THREE PHASE, FOUR WIRE DYNAMOMETER TYPE PORTABLE POWER FACTOR METER

Send Inquiry

Request To Call Back

THREE PHASE, FOUR WIRE DYNAMOMETER TYPE PORTABLE POWER FACTOR METER

Get a Price/Quote

MOQ : 1 Piece

THREE PHASE, FOUR WIRE DYNAMOMETER TYPE PORTABLE POWER FACTOR METER Specification

Resolution
Power factor scale subdivided 01.0

Features
Portable, robust, analog indication, high accuracy

Operating Temperature
0C to 55C

Sensors Specification
Electromechanical dynamometer

Power Source
External AC power

Display Type
Analog

Input
Three phase, four wire electrical supply

Components
Moving coil dynamometer mechanism, pointer, scale, terminals

Interface
Terminal connections

Output
Analog meter indication of power factor

Usage
ENGINEERING ELECTRONICS INSTRUMENTS

IP Rating
IP20

Response Time
Instantaneous analog display

Power Supply
Alternating Current

Product Type
THREE PHASE, FOUR WIRE DYNAMOMETER TYPE PORTABLE POWER FACTOR METER

Application
ENGINEERING ELECTRONICS INSTRUMENTS

Rated Voltage
110/230V AC

Supply Voltage
110/230V AC

Size
Portable

Dimension (L*W*H)
280 mm 200 mm 120 mm

Function
Measures power factor in three-phase, four-wire electrical systems

Color
Grey

Weight
Approx. 2.5 kg

Thickness
Enclosure thickness approx. 2 mm

Current Rating
Up to 10A

Capacity
Suitable for loads up to 10A

Frequency
50 Hz

Humidity Range
Up to 90% RH non-condensing

Calibration
Factory calibrated

Connection Type
Screw terminals

Accuracy
Class 1.5

Mounting
Portable, desktop

Body Material
Powder-coated steel

Dielectric Strength
2 kV for 1 minute

Scale Range
0 to 1.0 (power factor)

Safety Standard
IS 1248

THREE PHASE, FOUR WIRE DYNAMOMETER TYPE PORTABLE POWER FACTOR METER Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash on Delivery (COD), Cash Advance (CA), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Packaging Details
Carton Box, Export Quality also Available

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001, CE

About THREE PHASE, FOUR WIRE DYNAMOMETER TYPE PORTABLE POWER FACTOR METER

Experience triumphant accuracy at the best price with our Three Phase, Four Wire Dynamometer Type Portable Power Factor Meter. Crafted with a powder-coated steel body, this noble instrument ensures reliable analog readings with perfect precisionmeeting Class 1.5 standards. Designed for both desktop and portable use, it features a scale range of 0 to 1.0, robust screw terminals, and instant response dynamics. Last chance savings await with this expertly calibrated, factory-tested meter supporting up to 10A load. Secure this high-performance, IS 1248-certified solution for your engineering needs today!

Wide Application and Trusted Commercial Uses

The Three Phase, Four Wire Dynamometer Type Portable Power Factor Meter finds perfect utility in engineering electronics instruments, research labs, electrical maintenance, and industrial settings. Commercial users, including exporters, manufacturers, and suppliers across India, rely on its robust, accurate measurements. This meter is widely used by engineers, technicians, and educators for monitoring and optimizing power factor in complex three-phase, four-wire electrical systems, ensuring optimal performance and significant energy savings for commercial enterprises.

Reliable Supply, Packaging, and Export Logistics

We boast exceptional supply ability with streamlined logistics, ensuring timely delivery both in the domestic mar and for international clients. Each meter is meticulously packaged for transportation safety, maintaining product integrity throughout the journey. Our principal export markets encompass India and neighboring regions, with a special focus on exporter, manufacturer, and supplier requirements. Efficient shipping and careful handling guarantee that your portable power factor meter arrives ready for immediate use, every time.

FAQs of THREE PHASE, FOUR WIRE DYNAMOMETER TYPE PORTABLE POWER FACTOR METER:

Q: How does the Three Phase, Four Wire Dynamometer Type Power Factor Meter operate?

A: This meter uses an electromechanical dynamometer mechanism to provide instantaneous analog readings of power factor across three-phase, four-wire electrical systems with high accuracy.

Q: What are the main benefits of using this power factor meter?

A: The main benefits include accurate monitoring of power factor, portable convenience, robust construction, wide measurement range, fast response time, and cost savings through optimized electricity usage.

Q: Where should this meter be installed for optimal use?

A: It is designed for portable and desktop use in engineering labs, electrical workshops, and industrial testing environments. Its screw terminal connections offer secure, reliable installation at any site.

Q: When should I calibrate the power factor meter?

A: Each unit arrives factory-calibrated for immediate deployment; however, recalibration is recommended annually or in accordance with your facilitys maintenance protocol.

Q: What is the process for connecting this meter to an electrical supply?

A: Simply connect the terminal screws to the three-phase, four-wire system supply. Ensure the device matches the rated voltage (110/230V AC) and secure appropriate current (up to 10A) before use.

Q: Who typically uses this device and for what applications?

A: Engineers, technicians, and instructors employ this meter predominantly in educational, research, industrial, and quality assurance settings to assess and optimize power factor in electrical systems.
