Study Of Microwave Component

Price 100.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Study Of Microwave Component Specification

Display Type
Analog or digital power meter (if included).

Operating Temperature
0C to +50C.

Thermal Conductivity
Standard for metallic waveguide (Aluminum/Copper).

Input
RF/Microwave signal input (variable frequency).

Response Time
Instantaneous (depends on test instrument used).

Usage
Educational laboratory experiments.

Output
RF/Microwave signal output (measurable characteristics).

Processor Speed
N/A (not microprocessor based).

Charging Voltage
N/A (not battery powered).

Resolution
Depends on measurable output, typical power meter resolution mW range.

Interface
BNC/SMA connectors or waveguide flanges.

Power Source
Mains supply.

Features
Interchangeable components, precise measurement, modular design, experiment manual included.

IP Rating
Not applicable (laboratory equipment).

Sensors Specification
Power detector, frequency meter (optional).

Components
Waveguide, Klystron/ Gunn diode source, attenuator, directional coupler, circulator, slotted section, detectors, matched termination.

Power Supply
230V 10% AC, 50 Hz.

Product Type
Microwave Component Study Kit.

Application
Microwave engineering, electronics, laboratory experiments.

Rated Voltage
220V AC (for associated equipment).

Supply Voltage
230V AC.

Size
Standard bench-top; varies per kit, typically 480 x 350 x 170 mm.

Dimension (L*W*H)
Approx. 480 x 350 x 170 mm.

Function
To study the characteristics and functioning of microwave components such as attenuators, circulators, directional couplers, and termination.

Color
Depends on component, typically metallic or black.

Weight
Approx. 5-12 kg (depending on configuration).

Capacity
Supports multiple experiments/components.

Thickness
Component thickness varies; typical waveguide thickness 3-10 mm.

Current Rating
< 1A for instrument power.

Frequency
Typically X-band, 8-12 GHz (depends on kit specification).

Material
High-grade Aluminum or Copper waveguide components.

Supported Experiments
Attenuator characteristics, directional coupler performance, circulator properties, power measurement, impedance matching.

Waveguide Type
Standard rectangular, typically WR-90 for X-band.

Connector Type
Waveguide, SMA/BNC as required.

Calibration
Calibrated with traceable standards (on request).

Mounting
Rubber feet, stable bench-top setup.

Packaging
Supplied in foam-padded rigid box.

Compliance
Meets laboratory safety and EMC requirements.

Safety
Fuse protection and insulated mains connectors.

Included Accessories
User manual, set of cables, calibration certificate (if specified).

Study Of Microwave Component Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash Advance (CA), Telegraphic Transfer (T/T), Letter of Credit (L/C), Cash in Advance (CID), Cheque

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Middle East, Western Europe, Asia, Eastern Europe, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Study Of Microwave Component

Study Of Microwave Component

Experiments:

To study Magic Tee, Directional Coupler, Isolators & Circulators.
To measure characteristics of detector diode.
To study attenuation measurements.
To study the return loss measurements.

Component Name                                     Qty.

Klystron power supply                                  1

Klystron Tube                                                1

Frequency Meter                                           1

Fixed Attenuator 3,6,10db                            3

Detector Mount                                             1

Slotted Section                                              1

VSWR Meter Solid State                              1

S S Tunner                                                       1

Cooling Fan                                                    1

MHD Coupler 3,10,20db                              3

E-Plane Tee                                                    1

Klystron Mount                                             1

Isolator                                                           1

Variable Attenuator                                       1

Magic Tee                                                      1

Movable Short                                               1

Tunable Probe                                                1

Stands                                                             4

BNC Cable                                                     1

Matched termination                                     1

Cirulator                                                         1

H-Plane Tee                                                   1

Comprehensive Microwave Experimentation

The kit delivers a thorough platform for studying critical microwave components such as attenuators, circulators, directional couplers, and matched terminations. Its modular system allows easy configuration, making it ideal for educational labs and practical electronics courses.

Precision Calibrated Performance

Each waveguide and accessory is manufactured from high-grade aluminum or copper and can be calibrated against traceable standards upon request. This ensures accuracy in measurements and repeatability in learning outcomes, supporting demanding laboratory work.

Safe and Durable Laboratory Equipment

Safety features, including fuse protection and insulated mains, offer peace of mind during experiments. Sturdy construction, rubber feet, and foam-padded packaging protect components and make it convenient for bench-top use and setup.

FAQs of Study Of Microwave Component:

Q: How do I perform attenuation and power measurement experiments with this microwave kit?

A: Begin by connecting the attenuator between the RF source and the power meter using the supplied waveguide and cables. Adjust the attenuator to measure power changes and refer to the user manual for stepwise instructions.

Q: What types of waveguide and connectors are supplied with the kit?

A: The kit includes standard WR-90 rectangular waveguides suitable for X-band frequencies. Interfaces are provided via waveguide flanges, BNC, or SMA connectors, depending on the component and experiment requirements.

Q: When is calibration required and how is it provided?

A: Calibration ensures measurement accuracy, particularly for assessment or research purposes. A calibration certificate with traceable standards is available upon request during ordering, making it suitable for certified lab use.

Q: Where can this microwave study kit be utilized?

A: It is designed for educational laboratories, particularly in fields of electronics and microwave engineering, and is suitable for university courses, research labs, or technical training centers.

Q: What safety measures are included in the equipment?

A: The kit has built-in fuse protection, insulated mains connectors, and stable rubber feet for bench-top mounting, ensuring safe operation during experiments.

Q: How does the kit benefit practical learning in microwave engineering?

A: It provides hands-on experience with key microwave components, enabling students to study and verify theoretical principles such as impedance matching and power coupling. Modular design encourages interactive experimentation and deeper understanding.
