Compression Testing Machine

Price 1000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Compression Testing Machine Specification

Voltage
220V AC

Power Consumption
1.2 kW

Application
Cement, Concrete Cube or Cylinder Testing

Machine Speed
Adjustable

Accuracy
1% of indicated load

Screw Size
50 mm diameter

Capacity
2000 kN

Power
220V AC, 1-Phase

Operating Temperature
5C to 45C

Power Source
Electric

Frequency
50 Hz

Dimension (L*W*H)
1000 x 600 x 1200 mm

Features
Digital Display, Overload Protection, Auto Cut-Off

Product Type
Compression Testing Machine

Resolution
0.1 kN

Speed Range
0.5 to 5 mm/min (variable)

Color
Blue-Grey

Control System
Microprocessor Based

Load Capacity
2000 kN (200 Ton)

Stroke Length
220 mm (Platen Travel)

Weight
Approx. 600 kg

Phase
Single Phase

Sensor
Load Cell Based

Automatic Grade
Semi-Automatic

Material
Mild Steel Body

Suitable Sample Size
150 mm x 150 mm x 150 mm Cube, Cylinders up to 300 mm Height

Frame Construction
Welded Steel with Powder Coating

Ram Diameter
200 mm

Cooling System
Natural Air Cooling

Safety Features
Emergency Stop Button, Pressure Relief Valve

Display Type
Digital LCD

Data Recording
USB Interface, Print Option

Noise Level
<70 dB(A)

Accessories Included
Standard Spacers, Calibration Certificate

Indicator Type
Digital Load Indicator

Hydraulic Oil Type
Servo grade

Platen Size
220 mm x 220 mm

Compliance Standard
IS: 516, BS: 1881

Compression Testing Machine Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Compression Testing Machine

Compression Testing Machine

Applications:

Compression Testing Machine 2000 KN (200 Tons) Capacity (Two Pillar Model) Electrically Operated fitted with dual display i.e load gauge 0-2000 KN x 10 KN/ Division and Digital Load Indicator 2000 KN x 1 KN/ Division. The micro switch fitted in load gauge and relay contact in digital load indicator to protect the machine from overloading. The machine is suitable for operation on 440V, 3-phase, Ac supply.

Precision and Compliance

Engineered for accuracy, the CTM features a digital load indicator and a load cell-based sensor, delivering measurements within 1% accuracy. It is certified with a calibration certificate and complies with internationally recognized standardsIS: 516 and BS: 1881guaranteeing trustworthy test results suitable for both domestic and export markets.

User-Friendly and Safe Operation

Ease of use is paramount. The machine boasts a digital LCD display, microprocessor-based controls, and an emergency stop button for safety. Overload protection and auto cut-off further ensure secure operation, making it suitable for rigorous laboratory and field environments. All operations are streamlined with USB data logging and print support.

Versatile Sample Handling

The CTM can test concrete cubes of 150 mm and cylinders up to 300 mm in height. Standard spacers and a spacious platen (220 x 220 mm) accommodate varied sample sizes efficiently. Adjustable stroke length and variable speed range support multiple test processes for optimal flexibility and consistent performance.

FAQs of Compression Testing Machine:

Q: How does the digital LCD display enhance the testing process in this compression testing machine?

A: The digital LCD display provides clear, real-time load readings and test status updates, increasing ease of use and minimizing operator errors. It supports detailed data recording and instant result viewing through its user-friendly interface.

Q: What are the safety features integrated into the compression testing machine?

A: Safety is ensured by an emergency stop button, a pressure relief valve, overload protection, and auto cut-off. These features safeguard both users and the machine during operation, minimizing risks and potential damage.

Q: What types and sizes of samples can be tested with this machine?

A: This machine supports compressive strength testing for cement and concrete cubes up to 150 mm x 150 mm x 150 mm and cylinders with heights up to 300 mm, using its spacious platen and adjustable stroke length mechanism.

Q: When and where should the compression testing machine be used?

A: It is ideal for quality assurance laboratories, construction material production sites, and research facilities where routine or batch-wise compressive strength testing is necessary, enabling consistent assessment of building materials.

Q: What process does the machine use for strength testing and how are results recorded?

A: Samples are placed between platens, and a controlled load is applied using a hydraulic system. The microprocessor-based controls ensure accurate loading, while results are logged through USB, displayed digitally, and optionally printed.

Q: What are the key benefits of using this compression testing machine?

A: Key benefits include high accuracy (1%), robust welded steel construction, customizable speed, comprehensive safety features, and compliance with international standards. Data can be electronically recorded, which facilitates efficient reporting and traceability.
