Natural Draft Tray Dryer

Get a Price/Quote

MOQ : 1 Unit

Natural Draft Tray Dryer Specification

Accuracy
3 C C

Capacity
12 trays (other capacities available) Kg

Measurement Range
Depends on product loading

Temperature Range
Ambient to 100 C Celsius (oC)

Core Components
Trays, Outer Chamber, Insulation, Door

Automation Grade
Manual

Power Source
Electric

Voltage
220-240V AC Volt (v)

Frequency
50 Hz Hertz (HZ)

Feature
Uniform drying, Easy to operate, Sturdy construction

Equipment Materials
Mild Steel, Stainless Steel (contact parts)

Type
Natural Draft Tray Dryer

Usage
Pharmaceutical, Food, Chemical drying

Display Type
Analog

Dimension (L*W*H)
1150 x 600 x 900 mm (approx.) Millimeter (mm)

Weight
Approx. 150 kg Kilograms (kg)

Operating Environment
Laboratory, Pilot plant or Small scale industries

Temperature Uniformity
5C across trays

Insulation Material
Glass wool

Number of Shelves
3 (fits 12 trays)

Chamber Volume
Approx. 0.6 m3

Door Type
Double wall, front loading

Air Circulation
Natural convection

Tray Type
Removable, perforated trays

Finish Type
Powder coated (exterior)

Control
Thermostat controlled heating element

Natural Draft Tray Dryer Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Delivery Point (DP), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Letter of Credit (L/C), Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA)

Delivery Time
2 Week

Sample Available
No

Sample Policy
If order is confirmed we will reimburse the sample cost

Main Export Market(s)
Asia, Australia, Middle East, Central America, North America, South America, Eastern Europe, Western Europe, Africa

Main Domestic Market
All India, South India, Central India, North India, East India

Certifications
AS ISO 9001:2008, ISO 14001:2004 and OHSAS 18001:2007 CO.

About Natural Draft Tray Dryer

Natural Draft Tray Dryer:

Owing to the vast experience and knowledge of this field, we have been able to offer premium quality Natural Draft Tray Dryer to prestigious customers. These dryers are commonly used for analyzing the moisture elimination by various condition of high temperature under natural draft action. This draft action is generated by the hot stream of air.

Specifications:

Electric supply Provide: 230 +/- 10 VAC, 50 Hz, single phase electric supply with proper earthing. 5A, three pin socket with switch for weighing scale, 15A, three pin socket with switch for heater
Material Saw dust @ 1Kg.
Support table Size: 500 W x 500 D x 750 H in mm.

Uniform Drying Performance

This tray dryer uses natural convection for air circulation, ensuring gentle, even drying across all 12 trays with a temperature uniformity of 5C. The glass wool insulation and thermostat control maintain stable conditions, reducing energy loss and delivering consistent results for each batch.

User-Friendly and Durable Design

Constructed with a powder-coated exterior for long-lasting durability, this front-loading chamber features removable, perforated trays for flexible operation and easy cleaning. Stainless steel contact parts provide corrosion resistance, supporting applications in pharmaceutical, food, and chemical drying.

Versatile Applications and Easy Operation

With its analog controls and manual operation, the Natural Draft Tray Dryer is simple to use in laboratory, pilot plant, or small-scale industrial settings. It fits a range of products and quantities, supporting various batch sizes for customized drying processes.

FAQs of Natural Draft Tray Dryer:

Q: How does the natural draft tray dryer achieve uniform drying across all trays?

A: The tray dryer employs a natural convection system, combined with precise thermostat-controlled heating and glass wool insulation. This configuration maintains consistent temperature distribution, ensuring uniform drying with a temperature variation of only 5C across all 12 trays.

Q: What types of materials can be processed using this tray dryer?

A: The dryer is suitable for drying various products including pharmaceuticals, chemicals, and food items. Stainless steel contact parts ensure product safety and compatibility with a wide range of materials.

Q: When is it recommended to use a tray dryer with natural draft convection?

A: Tray dryers with natural convection are ideal for gentle drying requirements, especially in laboratories, pilot plants, or small-scale industries where precise temperature control and uniform heat distribution are important. They work best with heat-sensitive products or when forced air circulation is not necessary.

Q: Where can this dryer be installed and operated?

A: The compact dimensions (1150 x 600 x 900 mm) allow for installation in standard laboratory spaces, pilot scale facilities, or small industrial areas. All you need is access to a standard 220-240V AC power supply.

Q: What is the process for loading and unloading trays in the dryer?

A: The double-wall, front-loading door provides easy access. Trays are fully removable, allowing for straightforward placement and retrieval of product. The perforated design promotes efficient airflow around the material being dried.

Q: How does the insulation material benefit the drying process?

A: Glass wool insulation minimizes heat loss, thereby supporting stable internal temperatures and energy efficiency. This leads to consistent drying results and lower operating costs.

Q: What are the main benefits of using this model for drying applications?

A: This tray dryer offers uniform drying, simple manual controls, robust build quality, and flexible capacity. Its ergonomic, easy-to-clean design and compatibility with a broad range of products make it a valuable asset for quality-focused drying operations.
