Send InquiryTriaxial Shear Apparatus
Price 10000.0 INR/ Unit
MOQ : 1 Unit
Triaxial Shear Apparatus Specification
- Color
- Select (Typically Blue/Grey Steel Frame, Transparent/Metal Cell)
- Temperature Range
- 0-50 C Celsius (oC)
- Frequency
- 50/60 Hz Hertz (HZ)
- Operate Method
- MethodStress Control: The specimen is saturated, consolidated under $\sigma_3$, and then sheared by increasing the axial stress $\Delta\sigma$ at a constant strain rate while monitoring pressures and volume changes
- Classification
- Geotechnical Engineering / Soil Mechanics Testing
- Usage
- Foundation design, slope stability analysis, earth pressure calculations, and settlement prediction for major civil works
- Application
- Civil Engineering Labs, Research Facilities
- Measurement Range
- 0-100 kPa
- Automation Grade
- Manual
- Voltage
- 220 V Volt (v)
- Power Source
- Electric
- Material
- Steel, Acrylic, Precision Valves/Transducers
- Feature
- Rigid frame Easy operation
- Accuracy
- High precision %
- Core Components
- Steel Electronics
- Product Type
- Soil Strength Tester / Stress Path System
- Model No
- Warranty
- 1 Year
- Capacity
- 50 kN Kg
- Equipment Materials
- Stainless Steel
- Type
- Laboratory Testing Equipment
- Display Type
- Dial Gauge
- Dimension (L*W*H)
- 500x300x600 mm Millimeter (mm)
- Weight
- 45 kg Kilograms (kg)
About Triaxial Shear Apparatus
Triaxial Shear Apparatus Motorised Single Speed
For determining the triaxial shear strength of soil specimens of 38mm, 50mm, 75mm and 100mm dia.
Consists of :
One load frame 5000 Kgf motorised , consists one rate of strain type, giving the following rates of strain. 1.25mm/min . Load frame is supplied with a dial gauge bracket. Universal triaxial cell (stationary bushing) 10kg/cm.sq. One lateral pressure assembly 0-10 kg/cm.sq. One lateral pressure assembly 0-10kg/cm.sq. complete with foot pump and rubber hose. One high sensitivity proving ring capacity 1000kg. One strain dial gauge 0.01 x 25mm. Suitable for operation on 230 V A.C.
FAQs of Triaxial Shear Apparatus :
Q: What is the capacity of the Triaxial Shear Apparatus?
A: The capacity of the Triaxial Shear Apparatus is 50 kN.Q: What is the power source for the Triaxial Shear Apparatus?
A: The power source for the Triaxial Shear Apparatus is Electric.Q: What is the temperature range that the Triaxial Shear Apparatus can operate within?
A: The temperature range of the Triaxial Shear Apparatus is 0-50C.Q: What type of display does the Triaxial Shear Apparatus have?
A: The Triaxial Shear Apparatus features a Dial Gauge display.Q: What is the warranty period for the Triaxial Shear Apparatus?
A: The Triaxial Shear Apparatus comes with a warranty of 1 year.
