Binocular Pathological Research Microscope

About Binocular Pathological Research Microscope

Binocular Pathological Research Microscope

Phase Contrast and digital PID Bio-Thermal hot plate is one of the best microscope for viewing transparent or translucent specimens without a loss of resolution. This technique has proven to be a valuable tool for medical researchers in the study of living cells, cultures and many applications. The PROPORTIONAL INTEGRAL DERIVATIVE CONTROLLER (PID controller) is a generic control loop feedback mechanism (controller) which is widely used in medical control systems. This device is mainly used in Animal husbandry, various governmental & private Semen banks. This device is used to retain the plate at a proper temperature to check the live semens under the phase contrast light.

SPECIFICATIONS

Optical System
Plan / Achromat optical system.

Magnification
100x-1000x for visual observation.

Eyepiece tubes
Binocular tube, Sidentopf type ( 30, IP distance 55-75mm, 360 rotatable).

Eyepieces
WF 10x (F.O.V. 20mm) & Centering telescopic eye-piece.

Nosepiece
Quadruple nosepiece, reversed type.

Stage
Rectangular142x 120 mm surface stage mounted on the main body cross travel 130x50mm using low-positioned X/Y coaxial control knob.

Objectives
Plan / Achromat10x N.A.0.25, 20x N.A.0.4, 40x N.A.0.65,100x N.A.1.25

Condenser
Phase contrast condenser, Annular diaphragm turn plate.

Illumination
3W LED lighting system with brightness controller.

Filters
Frosted White Filter & Green Filter

Digital PID Bio-Thermal Hot Plate:

Control Action
PID Reverse Action

Input
K type thermocouple

Output
Relay Output

Alarm
1 deviation High alarm (AL1)

Temperature Range
Room Temperature 100 Celsius with auto cut facility.

Advanced Optics and Durability

Engineered with heavy-duty metallic construction and anti-fungal optical coatings, this microscope delivers dependable performance in demanding laboratory environments. The precise mechanical stage and achromatic lenses guarantee high-resolution images for diagnostics and research. Its ergonomic binocular head, adjustable interpupillary distance, and smooth coarse and fine focus contribute to ease of use during extended observation sessions.


Safety and Precision Focus

Featuring a secure head lock mechanism and a safety stop at the upper stage limit, slides are safeguarded from accidental damage. The combination of coarse and fine focus controls allows researchers to achieve minute adjustments, ensuring crisp clarity at all magnification levels.


Versatile Illumination and Convenient Accessories

A powerful, adjustable halogen lamp provides consistent brightfield illumination. The package includes essential spare parts like a dust cover, fuses, and a spare bulb, supporting seamless operation and longevity. Its stage size and mechanical coaxial adjustment make specimen manipulation precise and straightforward.
