Send InquirySteam Distillation Setup
MOQ : 1 Unit
Steam Distillation Setup Specification
- Capacity
- 500 ml to 5 Liters (customizable as per requirement)
- Accuracy
- 2C
- Model No
- LAB-STD-500/1000/5000
- Automation Grade
- Manual
- Temperature Range
- Ambient to 300C
- Core Components
- Heating mantle, distillation flask, condensers, receiver, steam generator, support stand, clamps
- Voltage
- 220V-240V AC
- Measurement Range
- 5 ml to full flask capacity (depending on model)
- Feature
- Easy to assemble/disassemble, high chemical resistance, uniform heating, safety features included
- Power Source
- Electric
- Frequency
- 50-60 Hz
- Equipment Materials
- Borosilicate glass, Stainless steel, Teflon fittings
- Type
- Laboratory Steam Distillation Setup
- Usage
- Oil extraction, phytochemical analysis, education & research
- Display Type
- Analog and digital options available
- Dimension (L*W*H)
- 450 x 250 x 650 mm (approx., standard setup)
- Weight
- 10-18 kg (depends on capacity)
- Safety
- Overheating protection and grounded power supply
- Condensation Unit
- High-efficiency Liebig or Allihn condenser
- Color
- Transparent (glassware), Silver (metal parts)
- Controller Type
- Digital/Analog temperature controller
- Glassware Joint Size
- Standard 24/29 or 29/32 joints
- Heating System
- Energy efficient heating mantle with adjustable temperature control
- Packaging
- Foam cushioned, export grade wooden/crate packing
- Installation
- Table-top, ready to use upon unpacking
- Distillation Rate
- 30-50 ml/min depending on batch and heating rate
Steam Distillation Setup Trade Information
- Minimum Order Quantity
- 1 Unit
- Payment Terms
- Cash on Delivery (COD), Days after Acceptance (DA), Delivery Point (DP), Letter of Credit (L/C), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Cash Against Delivery (CAD), Cash in Advance (CID), Cheque, Cash Advance (CA)
- Delivery Time
- 2 Week
- Sample Available
- Yes
- Sample Policy
- If order is confirmed we will reimburse the sample cost
- Main Export Market(s)
- Middle East, Western Europe, Africa, Central America, Eastern Europe, Australia, South America, Asia, North America
- Main Domestic Market
- South India, North India, East India, Central India, All India
- Certifications
- AS ISO 9001:2008, ISO 14001:2004 and OHSAS 18001:2007 CO.
About Steam Distillation Setup
Steam Distillation SetupThe equipment consists of jacketed pressure vessel for distillation. Steam from a steam generator can either be allowed to enter in the outer jacket or in the vessel. The vapours form the top of the vessel are condensed in the shell and tube type condenser by circulating cooling water, supplied by laboratory overhead tank. The condensate is collected in a separating chamber. The set-up is fitted with steam trap, control valves, pressure gauge, temperature sensors and other instrumentations required. Steam distillation is used industrially to purify liquids, which are immiscible with water, and to remove bad odors from oils. When water is added to a high boiling liquid immiscible with it, the total pressure exerted by the mixture above the liquid surface will be the sum of the vapor pressures of the pure components and therefore the boiling point of the mixture will be less than that of water at the given temperature. Because of this, even high boiling liquids are made to boil at low temperature and their decomposition is avoided. The steam consumption for steam distillation process is normally high.
Experimentation :
- To study the characteristics of Steam Distillation.
- Efficiency of simple steam distillation set-up.
Energy-Efficient Heating and Accurate Temperature Control
Equipped with a heating mantle offering uniform, energy-efficient heating and adjustable temperature control, this setup achieves precise regulation up to 300C. Overheating protection and grounded power supply enhance laboratory safety, making the system reliably stable for extended operations.
Versatile Condensation for Pure Output
The condensation unit provides a choice of high-efficiency Liebig or Allihn condensers, ensuring effective vapor condensing and high distillation rates. The transparent borosilicate glass offers visual clarity during operation, supporting both research and educational demonstrations.
FAQs of Steam Distillation Setup:
Q: How is the steam distillation setup installed and made ready for use?
A: The setup arrives in export-grade wooden or crate packaging with cushioning. Installation is table-top and straightforward, as components are ready to use upon unpacking, requiring only minor assembly such as attaching glass joints and support clamps.Q: What processes can the steam distillation setup be utilized for?
A: This laboratory apparatus is ideal for essential oil extraction, phytochemical analysis, education and research-based distillation processes, thanks to its customizable capacity and high distillation rates.Q: When should I consider using the digital or analog temperature controller?
A: Digital controllers are best for precise temperature regulation and display, especially in research and analytical applications; analog controllers are suitable for routine operations or educational use where visual feedback is adequate.Q: Where is this steam distillation equipment typically used?
A: It finds applications in laboratories, research centers, educational institutions, and industrial R&D facilities, serving researchers, students, and quality control professionals.Q: What are the benefits of using borosilicate glass and stainless steel in the setup?
A: Borosilicate glass provides excellent chemical resistance and transparency, allowing visual process monitoring. Stainless steel offers durability and robust support for thermal stability and extended laboratory use.Q: How does the overheating protection feature enhance safety during distillation?
A: Overheating protection prevents thermal runaway by automatically cutting off power in case of excessive temperature, safeguarding users and preserving both the setup and distilled samples from damage.
