Send InquiryStereo Zoom Binocular Microscope
MOQ : 1 Piece
Stereo Zoom Binocular Microscope Specification
- Application
- Research Microscope
- Product Type
- Stereo Zoom Binocular Microscope
- Spare Parts
- Eyepieces, illumination kit, objectives
- Material
- Mild Steel
- Features
- Sharp stereo 3D image, long working distance, widefield view, anti-fungal coated optics
- Focus System
- Coarse focusing knobs, adjustable tension
- Usage
- Laboratory
- Theory
- Stereo Microscope
- Drawtube
- Binocular
- Focal Distance
- 100 mm Millimeter (mm)
- Magnification
- 7x to 45x (with standard objectives and eyepieces)
- Dimensions
- Base approx. 210 x 260 mm Millimeter (mm)
- Focus Range
- 50 mm Millimeter (mm)
- Eyepieces
- Widefield WF10x / 20 mm (pair)
- Eyepiece Tube
- Compensation-free, adjustable 54-76 mm interpupillary distance
- Illumination
- Incident and transmitted LED illumination
- Coarse Adjustment Range
- Available
- Working Stage
- 120 mm diameter frosted glass plate with black & white contrast plate Square Millimeter (mm2)
- View Head
- Binocular, 360 rotatable
- Interpupillary Distance
- 54-76 mm adjustable Millimeter (mm)
- Objective Achromatic
- Zoom objective 0.7x - 4.5x achromatic
- Light Source
- Built-in LED lamps, both incident (top) and transmitted (bottom)
- Weight
- Approx. 5.2 kg
- Color
- White tested finish
- Maximum Height
- Approx. 380 mm
- Voltage
- 100-240V AC, 50/60Hz for illumination
- Objective Type
- Zoom with click stops
- Head Movement
- Vertical and rotational adjustment
- Base Material
- Metal, powder coated
- Stage Clips
- 2 spring-loaded clips
Stereo Zoom Binocular Microscope Trade Information
- Minimum Order Quantity
- 1 Piece
- Payment Terms
- Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)
- Sample Available
- No
- Sample Policy
- Sample costs shipping and taxes has to be paid by the buyer
- Packaging Details
- carton box, export quality also available
- Main Export Market(s)
- Asia, Eastern Europe, Western Europe, Middle East, Africa
- Main Domestic Market
- All India
- Certifications
- ISO 9001, 14001 ,CE
About Stereo Zoom Binocular Microscope
Stereo Zoom Binocular Microscope ETMS-137Stereo Zoom Binocular Microscope is used for viewing flat 3-Dimensional image having parafo called zoom objectives providing continuously variable magnification upto 200X depending upon eyepieces and auxiliary lenses.
Standard Features:-
- Binocular tube with an inclination of 45 for greater ease of observation
- Microscope Zooming ratio 1:5
- Extra wide field eyepieces 10x (Paired)
- Magnification 10x to 50x. (Standard)
- Rack-Pinion focussing stroke 50 mm
- Crisp, erect images with high resolution and excellent stereoscopic effect
- Standard Working distance 80 mm, regardless of magnification
- Interpupillary distance from 54 to 75mm
- Binocular body can be rotated at full 360 and locked in any position desired
- Once brought in focus, image remains clear and sharp throughout the whole zoom range
- Dual Illumination system having incident and transmitted illuminators, for Individual use or both at a time controlled through solid state built-in transformer for 60V-20Whalogen Bulbs
- Packed in plywood Storing cabinet with operation manual, vinyl cover etc
Enhanced Optical Performance
Achieve sharp, detailed 3D images using advanced achromatic zoom objectives and widefield WF10x eyepieces. The 45 inclined binocular view head minimizes user fatigue, while coated optics ensure longevity and precision. Its long 100 mm focal distance offers ample working space for various sample types.
Ergonomic and Versatile Design
The vertical and 360 rotating head, combined with adjustable interpupillary distance, accommodates different users, ensuring sustained comfort. The powder-coated metal base, spring-loaded stage clips, and spacious working area make operations stable and efficient, supporting a wide array of applications.
Reliable Illumination for Any Sample
Featuring built-in LED lamps for both incident (top) and transmitted (bottom) lighting, this microscope allows optimal visualization of opaque and transparent specimens. The variable intensity ensures that samples are clearly illuminated, even in diverse laboratory environments.
FAQs of Stereo Zoom Binocular Microscope:
Q: How do I adjust the magnification on the Stereo Zoom Binocular Microscope?
A: Magnification can be seamlessly changed from 7x to 45x by rotating the zoom control, which is equipped with click stops for precise increment. This flexibility is achieved through the 0.7x to 4.5x achromatic objectives and the WF10x/20 mm widefield eyepieces.Q: What is the process for adjusting interpupillary distance and focus?
A: Interpupillary distance can be set between 5476 mm using the adjustable eyepiece tubes to match your eyes. Focus is achieved through coarse focusing knobs, with adjustable tension to provide smooth and accurate focusing within a 50 mm range.Q: When should I use incident versus transmitted illumination?
A: Use incident (top) LED illumination for opaque samples that do not allow light to pass through, and transmitted (bottom) illumination for transparent specimens. Both light sources can be controlled independently for optimal visualization.Q: Where can I find spare parts for the microscope?
A: Spare parts such as eyepieces, objectives, and illumination kits are provided by the manufacturer, exporter, or supplier in India. Contact your distributor for genuine replacement components to maintain performance.Q: What are the key benefits of the anti-fungal coated optics?
A: The anti-fungal coating helps preserve optical clarity, especially in humid environments, by preventing fungus growth on lenses and prisms, ensuring sharp images and long-term reliability.Q: How do I secure a specimen on the working stage?
A: Place your sample on the 120 mm frosted glass stage plate and fasten it using the two spring-loaded clips. For better contrast, the black & white contrast plate may be used depending on sample characteristics.
