Sand Equivalent Apparatus

Get a Price/Quote

Sand Equivalent Apparatus Specification

Frequency
50 Hz

Power Source
Manual (Hand Operated)

Core Components
Graduated Cylinders, Siphon Assembly, Rubber Tubing, Plunger, Measuring Can with Graduations

Model No
SE-100

Capacity
1000 ml cylinders (graduated cylinders included)

Automation Grade
Manual

Measurement Range
0-100 Sand Equivalent Value

Temperature Range
Ambient to 50C

Accuracy
100 %

Voltage
N/A - Non-Electric

Feature
Highly Efficient

Equipment Materials
Acrylic/Polycarbonate Cylinders, Metal Base, Brass Valve

Type
Sand Equivalent Test Apparatus

Usage
Laboratory

Display Type
Analog

Dimension (L*W*H)
40 x 15 x 45 cm

Weight
Approx. 6-8 kg (set complete)

About Sand Equivalent Apparatus

Sand Equivalent Apparatus

We are offering Sand Equivalent Apparatus, which are equipped with two separate electronic timers to increase accuracy and ease of operation compared to a spring-type timer. It is recommended for samples in the laboratory. These are available bench mounted and designed to meet the requirements of the European &ASTM test methods.

Sand equivalent Apparatus Consist of Plastic Measuring Cylinder Weighted Foot Assembly Irrigator Tube Rubber Tubing complete with Pinch clipSyphone assembly, with 5 litre bottle Funnel & carrying Case Sand Equivalent Shaker electrically. For use in Laboratories performing a large number of test, this Shaker provides a consistent and repeatable oscillation, minimizing variation in test results.The unit is available bench mounted and designed to meet the requirements of the European & ASTM test methods.

Precise Sand Equivalent Determination

Designed for laboratory professionals, the SE-100 Sand Equivalent Apparatus offers a straightforward, dependable method for detecting detrimental fine dust and clay in aggregate or soil. Its graduated cylinders and precision plunger ensure accurate sand equivalent values, essential for material analysis in construction and civil engineering.

Robust Compliance and Durability

The apparatus adheres strictly to ASTM D2419 and AASHTO T176 standards, guaranteeing industry-approved results. Built from durable materials like acrylic/polycarbonate and metal, the SE-100 withstands rigorous laboratory usage, making it a long-lasting investment for regular material quality assessment.

Efficient Manual Operation

With a manual, hand-operated design, the SE-100 requires no electricity, ensuring hassle-free setup and operation in any laboratory environment. Its analog display and clear markings streamline the testing process, while its portable, lightweight construction allows for easy handling and transport.

FAQs of Sand Equivalent Apparatus:

Q: How is the Sand Equivalent Apparatus SE-100 used in soil and aggregate testing?

A: The SE-100 is utilized by filling its graduated cylinders with soil or aggregate samples and adding solution according to standard methods. The provided plunger agitates the sample, allowing clay-like particles to settle. The sand equivalent value is read from cylinder graduations to determine the proportion of unwanted fine materials.

Q: What standards does the SE-100 Sand Equivalent Apparatus comply with?

A: The apparatus fully complies with internationally recognized ASTM D2419 and AASHTO T176 standards, ensuring consistent, reliable results that meet regulatory requirements for materials testing laboratories.

Q: When should I use a sand equivalent test in construction projects?

A: This test is essential when assessing potential aggregate or soil materials for roadwork, concrete, or asphalt applications. It should be used whenever fine dust or clay-like contaminants may influence material performance and longevity.

Q: Where is the SE-100 apparatus typically employed?

A: The SE-100 is used primarily in laboratory environments across construction, civil engineering, and quality control sectors where accurate analysis of soils and aggregates is required to meet project or regulatory standards.

Q: What benefits does using the SE-100 provide to laboratories and projects?

A: Using the SE-100 enables laboratories to quickly and accurately assess material cleanliness, supporting informed decision-making and quality control. Its high efficiency, standard compliance, and fully manual design improve reliability without energy dependence.

Q: What is the measurement range and capacity of the SE-100 graduated cylinders?

A: Each included cylinder is graduated from 0 to 380 mm and has a 1000 ml capacity, allowing precise measurement of sedimentation and sand equivalent values up to 100.
