TRANSISTOR CHARACTERISTICS (CC PNP)

Name: TRANSISTOR CHARACTERISTICS (CC PNP)
Brand: EDUTEK INSTRUMENTATION
Price: 1400.0 INR
Availability: InStock

Price 1400.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TRANSISTOR CHARACTERISTICS (CC PNP) Specification

Output
Observations of voltage and current on test points or voltmeter/ammeter

Power Supply
230 V AC, 50 Hz (through stepdown transformer for internal circuits)

Usage
ENGINEERING ELECTRONICS INSTRUMENTS

Operating Temperature
0C to 50C

IP Rating
Not rated

Resolution
Typical meter resolution: 0.01V/0.1mA

Display Type
Analog/digital panel meters (as applicable)

Components
Mounted PNP transistor, meters, switches, binding posts, internal power supply

Power Source
Main powered (AC supply)

Features
Rugged ABS panel, clear circuit diagram, inbuilt regulated power supply, safe design, educational use

Interface
Test jacks & terminals for connection

Input
Variable DC for biasing

Response Time
Instantaneous (manual readings)

Product Type
TRANSISTOR CHARACTERISTICS (CC PNP)

Application
ENGINEERING ELECTRONICS INSTRUMENTS

Rated Voltage
230 V AC, 50 Hz

Supply Voltage
Dual DC power supply, typically +/-12V via internal regulators

Size
Standard desktop module, approx. 35cm x 25cm

Dimension (L*W*H)
Approx. 350mm x 250mm x 90mm

Function
To study the input and output characteristics of a PNP transistor in Common Collector (CC) configuration.

Color
As shown (Multi-color/Educational panel design)

Weight
Approx. 1.5 kg

Current Rating
Up to 1A (for meters, actual range lower for transistor test)

Thickness
Panel thickness typically 3-4 mm

Capacity
Single experiment panel

Frequency
50 Hz (input power supply)

Connection Type
4mm safety sockets

Meter Range
0-1V (voltage), 0-10mA (current)

Fuse Protection
Yes, internal fuse for safety

Configuration
Common Collector (CC)

Mounting
Desktop/benchtop use

Power Cable Length
Approx. 1.5 meters

Educational Level
Suitable for university/technical institute use

Test Points
Multiple clearly labeled test points

Included Accessories
AC mains cord, instruction manual

Transistor Type
PNP Germanium/Silicon as per kit design

Accessory
Comes with experiment manual

Safety Standards
Complies with standard educational apparatus safety guidelines

External Connections
Facility for connecting external voltmeter/ammeter

Panel Material
High grade ABS/Plastic

TRANSISTOR CHARACTERISTICS (CC PNP) Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash on Delivery (COD), Cash Advance (CA), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Packaging Details
Carton Box, Export Quality also Available

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001, CE

About TRANSISTOR CHARACTERISTICS (CC PNP)

The TRANSISTOR CHARACTERISTICS (CC PNP) kit offers world-class value and first-class reliability for academic and technical training. This popular educational apparatus is designed for superior usability featuring a desktop module with a noble multi-color panel design. Study PNP Germanium/Silicon transistors in a Common Collector (CC) configuration using multiple clearly labeled test points. Enjoy discount pricing for bulk orders. The experiment panel includes a stepdown-powered dual DC supply, high-grade ABS construction, fuse protection, and variable input bias. Accessories include an AC mains cord, detailed instruction manual, and user-friendly safety sockets. Ideal for university and technical institute labs in India.

Innovative Learning for Engineering Electronics

TRANSISTOR CHARACTERISTICS (CC PNP) equips students to analyze both input and output behaviors of PNP transistors in Common Collector configuration. Designed specifically for engineering electronics courses, it features rugged ABS construction, multiple labeled test points, and precise analog/digital panel meters. The apparatus enhances practical skill development in advanced labs, making it optimal for academic use in technical institutes and universities where practical understanding is crucial for modern electronics education.

Sample Orders, Certifications, and Shipment

Sample units of the TRANSISTOR CHARACTERISTICS (CC PNP) are readily available for testing and evaluation. Shipped goods are securely packed and typically handed over to logistics partners following formal purchase order confirmation. The main domestic market is India, with compliance to standard educational apparatus safety certifications. Each unit supplied guarantees adherence to quality benchmarks, and upon receipt of the purchase order, tracking information and user documentation are provided for institutional buyers.

FAQ's of TRANSISTOR CHARACTERISTICS (CC PNP):

Q: How can the TRANSISTOR CHARACTERISTICS (CC PNP) kit benefit engineering students?

A: This kit provides practical exposure to the functionality of PNP transistors in Common Collector configuration, enabling hands-on learning through clearly labeled test points and interactive experiments. It fosters a deeper understanding of transistor behavior in real-world circuits.

Q: What accessories are included with the experiment panel?

A: The kit comes complete with an AC mains cord, a comprehensive experiment manual, and necessary connection accessories, ensuring users have everything required to begin experiments immediately.

Q: Where can this apparatus be ideally used?

A: This product is suitable for laboratory use in universities, technical institutes, and engineering colleges engaged in electronics education and experimentation.

Q: What safety measures does the device incorporate?

A: The kit incorporates an internal fuse for electrical protection, features rugged ABS panel construction, complies with standard educational safety guidelines, and offers safety sockets for secure connections.

Q: What is the process for ordering and receiving the kit?

A: Place a purchase order with the supplier; samples are available upon request. After order confirmation, the goods are promptly shipped and handed over to the appointed logistics service, with tracking and manuals provided.

Q: Does the product support external measurement devices?

A: Yes, the apparatus includes facilities for connecting external voltmeters and ammeters, giving users flexibility for advanced observation and analysis.
