Send InquiryNOZZLE METER TEST RIG APPARATUS
Price 5000.0 INR/ Piece
MOQ : 1 Piece
NOZZLE METER TEST RIG APPARATUS Specification
- Application
- Fluid Mechanics Lab Equipment
- Usage
- Fluid Mechanics Lab Equipment
- Product Type
- NOZZLE METER TEST RIG APPARATUS
NOZZLE METER TEST RIG APPARATUS Trade Information
- Minimum Order Quantity
- 1 Piece
- Payment Terms
- Cash on Delivery (COD), Cash Advance (CA), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)
- Packaging Details
- Carton Box, Export Quality also Available
- Main Export Market(s)
- Asia, Middle East, Africa
- Main Domestic Market
- All India
- Certifications
- ISO 9001, 14001, CE
About NOZZLE METER TEST RIG APPARATUS
Specification:
NOZZLEMETER TEST RIG APPARATUS
Nozzle meter test rig apparatus
The apparatus consists of a Nozzlemeter. The flow can be regulated by the valve provided at the downstream Presentset-up is self-contained water re-circulating unit, provided with a sump tankand a centrifugal pump.
Flow control valve and by-pass valveare fitted in water line to conduct the experiment on different flow rates.Flow rate of water is measured with the help of measuring tank and stop watchExperiments To measure discharge through Nozzle meter and to calibrate itUtilities Required Electric supply 0.5 kW, 220 V AC, Single Phase Water supplyTap water connection.
Experiment
To determine the co-efficient ofdischarge for nozzle meter at different flow rates.
Requirements
Consisting of Transparent acrylicNozzle meter,
Manometer and Piezometer,
0.5 hp pump,
Sump tank and delivery tank,
Pressure tapping valves andcontrolling valves.
