REBORING MACHINE

Get a Price/Quote

REBORING MACHINE Specification

Accuracy
0.01 mm

Power Supply
415V, 50Hz, 3 Phase

Test Range
20 mm to 120 mm (Diameter)

Max Height
1200 mm

Resolution
0.01 mm

Features
Sturdy Construction, Precise Boring, Adjustable Tool Mount, Safety Guard

Interface Type
Manual Interface

Number of Specimens
One at a Time

Operating Voltage
415 V

Mounting Type
Floor Mounted

Humidity
Up to 85% RH (Non-Condensing)

Response Time
Instantaneous (Mechanical Operation)

Specimen Size
Diameter 20-120 mm (Cylinder Bores)

Temperature
0C to 45C

Frequency
50 Hz

Automation Grade
Manual

Application
Automobile Cylinder Block Reboring, Engine Workshops

Measuring Range
20 mm - 120 mm

Equipment Type
Vertical Cylinder Boring/Reboring Machine

Display Type
Analog/Dial Indicator (Standard)

Usage
Reboring Engine Cylinder Blocks

Capacity
Bore Processing Up to 120 mm Dia

Machine Weight
850 Kg

Test Speed
Variable (Depending on Operation)

Test Width
Standard (Customizable with Tooling)

Test Stroke
0 - 250 mm

Control Mode
Manual/Lever Operated

REBORING MACHINE Trade Information

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About REBORING MACHINE

REBORING MACHINE

Cylinder head Reboring machine

Type : Normal
Production Capacity : 15-20 sets/ month
Voltage : 380V/50Hz/3Ph
Power (W) : 3.7KW
Dimension(L*W*H) : 1400x 1400 x 2250mm
Weight : 2000 Kg
Max Boring Depth : 650 mm
Usage : Cylinder head boring
Spindle Speed : 175-600r/mm
Boring Diameter (Standard) : 30-180 mm

Precision Engineering for Cylinder Blocks

This vertical rebore machine offers precise and accurate boring for engine cylinder blocks, with a chuck diameter up to 120 mm and a table travel of 600 mm. Its adjustable tooling and dial indicator display enable repeatable accuracy within 0.01 mm, making it ideal for automotive workshops requiring high-quality performance in cylinder rebore operations.

Engineered for Durability and Safety

Built from cast iron and finished with corrosion-resistant paint, this machine is crafted for long-term durability. Advanced safety features, such as overload protection, emergency stop, and a sturdy safety guard, minimize operational risks. Its industrial-grade design ensures safe operation even in demanding workshop environments.

Customizable Operation and User-Friendly Controls

The rebore machine supports automatic and manual tool feeds, with an easy-to-use manual/lever interface. Operators can adjust stroke, speed, and tool mount settings to suit different bore sizes and tasks. The optional coolant system helps maintain optimal working conditions, while simple controls make operation efficient and accessible for trained technicians.

FAQs of REBORING MACHINE:

Q: How is the REBORING MACHINE typically used in engine workshops?

A: The REBORING MACHINE is primarily employed to rebore engine cylinder blocks, restoring their internal diameter to standard specifications. Technicians mount a cylinder block to the machine, select the appropriate tooling, and use the manual/lever controls to precisely enlarge or refine the bore, achieving high levels of accuracy required for effective engine performance.

Q: What are the key benefits of using this rebore machine for automotive cylinder blocks?

A: Benefits include precise boring accuracy (0.01 mm), sturdy construction for long-term use, overload and safety protection, adaptable settings for various bore sizes (20120 mm), and compatibility with a wide range of cylinder block dimensions. Its corrosion-resistant finish and optional coolant system also contribute to its low maintenance needs and extended lifespan.

Q: Where can this rebore machine be installed and operated effectively?

A: The machine is best suited for automotive workshops, engine reconditioning facilities, and manufacturing plants that handle engine repairs or remanufacturing. Its floor-mounted design and compatibility with standard 415V, 3-phase industrial power supply make it suitable for professional and industrial environments.

Q: What process should be followed for reboring with this machine?

A: Begin by securely mounting the engine cylinder block on the machine table. Select the appropriate tool diameter and adjust the tool mount. Set the desired test stroke and speed, ensuring safety features such as the guard are engaged. Then proceed with either automatic or manual feed, monitoring progress via the analog dial indicator for accuracy. Always use the coolant system if needed to manage heat during operation.

Q: How does the control and interface system enhance machine usage?

A: The manual/lever-operated interface provides precise operator control during the boring process. This hands-on approach allows for meticulous adjustments to depth and feed, facilitating accurate results for varying bore sizes and ensuring users can respond instantly to any operational feedback or requirement changes.

Q: What safety features are included with this reboring machine?

A: The machine incorporates overload protection and an emergency stop button to protect both the operator and equipment in case of malfunctions or unexpected loads. A safety guard is also present to shield the user from moving components and debris during the boring process.
