Digital Flame Photometer

Get a Price/Quote

MOQ : 1 Piece

Digital Flame Photometer Specification

Usage
Measurement of sodium, potassium, calcium, and lithium concentrations

Voltage
230 V AC ±10%, 50 Hz

Classification
Analytical Instrument

Operate Method
Digital display, keypad operation

Application
Clinical laboratory, Agricultural, Environmental analysis, Soil and plant analysis

Capacity
Sample volume: 3 ml

Product Type
Digital Flame Photometer

Power
50 W

Material
Metal body with powder coating

Color
White and Blue

Weight
6.5 kg

Dimension (L*W*H)
360mm x 250mm x 210mm

Data Output
RS232 serial port

Aspiration Time
8 seconds per measurement

Sample Throughput
Up to 70 samples per hour

Response Time
Less than 10 seconds

Filter Set
Optical filters for Na, K, Ca, Li

Ambient Temperature
10C to 40C

Sensitivity
Na/K: 1 ppm minimum

Measuring Channels
Up to 4 channels (Na, K, Ca, Li)

Display Type
Digital LED display

Flame Type
Gas - LPG/Air

Safety Features
Flame failure protection, Overload shut-off

Accuracy
2% for Na/K/Li

Nebulizer Type
Stainless steel, non-corrosive

Detector
Photoelectric flame detection

Calibration
Automatic and manual modes

Digital Flame Photometer Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Digital Flame Photometer

Digital Flame Photometer

Flame photometers are used to determine concentration of Na, K, Li and Ca solutions in clinical lab and soil laboratories. These equipment are durable, rugged in construction, reliable and give 100% accurate test results. Engineered using quality raw material and electronic components our range of Flame Photometers are fabricated in strict compliance with international quality standards. We offer Flame photometers in standard as well as customized specifications at industry leading prices.


No. of Filters	Na & K (Ca & Li optional)	Na & K (Ca & Li optional)
Range	Na: 0-100 ppm Ca: 20-100 ppm	Na: 0-200 meq/l Ca: 0-2 meq/l
	K : 0-100 ppm	K : 0-100 meq/l
	Li: 10-100 ppm	Li: 0-10 meq/l
Sensitivity	Na: 5 ppm Ca: 10 ppm	Na: 5 pmm Ca: 10 ppm
Sensitivity	K : 5 ppm Li: 10 ppm	K : 5 pmm Li: 10 ppm
Display	2 1/2 digit bright LED Display	Dual 2 1/2 digit bright LED Display
Accuracy	+ 2% upto 40 ppm	+ 2% upto 100 meq/l
Accuracy	+ 5% above 40 ppm	+ 5% above 100 meq/l
Repeatability	+ 2 Count	+ 2 Count
Detector	Silicon Photodiode	Silicon Photodiode
Filters	Narrow band interference glass filters	Narrow band interference glass filters
Nebulizer	Black bakelite, axial flow type	Black bakelite, axial flow type
Flame System	LPG and dry oil free air	LPG and dry oil free air
Warmup time	10 minutes	10 minutes
Power	230V + 10% AC 50 Hz	230V + 10% AC 50 Hz
Size (LxBxH)	355 x 250 x 210 mm	455 x 250 x 210 mm
Weight	6.5 kg (Approx.)	7.5 kg (Approx.)

Salient features of Flame photometers are:

Simple & easy to operate
Narrow band interference filters
Dual channel display Na & K at single aspiration

High-Precision Multi-Channel Analysis

Our digital flame photometer enables simultaneous detection of sodium, potassium, calcium, and lithium concentrations with high sensitivity and accuracy. The instrument is designed with four channels, optical filters for selectivity, and rapid aspiration and detection rates, making it suitable for diverse laboratory requirements.

User-Friendly Operation with Digital Display

The device features a clear digital LED display and intuitive keypad controls, supporting both automatic and manual calibration. Users can easily monitor results, securing reliable measurements quickly with a straightforward user interface, while benefiting from a fast response time of under 10 seconds.

Safety and Durability Built-In

Safety measures such as flame failure protection and overload shut-off are integrated to safeguard users during operation. The non-corrosive stainless steel nebulizer and robust powder-coated metal body ensure long-term durability and resistance to demanding operational environments.

FAQs of Digital Flame Photometer:

Q: How do you operate the digital flame photometer for sample measurement?

A: To operate the photometer, add approximately 3 ml of sample, select the target channel using the keypad, and initiate the measurement. The instrument aspirates the sample for 8 seconds, displays the concentration result on the LED display, and is ready for the next sample almost immediately.

Q: What benefits does the multi-channel design offer for laboratory analysis?

A: The photometers four channels allow for simultaneous or sequential measurement of sodium, potassium, calcium, and lithium, increasing sample throughput and ensuring versatile application in clinical, agricultural, and environmental laboratories.

Q: Where can this digital flame photometer be effectively used?

A: It is suitable for clinical laboratories, agricultural research centers, environmental analysis labs, and facilities conducting soil and plant analysis, supporting a wide spectrum of analytical needs.

Q: What is the calibration process, and when should it be performed?

A: Calibration can be conducted automatically or manually, ensuring accurate readings. It is recommended to calibrate the instrument at the beginning of each analysis session, after changing gas cylinders, or when switching analyte channels.

Q: How does the device maintain measurement accuracy and data integrity?

A: The photometer maintains 2% accuracy for Na, K, and Li measurements, and provides stable data output via the RS232 serial port, allowing easy integration with laboratory information systems.

Q: What safety features are incorporated in the photometer?

A: Safety provisions include flame failure protection and an overload shut-off mechanism, providing operational safety and automatically shutting down the device if unsafe conditions are detected.
