Automatic Compression Testing Machine

Price 10000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Automatic Compression Testing Machine Specification

Capacity
2000 kN (customizable) Kg

Frequency
50 Hz Hertz (HZ)

Power Source
Electric

Feature
Automatic Data Recording, Safety Guards, Overload Protection

Automation Grade
Automatic

Core Components
Load Frame, Digital Controller, Hydraulic Pump, Load Cell

Warranty
1 year

Measurement Range
0 2000 kN

Model No

Voltage
230V AC, Single Phase Volt (v)

Accuracy
1% of indicated value %

Temperature Range
Ambient to 50 C Celsius (oC)

Equipment Materials
Steel Alloy with Powder Coated Finish

Type
Automatic Compression Testing Machine

Usage
Compression Strength Testing of Concrete Cubes/Cylinders

Display Type
Digital / LCD Touchscreen

Dimension (L*W*H)
900 mm x 600 mm x 1250 mm Millimeter (mm)

Weight
Approx. 400 Kg Kilograms (kg)

Pressure Gauge Readout
Provided with Digital Indication

Control System
Microprocessor-Based with USB & Printer Port

Maximum Piston Stroke
60 mm

Test Speed Adjustment
Automatic Rate Control (as per Standards)

Hydraulic System Type
Servo Controlled

Safety Interlock
Integrated Emergency Stop Button

Accessories Included
Calibration Certificate, Platen Spacers, Power Cable

Standards Compliance
IS:516, BS 1881, ASTM C39/C39M

Noise Level
< 70 dB (A) at full load

Platen Size
220 mm diameter (upper), 225 mm diameter (lower)

Operating Mode
Automatic / Manual Selectable

Data Storage
Built-in Memory for Multiple Test Results

Automatic Compression Testing Machine Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Telegraphic Transfer (T/T), Letter of Credit (L/C), Cash Advance (CA), Cash Against Delivery (CAD), Cash on Delivery (COD), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit at Sight (Sight L/C)

Delivery Time
2 Week

Sample Available
Yes

Sample Policy
If order is confirmed we will reimburse the sample cost

Main Export Market(s)
Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Asia, Australia, Africa

Main Domestic Market
All India, North India, South India, Central India, East India

Certifications
AS ISO 9001:2008, ISO 14001:2004 and OHSAS 18001:2007 CO.

About Automatic Compression Testing Machine

Automatic Compression Testing Machine

The Automatic Compression Testing Machine has all features of Micro Controller based Compression Testing Machine.

In addition, it has:

An automatic load release facility
Support for data transmission over distances upto several kilometers. This is useful for testing in the field. (Optional feature)
Measurements of Strain with a resolution of upto 0.001 mm (optional feature)
Measurement of Flexural Strength (optional feature)
Facility to enter the required pace rate, at the beginning of the run

Software: A powerful Analysis and Reporting Software Tools with the following features:

An intuitive and easy to use graphical userinterface
Facility to list all the runs stored in the digital head/box
Facility to download and plot the data for a selected run
Facility to save test-data along with other information about the sample such as age, sample number and batch name
On -line graph of Load Vs Time
Numerical display of the instantaneous value of the load
Automatic display of a breaking load at the end of the test
Log-in controlled multilevel access
A facility for creating users and enabling /disabling their log-in permissions
. A sophisticated reporting tool which can be used to generate-Reports for individual samples with data in graphical of tabular form
Load Vs Time Plot
Stress Vs Time Plot
Calibration report
Batch Summary report
Selective deletion of individual and multiple sample records
Online Help Manual

Advanced Control System for Accurate Testing

It employs a smart microprocessor-based control system that ensures precision and user-friendly operation. With USB and printer port connectivity, data storage for multiple test results, and a digital/LCD touchscreen, it streamlines the testing and reporting process for concrete specimens, making it suitable for modern laboratories.

Servo-Controlled Hydraulic Performance

Equipped with a servo-controlled hydraulic system, this machine delivers smooth and reliable pressure application, maintaining accuracy within 1% of the indicated value. Automatic and manual selectable modes, combined with automatic rate control, enable standardized, repeatable tests that comply with international norms.

Comprehensive Safety and Compliance

Safety is enhanced with an integrated emergency stop button, overload protection, and sturdy construction of steel alloy with a powder-coated finish. The machine adheres to major standards such as IS:516, BS 1881, and ASTM C39/C39M, ensuring credible results and practical use in a range of professional settings.

FAQs of Automatic Compression Testing Machine:

Q: How does the automatic compression testing machine record and store test data?

A: The machine features a built-in memory that automatically records and stores multiple test results. Data can also be exported through the USB or printer port for external documentation and further analysis.

Q: What is the process for adjusting test speeds on this machine?

A: Test speeds are managed automatically by the microprocessor, which controls the rate as per relevant standards. Operators can select or customize test speeds according to the requirements of IS:516, BS 1881, or ASTM C39/C39M guidelines.

Q: When should I use the manual operating mode?

A: Manual mode is recommended for specialized testing conditions or when operators need to initiate, pause, or control specific steps manually. It is useful during calibration, troubleshooting, or non-standard test methods.

Q: Where can this compression testing machine be utilized?

A: This equipment is ideal for use in construction quality control laboratories, research institutions, concrete product manufacturing plants, and on-site testing locations, especially in compliance-focused environments in India and abroad.

Q: What are the safety features included in the automatic compression testing machine?

A: Key safety features include an emergency stop button, overload protection, safety guards, and reliable steel alloy construction. These measures safeguard both the operator and the integrity of the machine during operation.

Q: How does the automatic data recording benefit laboratory workflows?

A: Automatic data recording reduces manual errors, saves time, and enhances traceability. It streamlines reporting, facilitates repeat testing, and ensures test results are securely stored and easily accessible.

Q: What accessories are provided with the machine upon delivery?

A: It is supplied with a calibration certificate, platen spacers, power cable, and necessary documentation, ensuring immediate setup for standard compression strength tests of concrete samples.
