ACTIVER FILTERS (LOW PASS AND HIGH PASS)

Name: ACTIVER FILTERS (LOW PASS AND HIGH PASS)
Brand: EDUTEK INSTRUMENTATION
Price: 1200.0 INR
Availability: InStock

Price 1200.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

ACTIVER FILTERS (LOW PASS AND HIGH PASS) Specification

IP Rating
IP20

Operating Temperature
0 to 50C

Input
Analog electrical signal

Interface
Terminal block

Usage
ENGINEERING ELECTRONICS INSTRUMENTS

Thermal Conductivity
Standard PCB thermal specification

Power Source
AC mains

Output
Filtered analog signal

Response Time
<1 ms

Components
Op-amps, resistors, capacitors, PCB, connectors, terminals

Power Supply
AC

Features
Pre-built, durable PCB, easy to use, accurate filtering, educational

Product Type
ACTIVER FILTERS (LOW PASS AND HIGH PASS)

Application
ENGINEERING ELECTRONICS INSTRUMENTS

Rated Voltage
230 V AC

Supply Voltage
230 V AC

Size
115x90 mm

Dimension (L*W*H)
115 mm x 90 mm x 40 mm

Function
Filters specific frequency ranges; Low Pass filters pass frequencies below cutoff, High Pass filters pass frequencies above cutoff

Color
Green

Weight
260 gm

Thickness
Standard PCB thickness

Capacity
Standard load handling for educational and light industrial use

Current Rating
0.2A

Frequency
Cutoff frequency configurable 1 Hz to 10 kHz

Cutoff Adjustability
Fixed and variable options available

Filter Type
Active, available as low pass and high pass modules

Connector Type
Screw terminals

Mounting Type
Panel and screw mountable

Build Material
FR4 epoxy PCB with high-grade electronic components

Technology
Based on operational amplifier (Op-Amp) architecture

Safety Standards
Compliance with standard laboratory safety protocols

ACTIVER FILTERS (LOW PASS AND HIGH PASS) Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash on Delivery (COD), Cash Advance (CA), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Packaging Details
Carton Box, Export Quality also Available

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001, CE

About ACTIVER FILTERS (LOW PASS AND HIGH PASS)

Specification:

ACTIVER FILTERS (LOW PASS AND HIGH PASS)

Built in regulated power supply: +15V,-15V/300 mA.

Instruction Manual: Step-By-Step detailed instruction manual.

Dimension: 27cmX 17cm X 10cm

Input Supply: 230V AC/50 Hz mains operated

Reliable Active Filtering for Precise Applications

Our active filters are engineered to accurately filter analog signals by allowing only desired frequency ranges to pass. Low pass modules transmit frequencies below a set cutoff, while high pass modules allow those above it, making them essential for electronic experiments and signal processing in labs and classrooms. Each module ensures robust performance with fast response time and reliable operation, built on an FR4 epoxy PCB for reliable and safe usage.

Versatile Installation and Easy Connectivity

These modules are designed for effortless installation with their panel and screw mounting options, making them suitable for most laboratory and educational setups. The screw terminal connectors ensure secure, tool-free wiring for fast, repeatable integration into your existing systems. Dimensions of 115x90x40 mm offer compatibility with standard instrument panels.

Accurate Cutoff Control: Fixed and Variable Options

Meet varying experimental needs with modules featuring both fixed and variable cutoff frequencies, adjustable from 1 Hz to 10 kHz. This allows educators and technicians to tailor filtering precisely to their application's frequency range, whether for routine lab exercises or more advanced demonstrations.

FAQ's of ACTIVER FILTERS (LOW PASS AND HIGH PASS):

Q: How do I mount these active filters in my engineering lab setup?

A: The modules are designed for easy installation using either panel or screw mounting. Simply fix the unit to your instrument panel or designated enclosure using standard screws, ensuring a secure and stable attachment for reliable operation.

Q: What is the process to adjust the cutoff frequency?

A: For modules with variable cutoff, you can adjust the cutoff frequency within the range of 1 Hz to 10 kHz using the provided controls on the PCB. For fixed cutoff modules, the frequency is preset during manufacturing based on your selection. Please refer to the module's labeling and manual for adjustment instructions.

Q: Where can these filters be used effectively?

A: These active filters are primarily used in engineering electronics instruments for educational, laboratory, and light industrial experiments where precise frequency selection or noise reduction is required.

Q: What benefits do these active filters provide over passive filters?

A: Active filters based on operational amplifiers offer greater accuracy, enhanced filtering sharpness, no signal loss, configurable cutoff settings, and amplification of weak signals, making them ideal for sensitive experiments and demonstrations.

Q: How do the screw terminal connectors enhance usability?

A: Screw terminal connectors allow for quick, tool-free wiring of analog input and output signals, simplifying installation and making the filters reusable across various setups without soldering.

Q: What safety standards are followed and what is the recommended operating environment?

A: The modules comply with standard laboratory safety protocols and feature an IP20 rating. They should be operated in environments within the 0 to 50C temperature range, away from excessive moisture or conductive dust, and powered by 230V AC mains supply.
