GRAIN SIZE CHART .

Price 100.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

GRAIN SIZE CHART . Specification

Core Components
Reference Chart, Printed Standards

Measurement Range
ASTM Grain Size Numbers 1 to 12

Feature
Accurate ASTM E112 Comparison

Automation Grade
Manual

Accuracy
Standardized to ASTM E112 %

Model No

Equipment Materials
High Quality Paper / Laminate

Type
GRAIN SIZE CHART

Usage
Grain Size Measurement Reference

Display Type
Analog (Chart Format)

Dimension (L*W*H)
Approx. 210mm x 297mm (A4 Size) Millimeter (mm)

Weight
Lightweight, Typically <100g Grams (g)

Surface Finish
Glossy or Matte (Depending on Model)

Packaging Type
Protected Cardboard Envelope

Application
Metallurgical Laboratory, Educational, Industrial QA

Print Resolution
High Clarity Precision Print

Color
Black & White Reference with Clear Grids

Language
English

Environmental Resistance
Moisture Resistant (When Laminated)

Lifespan
Unlimited with Proper Handling

About GRAIN SIZE CHART .

GRAIN SIZE CHART

Use: Soil grain chart

Standards

To classify soils to BS 1377:2, ENV 1997-2, ASTM D4318, AASHTO T89

Specifications:

Grain Size Chart is widely used by field geologists for describing samples.
Pocket-sized with recessed die-cut sample cavities filled with precision sieved sedimentary particles permanently mounted to the chart.
Classed according to the Wentworth grading system.

Accurately Assess Grain Size in Metallurgy

This chart delivers reliable ASTM E112-compliant grain size comparisons, making it indispensable for metallurgical professionals, students, and industry QA teams. The high clarity print and sharp grid references ensure measurements are straightforward, and the charts analog format streamlines manual evaluations without electronic equipment.

Durable Design for Longevity

Constructed from premium paper or laminate, the GRAIN SIZE CHART resists moisture (when laminated) and physical wear, ensuring long-term usability. Lightweight and compact, it is convenient to use on the go or store in laboratories, classrooms, or QA departments.

FAQs of GRAIN SIZE CHART:

Q: How do I use the GRAIN SIZE CHART for grain size measurement?

A: To use the GRAIN SIZE CHART, place your sample under a microscope and compare its grain structure to the printed reference grids (ASTM grain sizes 1 to 12) on the chart to determine the closest match. The chart facilitates quick and accurate evaluation according to ASTM E112 standards.

Q: What makes this chart suitable for industrial, educational, and laboratory applications?

A: Its standardized measurements, high clarity precision printing, and robust construction make the chart ideal for professional metallurgists, educators teaching material science, and industrial quality assurance teams ensuring compliance with ASTM E112 guidelines.

Q: What is the benefit of choosing a laminated GRAIN SIZE CHART?

A: A laminated version offers enhanced moisture resistance, increasing the charts durability and making it suitable for challenging environments or frequent handling, thus ensuring a longer operational life.

Q: When should I consider replacing the chart?

A: With proper handling and storage, the chart has an unlimited lifespan. Replacement is typically only necessary if the chart is physically damaged, excessively soiled, or if standards are updated.

Q: Where can the GRAIN SIZE CHART be stored safely?

A: Store the chart in the provided protected cardboard envelope or in a dry, flat location away from direct sunlight and moisture to maintain its quality and extend its usability.

Q: What is the process for ensuring measurement accuracy with this chart?

A: For consistent accuracy, always compare against the high-clarity reference grids under adequate lighting and follow the ASTM E112 procedures outlined by your laboratory or institution.

Q: What are the main advantages of using an analog chart format?

A: The analog format allows for immediate, electricity-free visual reference, making it ideal for quick checks, fieldwork, or laboratories without digital grain size measurement equipment.
