Transducer Instrumentation Kit

Price 1000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Transducer Instrumentation Kit Specification

Frequency
50 Hz Hertz (HZ)

Measurement Range
0-100 Units

Feature
Highly Efficient

Power Source
AC Mains (230V)

Model No

Automation Grade
Manual

Voltage
230 V AC Volt (v)

Accuracy
100 % %

Temperature Range
-10 C to 50 C Celsius (oC)

Core Components
Sensors, Signal Conditioning Circuit, Display Unit

Capacity
Varies as per configuration Pcs/hr

Equipment Materials
Aluminum Alloy, ABS Plastic

Type
Transducer Kit

Usage
Laboratory

Display Type
Analog and Digital

Dimension (L*W*H)
320mm x 220mm x 100mm Millimeter (mm)

Weight
Approx 2.5 kg Kilograms (kg)

About Transducer Instrumentation Kit

Transducer Instrumentation Kit For Engineering training lab Equipment

Edutek Instrumentation are the Best Manufacturer and Exporter Company in India.Sensor and Transducer Trainer is a modular training system which

covers the theory, fundamental concepts and applications of sensors

and transducers. The trainer should has many experimental modules

covering a wide range various type of sensors and transducers including

standard signals processing methods, which are required by many

applications.

Specification

used to demonstrate aspects of light intensity control for automatic lighting system

Position and Displacement Measurement Modules

The modules are offered which are commonly used to detect position and displacement of objects. LVDT Transducer Module

which can be use to indicate the linear position of a moving object

Air Flow Sensors Modules

These modules contain a variety of units that are common to the measurement of air flow.

Consist of Differential Pressure Module and Paddle Wheel type Flow meter Module.

Highly Efficient and Accurate Measurement

Designed for laboratory environments, this transducer kit offers rapid response time and exceptional accuracy. Users benefit from pre-calibrated sensors and an integrated signal conditioning circuit, making it reliable for a range of experimental and measurement tasks. The dual display (analog/digital) accommodates varying user preferences.

Robust Construction and User-Friendly Operation

With a shock resistance of up to 50 g, IP20 protection class, and ambient humidity tolerance up to 85% RH, the kit assures dependable performance. The included user manual guides through setup and usage, complemented by connecting wires for quick installation. Its manual operation is intuitive for both students and professionals.

Versatile Laboratory Application

Ideal for research and educational labs, this kit can be used across various applications due to its flexible capacity and measurement range. The standard voltage/current output makes integration seamless with other instruments, expanding its utility.

FAQs of Transducer Instrumentation Kit:

Q: How do I set up the Transducer Instrumentation Kit with Calibration for laboratory use?

A: The kit is designed for easy tabletop mounting. After unpacking, connect the provided wires according to the user manual, ensure the AC mains (230V) power source is available, and follow the calibration steps in the manual to begin measurements.

Q: What are the main benefits of using a factory pre-calibrated transducer kit?

A: Factory pre-calibration ensures high measurement accuracy (100%) right out of the box, saving time on setup and reducing chances of user error during initial calibration processes.

Q: When should I recalibrate the sensors included in the kit?

A: Recalibration is generally unnecessary immediately since the kit arrives pre-calibrated. However, periodic checks as referenced in the user manual are recommended, especially after heavy usage or exposure to environmental extremes.

Q: Where can this kit be effectively utilized?

A: This transducer kit is designed for laboratory settings, making it suitable for educational, research, and industrial labs where precise measurement and quick response are required.

Q: What is the process for taking measurements using the display unit?

A: After setting up the kit and powering it on, select your desired measurement range (0100 units). The display unit will show real-time data in both analog and digital formats, ensuring easy monitoring and data logging.

Q: What are the included accessories, and how do they assist in using the kit?

A: The package contains connecting wires and a detailed user manual. The wires simplify connections with other devices, while the manual provides step-by-step guidance for setup, operation, and troubleshooting.

Q: How does the kit handle shock-prone environments?

A: Thanks to its robust construction and capacity to withstand shocks up to 50 g, the kit maintains reliable functioning, making it suitable for environments where vibrations or accidental impacts might occur.
