Send InquiryFET CHARACTERISTICS APPARATUS WITH BAKELITE PANEL & ROUND METERS
MOQ : 1 Piece
FET CHARACTERISTICS APPARATUS WITH BAKELITE PANEL & ROUND METERS Specification
- Operating Temperature
- 0C to 50C.
- IP Rating
- Not rated (for indoor lab use only).
- Thermal Conductivity
- Not applicable.
- Interface
- 4mm safety socket terminals for external connections.
- Usage
- ENGINEERING ELECTRONICS INSTRUMENTS
- Sensors Specification
- Not applicable.
- Power Source
- Mains powered (AC supply).
- Response Time
- Immediate (depends on analog meter movement).
- Components
- FET, variable resistors/potentiometers, ammeter, voltmeter (round analog meters), switches, terminals.
- Display Type
- Round analog meters for voltage and current.
- Input
- Variable DC supply for FET biasing, typically 0-30V.
- Processor Speed
- Not applicable.
- Features
- Robust bakelite panel, easy-to-read round analog meters, suitable for demonstration and student use.
- Output
- Measured values of voltage and current for plotting characteristics.
- Resolution
- Analog meter resolution defined by scale marking (typically 0.1V/step or 0.01mA/step).
- Charging Voltage
- Not applicable.
- Power Supply
- 230V 10% AC, 50 Hz single phase.
- Product Type
- FET CHARACTERISTICS APPARATUS WITH BAKELITE PANEL & ROUND METERS
- Application
- ENGINEERING ELECTRONICS INSTRUMENTS
- Rated Voltage
- Not specified (typical use: 0-30 V DC supply).
- Supply Voltage
- 230V AC / 50 Hz
- Size
- Panel size approx. 300mm x 200mm.
- Dimension (L*W*H)
- Approx. 300 mm 200 mm 90 mm
- Function
- To plot the characteristics of Field Effect Transistor (FET), specifically drain and transfer characteristics.
- Color
- Black panel (bakelite) with white printed front panel layout.
- Weight
- Approx. 2.5 - 3 Kg.
- Capacity
- Suitable for performing FET characteristic experiments in academic labs.
- Current Rating
- Ammeter range typically up to 1 mA or 10 mA DC.
- Thickness
- Bakelite panel thickness: 4-5 mm approx.
- Frequency
- 50 Hz (AC supply frequency).
- Meter Type
- Round analog, moving coil meters.
- Environment
- Intended for use in physics/electronics laboratories.
- Panel Material
- High-quality bakelite for increased insulation and durability.
- Indication
- Mechanical pointer analog meters for both voltage and current.
- Test Points
- Multiple front panel terminals for measurement.
- Safety Standard
- Fused input and proper insulation for student safety.
- Control Elements
- Rotary knobs for voltage/current adjustment.
- Mounting Type
- Table-top/bench mount.
- Transistor Type
- N-channel or P-channel FET depending on model.
- Accessories Included
- Connecting leads, user manual.
FET CHARACTERISTICS APPARATUS WITH BAKELITE PANEL & ROUND METERS Trade Information
- Minimum Order Quantity
- 1 Piece
- Packaging Details
- Carton Box, Export Quality also Available
- Main Export Market(s)
- Asia, Middle East, Africa
- Main Domestic Market
- All India
- Certifications
- ISO 9001, 14001, CE
About FET CHARACTERISTICS APPARATUS WITH BAKELITE PANEL & ROUND METERS
Specification:
FET CHARACTERISTICS APPARATUS WITH BAKELITE PANEL & ROUND METERS
Two Variable DC Regulated Power Supply ( 0 - 5V & 0 - 15V )
Three Analog Moving Coil Meter ( 5V , 5 mA / 15 mA , 15V )
Power Requirement: 220V AC 10%, 50Hz
Cabinet Size(mm): 330 mm x 205 mm x 85 mm
Robust Design for Safe Student Use
This apparatus is built on a high-quality bakelite panel, delivering superior insulation and durability, essential for educational laboratory settings. Fused input further enhances user safety, ensuring the system is ideal for student applications across engineering and electronics courses.
Precise Measurement and Ease of Operation
Equipped with round analog moving coil meters, the device allows accurate and quick readings of voltage and current, facilitating reliable plotting of drain and transfer characteristics of FETs. Rotary knobs enable straightforward adjustment, while clear front-panel terminals make measurement processes efficient.
Versatile Applications in Academic Labs
Designed for tabletop use and bench mounting, this instrument suits a wide range of laboratory configurations. Its integration of FETs, variable resistors, switches, and analog meters serves to demonstrate electronic principles and FET behaviors to students and instructors alike.
FAQs of FET CHARACTERISTICS APPARATUS WITH BAKELITE PANEL & ROUND METERS:
Q: How do I use the FET Characteristics Apparatus to plot FET characteristics?
A: To plot FET characteristics, connect the supplied leads according to the user manual, set the required bias voltage using rotary knobs, and use the round analog meters to measure drain current and voltage across the FET. Record the readings while varying gate or drain voltages to plot the transfer and drain characteristics.Q: What are the benefits of using a bakelite panel in this apparatus?
A: Bakelite panels offer excellent electrical insulation and robustness, providing increased safety and longevity in laboratory environments. This minimizes risks and ensures consistent performance even during extensive student use.Q: Where is the FET Characteristics Apparatus typically used?
A: This apparatus is intended for use in academic settings such as physics and electronics laboratories, mainly within schools, colleges, and engineering institutes for demonstration and experimental studies of FETs.Q: What safety features are incorporated in the apparatus for students?
A: Safety is prioritized through the use of fused input and high-quality insulation. Bakelites durability and insulation properties, along with properly rated terminals and protective measures, help reduce accident risks during operation.Q: Which FET types can be studied using this device and how is the type selected?
A: Depending on the chosen model, the apparatus is equipped with either N-channel or P-channel FETs. Selection of FET type must be specified at the time of purchase according to the experimental curriculum requirements.Q: What process should I follow for external connections to the apparatus?
A: External connections are made using the provided 4mm safety socket terminals and connecting leads. These terminals allow secure attachment of measuring instruments and inputs, guided by the step-by-step instructions outlined in the user manual.Q: What accessories are included with the apparatus and how do they enhance usability?
A: The FET Characteristics Apparatus comes supplied with connecting leads and a detailed user manual. These accessories facilitate a quick and straightforward setup, enabling users to begin experiments without the need for additional equipment.
