MICROPROCESSOR UV SPECTRO PHOTOMETER

Price 100.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

MICROPROCESSOR UV SPECTRO PHOTOMETER Specification

Color
White and Blue

Classification
Laboratory Instrument

Material
High-grade plastic and metal

Voltage
220 V AC 10% 50 Hz

Dimension (L*W*H)
470 mm x 380 mm x 200 mm

Usage
Quantitative and qualitative analysis of compounds

Application
Pharmaceutical, Chemical, Environmental Testing, Research

Weight
13 kg

Product Type
Microprocessor UV Spectrophotometer

Capacity
Single sample cuvette holder

Operate Method
Microprocessor controlled with digital interface

Power
80 W

Environment Conditions
Humidity <80%, Temperature 5°C to 40°C

Storage Memory
Onboard memory for up to 200 results

Detector
Silicon Photodiode

Safety Features
Overload protection, power failure memory backup

Calibration
Auto calibration with in-built standards

Operation Modes
Photometric, Quantitative, Wavelength Scan, Reaction Kinetics

Display
Large LCD digital display

Stray Light
Less than 0.3% at 220 nm

Data Output
USB and RS232 ports

Wavelength Range
190 nm to 1000 nm

Sample Holder Type
Standard cuvette (10 mm path length)

Wavelength Accuracy
±0.5 nm

Light Source Life
Deuterium Lamp: 1000 hrs, Tungsten Halogen: 2000 hrs

Photometric Range
-0.3 to 3.0 Abs

Spectral Bandwidth
2 nm

Lamp Type
Deuterium and Tungsten Halogen Lamp

MICROPROCESSOR UV SPECTRO PHOTOMETER Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About MICROPROCESSOR UV SPECTRO PHOTOMETER

MICROPROCESSOR UV SPECTRO PHOTOMETER ETA-17

We offer wide range of Double Beam Spectrophotometer with following specifications.

SPECTREAL

Range 190 to 1100nm
Resolution 0.1 nm
Sepctral Band Width 1 nm
Accuracy 0.3 nm
Repeatability 0.2 nm

PHOTOMETRIC

Photometric Range % T : 0 to 200 % , 0.3 to 3.0 A, 0 to
999C
Accuracy 0.001 A/h
Stray Light 0.05% T @ 220 nm, 360 nm
Data Readout 6âLCD
Key Board 4 Keys, soft touch membrance type
Serial Interface USB
Light Source a) Tungsten Halogen Lamp
b) Deuterium Lamp (D2)
Detector Selecon Photo load
Readability 1 Count
Printer Interface Printer interface for any centronics
dot matrix printer
Optics Complete mirror optics with resolution
1200 grooves/mm grating
Power 230V 10% AC, 50 Hz

High Precision and Versatile Functionality

Engineered for both qualitative and quantitative analysis, this spectrophotometer ensures reliable results across a broad wavelength range. A microprocessor-controlled digital interface simplifies operation, and auto calibration guarantees accuracy with every measurement. Its durable lamps and low stray light provide outstanding reproducibility for critical laboratory tasks.

User-Friendly Operation and Data Management

Featuring a large LCD digital display and intuitive controls, the device enables smooth handling of photometric, quantitative, scanning, and kinetic experiments. Onboard memory stores up to 200 measurements, while USB and RS232 outputs facilitate easy data transfer to external devices, supporting comprehensive record-keeping and analysis.

Designed for Laboratory Excellence

Constructed from high-grade plastic and metal with optimal environmental tolerance, this spectrophotometer is ideal for routine and advanced applications in pharmaceutical, chemical, environmental, and research laboratories. Built-in safety features, compact design, and single sample handling make it a practical and dependable choice for a variety of professional settings.

FAQs of MICROPROCESSOR UV SPECTRO PHOTOMETER:

Q: How does the MICROPROCESSOR UV SPECTRO PHOTOMETER achieve high wavelength accuracy?

A: The device utilizes precise microprocessor control and in-built calibration standards to maintain a wavelength accuracy of 0.5 nm, ensuring highly reliable and reproducible spectral measurements.

Q: What types of samples and cuvettes can be used with this spectrophotometer?

A: Standard cuvettes with a 10 mm path length are supported, making the instrument suitable for liquid samples in pharmaceutical, chemical, and environmental testing applications.

Q: When should the Deuterium and Tungsten Halogen lamps be replaced?

A: The Deuterium lamp has a typical lifespan of 1000 hours, while the Tungsten Halogen lamp lasts up to 2000 hours. Lamp replacement is recommended upon reaching these operational hour limits or if light intensity visibly diminishes.

Q: Where can the stored data be accessed or transferred from the instrument?

A: Results stored in the onboard memory (up to 200 entries) can be accessed via the large LCD display and transferred easily through USB and RS232 ports to external computers for further analysis or record keeping.

Q: What is the process for auto calibration on this spectrophotometer?

A: The instrument features automated calibration using its built-in calibration standards, which simplifies setup and ensures measurement accuracy without manual adjustments.

Q: How do the safety features benefit laboratory users during operation?

A: Equipped with overload protection and power failure memory backup, the spectrophotometer safeguards data and prolongs instrument life, offering peace of mind during critical laboratory procedures.

Q: What are the primary benefits of using this spectrophotometer in laboratory analysis?

A: Its comprehensive operation modes, high accuracy, reliable performance, and efficient data management streamline both routine and specialized analyses, delivering trustworthy results for research and industrial applications.
