Digital Automatic Melting Point Apparatus

Send Inquiry

Request To Call Back

Digital Automatic Melting Point Apparatus

Price 1000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Digital Automatic Melting Point Apparatus Specification

Operate Method
Digital (Automatic) with Keypad Controls

Capacity
Multiple samples (up to 3 capillaries at a time)

Product Type
Digital Automatic Melting Point Apparatus

Power
40W

Weight
4.5 kg (approx.)

Color
White and Blue

Application
Pharmaceutical, Chemical, Research Laboratories

Classification
Lab Equipment

Dimension (L*W*H)
300 x 220 x 170 mm (approx.)

Usage
For precise determination of melting points of solid substances

Voltage
220V AC, 50Hz

Material
Metal Body with Powder Coating

Temperature Resolution
0.1C

Safety Features
Over-temperature Protection and Thermal Cut-off

Calibration
Digital Auto Calibration feature

Display Type
Backlit Digital LCD

Heating Rate
Selectable (0.5C/min to 5C/min)

Temperature Range
Room temperature to 300C

Cooling Time
Fast Cooling by Standby Fan (Optional)

Accessories Included
Sample Capillaries, Power Cord, Operating Manual

Environmental Conditions
Operating humidity 20-80% RH, Non-condensing

Alarm
Audio/Visual End-of-Test Alarm

Fuse Protection
Internal replaceable fuse

Sample Viewing
Magnifying Lens with LED Illumination

Data Output
RS232 Interface for Printer/PC Connectivity

Sample Holder
Sealed Capillaries with Holder for 3 samples

Digital Automatic Melting Point Apparatus Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Digital Automatic Melting Point Apparatus

Digital Automatic Melting Point Apparatus ETA-27

Digital automatic Melting Point Apparatus is designed for quick and accurate detection of melting point. Feature packed & easy to use, this is an indispensable bench top tool. This equipment has an arrangement to hold the capillary containing the sample in uniformly heating media. The temperature is indicated on a digital display readable in I.0C. At the point, when the sample melts, the heating is automatically cut-off and the digital display showing the temperature remains on the indicator till it is cleared. No silicon oil or other bath is required as heating media . Range 2.0C above room temperature to 350C.

Specifications
Display	Digital 3 1/2 Digit, Bright LED
Accuracy	0.01
Operation	Fully Automatic
Dimensions	L 405 x B 360 x H 235 mm (approx)
Weight	5 Kg (approx.)
Power	230V + 10?, 50Hz
Accessories	Capillary Tube - 100 No.
Accessories	Cleaning Tool - 1 No.

Precision and Reliability in Melting Point Analysis

With advanced digital controls and automatic temperature calibration, this apparatus delivers reliable melting point measurements for up to three samples simultaneously. Exceptional temperature resolution and selectable heating rates ensure flexibility for a range of substances commonly tested in pharmaceutical and research settings.

Intuitive User Interface and Enhanced Viewing

A backlit digital LCD provides clear readouts while keypad controls make operation straightforward. The built-in magnifying lens with LED illumination allows close observation of samples during tests, and audio/visual alarms notify users immediately upon test completion, supporting efficient workflow.

Safety and Connectivity for Modern Laboratories

Engineered for safety, the unit features over-temperature protection, an automatic thermal cut-off, and an internal replaceable fuse. The RS232 data output enables seamless integration with computers or printers, facilitating comprehensive documentation and data management.

FAQs of Digital Automatic Melting Point Apparatus:

Q: How is the melting point determined using this apparatus?

A: The apparatus heats solid samples contained in sealed capillaries at a selectable rate within the 0.5C/min to 5C/min range. The melting process is observed via the magnifying lens with LED illumination, and the precise temperature at which the sample melts is displayed on the digital LCD.

Q: What types of laboratories commonly use this melting point apparatus?

A: It is widely utilized in pharmaceutical, chemical, and research laboratories for accurate determination of melting points of various solid substances, ensuring product quality and compliance with industry standards.

Q: When should the digital auto-calibration feature be used?

A: Digital auto-calibration should be conducted periodically, especially prior to critical measurements or after extended periods of non-use, to maintain optimal accuracy in melting point readings.

Q: Where can the data from the melting point test be stored or sent?

A: Data can be transmitted via the RS232 interface to a connected printer or computer, enabling secure digital storage and efficient result sharing or documentation.

Q: What are the key safety features of the apparatus during operation?

A: Safety is ensured by over-temperature protection, an automatic thermal cut-off, and an internal replaceable fuse, safeguarding users and laboratory environments from potential hazards.

Q: How does the optional standby fan aid in the cooling process?

A: The optional standby fan increases air circulation around the device, significantly reducing cooling times between tests and enhancing overall throughput in busy laboratory settings.

Q: What are the benefits of testing up to three samples simultaneously?

A: Simultaneous testing of up to three samples increases productivity and allows comparative analysis, reducing time and effort needed for batch sample evaluation.
