Send InquiryMicrocontroller pH and Temperature Meter
MOQ : 1 Piece
Microcontroller pH and Temperature Meter Specification
- Product Type
- Microcontroller pH and Temperature Meter
- Usage
- To simultaneously measure pH and temperature in liquids
- Dimension (L*W*H)
- Approximately 220 x 200 x 60 mm
- Voltage
- 110-230V AC, 50/60Hz
- Operate Method
- Microcontroller based automatic operation via keypad
- Material
- ABS Plastic Body
- Application
- Educational, Industrial, Research Labs, Water Analysis
- Weight
- Around 1 kg
- Capacity
- Single junction, suitable for standard pH and temperature ranges
- Power
- External power adapter
- Classification
- Laboratory Meter Equipment
- Color
- White with Blue Panel
- Measurement Range (pH)
- 0.00 to 14.00 pH
- Calibration
- Automatic / Manual (2 or 3 point) Calibration
- Input
- BNC connector for pH electrode, RCA for temperature probe
- Compensation
- Automatic and Manual Temperature Compensation (ATC/MTC)
- Electrode Type
- Combined Glass Electrode for pH, PT100/NTC sensor for temperature
- Data Hold Function
- Yes
- Operating Temperature
- 0C to 50C
- Accuracy (pH)
- 0.01 pH
- Storage Condition
- -10C to 60C, dry place
- Accessories Included
- pH Electrode, Temperature Probe, Calibration Buffers, Power Adapter, Instruction Manual
- Alarm Function
- In-built for out-of-range readings
- Measurement Range (Temperature)
- 0C to 100C
- Auto Power Off
- Yes
- Resolution (pH)
- 0.01 pH
- Accuracy (Temperature)
- 0.1C
- Resolution (Temperature)
- 0.1C
- Display Type
- Digital LCD Display
Microcontroller pH and Temperature Meter Trade Information
- Minimum Order Quantity
- 1 Piece
- Payment Terms
- Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)
- Sample Available
- Yes
- Sample Policy
- Sample costs shipping and taxes has to be paid by the buyer
- Packaging Details
- carton box, export quality also available
- Main Export Market(s)
- Africa, Asia, Eastern Europe, Western Europe, Middle East
- Main Domestic Market
- All India
- Certifications
- ISO 9001, 14001 ,CE
About Microcontroller pH and Temperature Meter
Microcontroller pH and Temperature Meter ETA-01C
We offer wide range of Microcontroller pH And Temperature Meter for measurement of Ph and temperature, 3 Digit LED display with Ph combination electrode and temperature probe.
Technical Specifications of Microcontroller pH and Temperature Meter
| Range | 0 TO 14 pH | |
| Resolution | 0.01 pH | |
| Accuracy | + 0.01 pH + 1 digit | |
| Slope Adjustment | 80 % to 120 % by default 100 %. | |
| Temp. Compensation | 0 to 100 C Auto with temp. probe/Manual with Keys. | |
| Auto Buffer Recognition | 4.00 pH, 7.00pH, 9.20 pH (AUTOMATIC) | |
| Calibration | AUTO & MANUAL, 3 Point/2 Point (Programmable) | |
| 2- POINT, 3- POINT | ||
| mV (ORP) | ||
| Range | - 1999 mV to + 1999 mV | |
| Resolution | 1 mV | |
Advanced Dual Measurement
This meter is engineered to simultaneously monitor pH and temperature in liquids, delivering rapid and precise results. Users benefit from automatic temperature compensation, enhancing accuracy across a wide range of sample conditions. Its versatility makes it invaluable for water analysis, research, educational demonstrations, and industrial quality control.
Intuitive Calibration and Operation
Easily calibrate the device using its automatic or manual two- or three-point system, ensuring sustained measurement accuracy. The intuitive keypad interface and clear LCD display streamline setup, operation, and adjustment processes, making this meter accessible to both novice and experienced users.
Robust and Reliable Design
Crafted from durable ABS plastic and designed for laboratory environments, this meter resists wear and operates within a broad temperature range. The kit includes a pH electrode, temperature probe, calibration buffers, and manualeverything needed for immediate deployment and productivity in diverse settings.
FAQs of Microcontroller pH and Temperature Meter:
Q: How do I calibrate the Microcontroller pH and Temperature Meter?
A: Calibration is straightforward and can be performed automatically or manually at two or three points. Simply follow the on-screen instructions in the manual using the provided calibration buffers. This ensures consistent measurement accuracy for both pH and temperature.Q: What types of applications is this meter suitable for?
A: This meter is ideal for a variety of applications, including educational experiments, industrial quality control, laboratory research, and water analysis. Its broad measurement ranges and precise readings make it well-suited for most liquid testing scenarios.Q: When should I perform calibration for optimal accuracy?
A: It is advisable to calibrate the meter before each series of measurements, after changing electrodes, or if the device has not been used for an extended period. Regular calibration maintains the accuracy and reliability of your readings.Q: Where can I use this meter safely?
A: The meter operates effectively within temperatures of 0C to 50C and should be stored in a cool, dry place between -10C and 60C. Avoid environments with excessive humidity or dust to preserve its longevity and performance.Q: What is the benefit of the automatic temperature compensation (ATC) feature?
A: ATC allows the meter to automatically adjust pH readings based on the samples temperature, providing more accurate and reliable results across varying temperature conditions. This is especially important in laboratory and field measurements where sample temperatures may fluctuate.Q: How do I use the alarm and data hold functions?
A: The in-built alarm alerts you if your readings go beyond preset limits, ensuring prompt response to out-of-range situations. The data hold function allows you to freeze the current reading on the display for convenient recording or analysis.Q: What accessories are included with the meter?
A: Included accessories are a combined glass pH electrode, temperature probe, calibration buffer solutions, a power adapter, and a comprehensive instruction manual. These items provide everything you need for immediate setup and operation.
