Under Voltage Coil

Price 50.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Under Voltage Coil Specification

Feature
Highly Efficient

Model No
UVC-220

Power Source
Electrical

Temperature Range
-10C to 60C

Automation Grade
Manual

Core Components
Under Voltage Coil

Measurement Range
180V AC to 230V AC

Voltage
220V AC

Accuracy
3%

Frequency
50 Hz / 60 Hz

Equipment Materials
Copper Winding, Insulated Housing

Type
UNDER VOLTAGE COIL

Usage
Industrial

Dimension (L*W*H)
45 mm x 35 mm x 30 mm

Weight
Approx. 120 g

Life Expectancy
>100,000 Operations

Protection Class
IP20

Insulation Resistance
>100 M at 500V DC

Mounting Type
Panel Mounted

Response Time
< 100 ms

Operating Principle
Trips the Circuit When Voltage Falls Below Set Limit

Operating Humidity
Up to 90% RH Non-Condensing

Color
Black and Copper

Contact Rating
5A at 230V AC

Application
Used for Control & Protection Circuits

About Under Voltage Coil

Experience the finest in industrial control and protection with our Best-seller Under Voltage Coil, Model UVC-220. This affordable, highly efficient unit is famed for its rapid <100 ms response, ensuring noteworthy reliability in control and protection circuits. Crafted with copper winding and an insulated black-copper housing, it operates at 220V AC and supports a contact rating of 5A at 230V AC. With a remarkable life expectancy of over 100,000 operations and robust IP20 protection, this top exporter, manufacturer, and supplier from India delivers exceptional performance and safety.

Key Features & Durable Construction

The Under Voltage Coil stands out with its efficient performance and robust material features. Designed for panel mounting, it boasts a protection class of IP20 and an impressive insulation resistance above 100 M at 500V DC. Crafted from premium copper winding and an insulated housing, it ensures stable operation and safety. This coil excels in industrial applications, providing reliable circuit protection with a response time under 100 ms, even in demanding environments, and supports up to 90% operating humidity.

Payment Valuation, Certifications & Export Markets

We offer flexible payment terms ensuring your transactions are smooth and valued. Products come certified for quality and reliability, underlining our commitment as a prominent exporter and supplier of Under Voltage Coils from India. Express shipping options and convenient exchange processes support customer satisfaction. Our acclaimed UVC-220 units are trusted across international markets, including Asia, the Middle East, and Africa, where prompt delivery and compliance with global standards are consistently prioritized.

FAQs of Under Voltage Coil:

Q: How does the Under Voltage Coil enhance safety in control circuits?

A: The Under Voltage Coil instantly trips the circuit if voltage drops below the set limit, ensuring the protected equipment remains safe from under-voltage issues and mitigating risks of malfunction or damage.

Q: What is the process for mounting this Under Voltage Coil?

A: This coil is panel mounted, allowing straightforward and secure installation onto control panels commonly used in industrial setups for efficient integration and operation.

Q: When should I use an Under Voltage Coil in my system?

A: You should use an Under Voltage Coil in control and protection circuits to safeguard sensitive devices whenever your operation is at risk of voltage fluctuations below a specified threshold (180V to 230V AC).

Q: What makes this Under Voltage Coil a best-seller in the market?

A: Its reliable performance, over 100,000 operation life expectancy, rapid response time, and affordable pricing have made it a top choice among global industrial users seeking the finest protection solutions.

Q: Where can this product be used?

A: This Under Voltage Coil is tailored for industrial applications, ideal for environments requiring fast, efficient control and protection of valuable equipment from voltage irregularities.

Q: How efficient is the Under Voltage Coil during continuous use?

A: With high insulation resistance, robust construction, and operation at up to 90% relative humidity, the coil is designed for lasting efficiency, even under challenging industrial conditions.
