INDUCTION MACHINE (ASYNCHRONOUS)

Price 100.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

INDUCTION MACHINE (ASYNCHRONOUS) Specification

Operating Temperature
-10C to 50C

IP Rating
IP55

Components
Stator, Rotor, Frame, Terminal Box

Interface
Terminal Block

Output
Rotational Mechanical Power

Power Supply
Three Phase AC

Features
Robust construction, Low maintenance, Smooth operation

Power Source
Electricity

Response Time
Instantaneous

Input
Electric Power

Usage
Industrial Automation, Pumping, Fans, Compressors

Product Type
Asynchronous Induction Machine

Application
Machinery Drive, Industrial Equipment, Conveyor Systems

Rated Voltage
415 V

Supply Voltage
415/380 V

Size
Standard

Dimension (L*W*H)
46 cm x 27 cm x 30 cm

Function
Convert electrical energy into mechanical energy (rotary motion)

Color
Blue

Weight
27 kg

Current Rating
6.2 A

Capacity
3 HP

Frequency
50 Hz

Cooling Type
Surface fan cooled

Speed
1440 RPM

Phase
Three Phase

Number of Poles
4

Enclosure
TEFC (Totally Enclosed Fan Cooled)

Insulation Class
Class F

Mounting Type
Foot Mounted

Duty Cycle
S1 (Continuous Duty)

Noise Level
< 70 dB

Starting Method
Direct On Line (DOL) or Star-Delta

Frame Size
112M

Efficiency
87% (at rated load)

INDUCTION MACHINE (ASYNCHRONOUS) Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Telegraphic Transfer (T/T), Cash in Advance (CID), Cash Advance (CA), Letter of Credit (L/C), Cheque

Supply Ability
Unit

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Eastern Europe, Middle East, Western Europe, Africa, Asia

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About INDUCTION MACHINE (ASYNCHRONOUS)

INDUCTION MACHINE (ASYNCHRONOUS)TRAINING UNIT

The unit serves to familiarize students with the components and principle of operation of induction machines and enables them to examine the characteristic values ofthe induction machines

The motor power: 300W

Unit power supply 220V, 60Hz, 3-phase

Pc and Software and license for operation included all required tools for operation series of motors, generators, brake, tools and various accessories to be able to make any test on the electric induction machines included

Unit complete with all required accessories

High-Efficiency Design

This induction machine achieves up to 87% efficiency at its rated load, minimizing energy consumption and operational costs. Its surface fan cooling mechanism and TEFC enclosure enhance heat dissipation and protect internal components, supporting continuous, heavy-duty industrial applications while maximizing reliability.

Versatile Industrial Applications

With a power output of 3 HP and an operating speed of 1440 RPM, this motor serves diverse industrial purposes, including conveyor systems, pumping stations, fans, compressors, and general machinery drives. The foot-mounted structure and terminal block interface accommodate easy and flexible installations across various manufacturing environments.

Durable and Safe Construction

The induction machines robust build, IP55 ingress protection, and Class F insulation safeguard against moisture, dust, and voltage fluctuations. Its low noise (under 70 dB) and instantaneous response time ensure a safe and comfortable workplace, making it a trusted choice in critical operations and industrial automation.

FAQs of INDUCTION MACHINE (ASYNCHRONOUS):

Q: How does the three-phase induction machine convert electrical energy into mechanical energy?

A: The induction machine utilizes the interaction between its stator and rotor. When three-phase AC voltage is supplied to the stator, a rotating magnetic field is produced, inducing current in the rotor. This interaction generates torque, resulting in mechanical rotary motion, which is harnessed for driving various industrial equipment.

Q: What are the advantages of using a TEFC enclosure in this induction motor?

A: A Totally Enclosed Fan Cooled (TEFC) enclosure ensures that the motors internal components are shielded from dust, moisture, and contaminants. It also supports efficient cooling via an exterior fan, leading to enhanced durability, low maintenance requirements, and reliable operation even in harsh industrial environments.

Q: When should I choose star-delta starting over direct-on-line (DOL) for this motor?

A: Star-delta starting is preferable for applications where reduced starting current is necessary to avoid electrical surges and minimize stress on the power supply system. DOL starting can be used for lower-capacity installations where the incoming supply can handle the inrush current. Both methods suit this induction motors specifications.

Q: Where can this induction machine be installed for optimal performance?

A: It is designed for foot-mounted installations in industrial automation settings such as pump stations, conveyors, compressors, and machinery drives. The IP55 rating and standard frame size allow it to function reliably indoors where exposure to dust, moisture, and varying temperatures is expected.

Q: What is the maintenance process required for this induction motor?

A: Routine maintenance involves periodic inspection of the bearings, terminal connections, and cooling fans. With its robust, low-maintenance TEFC construction, regular cleaning of the external surface and ensuring the fan operates efficiently will maximize lifespan and performance.

Q: How does the motors efficiency benefit industrial operations?

A: Operating at an efficiency of 87% at rated load means lower electricity consumption and reduced operating costs. Improved energy utilization also contributes to sustainability and decreases downtime, ensuring processes run smoothly in industrial settings.

Q: What safety features are incorporated in this machine?

A: Safety is assured through features such as Class F insulation, IP55 ingress protection, low noise emission, and instantaneous response time. These elements protect against environmental hazards, electrical faults, and ensure workplace comfort and safety during continuous operation.
