope in optimal condition.

Q: What are the benefits of the calibrated mechanical stage and fine focusing system?

A: The XY mechanical stage with calibrated vernier allows precise sample positioning, critical for exact measurements and documentation. The coaxial focusing system with both coarse and fine adjustments (0.002 mm per division) ensures sharp, detailed imaging at all magnifications.
