Digital Flame Photo Meter

Price 100.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Digital Flame Photo Meter Specification

Dimension (L*W*H)
350 x 260 x 170 mm

Weight
Approx. 6 kg

Classification
Scientific Laboratory Equipment

Capacity
Single channel (Na/K); optional dual/different channels

Product Type
Digital Flame Photo Meter

Material
Metal Body with Plastic Front Panel

Usage
Digital Flame Photo Meter

Color
White and Blue

Application
Clinical Labs, Biochemistry Labs, Research Institutions, Environmental Testing

Operate Method
Digital, Manual Calibration

Voltage
230 Volt (v)

Power
Power 230V 10% AC 50 Hz Volt (v)

Display
Digital LED Readout

Accessories
Compressor, Nebulizer, Standard Solutions, Instruction Manual

Detector
Photo Sensor

Sample Introduction
Nebulizer operated by air compressor

Calibration
Two Point Calibration

Filter System
Interference Optical Filters

Aspiration Rate
5-6 ml/min

Output
Analog (Recorder) and Digital

Safety Features
Fuse Protection, Overload Protection

Sensitivity
Na: 2 ppm, K: 1 ppm (typical)

Measuring Range
Sodium: 0 to 100 ppm, Potassium: 0 to 100 ppm

Digital Flame Photo Meter Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Letter of Credit (L/C), Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Eastern Europe, Western Europe, Middle East, Africa, Asia

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Digital Flame Photo Meter

Digital Flame Photo Meter ETA-12

We are manufacturer and exporter of digital flame photo meter in India.

Specification of Digital Flame Photo Meter

No. of Filters Na & K(Ca & Li optional)
Range Na : 0-100 ppm
Ca : 20-100 ppm
K : 0-100 ppm
Li : 10-100 ppm
Sensitivity Na : 5 ppm
Ca : 10 ppm
K : 5 ppm
Li : 10 ppm
Read out 2 digit bright LED Display
Accuracy 2% up to 40 ppm
5% above 40 ppm
Repeatability 2 Count.
Detector Silicon Photodiode
Filters Narrow band interference glass filters
Nebulizer Black bakelite, axial flow type
Flame System LPG and dry oil free air
Warmup time 10 minutes
Power 230V 10% AC 50 Hz

Advanced Detection System

Utilizing high-precision photo sensor detectors and interference optical filters, this flame photometer achieves reliable and selective detection of sodium and potassium ions in laboratory samples. Its digital LED display provides clear, quantitative results, simplifying the analytical workflow for researchers and technicians.

Effortless Calibration & Operation

Manual two-point calibration, supported by supplied standard solutions, enables precise measurement accuracy. The intuitive digital operation ensures consistent results. Nebulizer-driven sample aspiration, powered by an air compressor, allows smooth introduction of liquid samples into the instrument for analysis.

Safety and Reliability

Equipped with fuse protection and overload safeguards, this instrument ensures safe operation in busy laboratory environments. The sturdy metal construction, complemented by a functional plastic front panel, is built to withstand regular use while maintaining measurement integrity.

FAQs of Digital Flame Photo Meter:

Q: How is the sample introduced into the Digital Flame Photo Meter?

A: Samples are introduced using a nebulizer, which is operated by an air compressor included with the instrument. This ensures a consistent aspiration rate of 5-6 ml/min for effective analysis.

Q: What is the typical sensitivity for sodium and potassium detection?

A: The photo meter detects sodium at a sensitivity of 2 ppm and potassium at 1 ppm, providing accurate results even for low concentration samples.

Q: Where can this flame photometer be used?

A: It is suitable for clinical laboratories, biochemistry labs, research institutions, and environmental testing applications, wherever precise sodium and potassium measurement is required.

Q: What calibration process does the instrument utilize?

A: The device uses a manual two-point calibration system, employing supplied standard solutions to ensure measurement accuracy before sample analysis.

Q: What are the safety features of the Digital Flame Photo Meter?

A: Fuse protection and overload protection are integrated to safeguard the instrument and users during operation, especially in continuous laboratory workflows.

Q: What are the main benefits of using this photo meter?

A: It delivers quick, accurate measurements with digital LED display, supports both analog and digital outputs for data recording, and is easy to operate and calibrate, making it a reliable choice for scientific professionals.

Q: What accessories are provided with the photo meter?

A: The instrument is supplied with an air compressor, nebulizer, standard calibration solutions, and an instruction manual, facilitating immediate, effective laboratory use.
