Hemoglobin Meter

Get a Price/Quote

MOQ : 1 Piece

Hemoglobin Meter Specification

Voltage
220 Volts

Dimension (L*W*H)
260 x 180 x 75 mm

Usage
For quick hemoglobin measurement in clinical and laboratory settings.

Operate Method
Hemoglobin Meter Display 16X2 Lines LED Display. Measuring Range 0-40 gm/di of HB. Zero Adjustment Automatic . Dilution ratio 1.251. Key Board Soft touch 4 days. Calibration Automatic. Wavelength 530 nm. Detector High sensitive silicon photodiode.

Power
220V AC, 50Hz

Material
ABS Plastic Body

Classification
Hematology Analyzer

Weight
2.5 kg approx.

Product Type
MICROPROCESSOR HEMOGLOBIN METER

Application
Hospitals, Pathology Labs, Diagnostic Centers

Capacity
Single sample at a time

Color
White and Blue

Zero Adjustment
Automatic

Calibration
Automatic

Measuring Range
0-40 gm/dl of Hemoglobin

Sample Volume
10 µl

Key Board
Soft touch (4 keys)

Detector
High sensitive silicon photodiode

Wavelength
530 nm

Response Time
Less than 10 seconds

Dilution Ratio
1:251

Display
16x2 Lines LED Display

Hemoglobin Meter Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Western Europe, Middle East, Africa, Asia, Eastern Europe

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Hemoglobin Meter

MICROPROCESSOR HEMOGLOBIN METER ETA-19A

Edutek are manufacturer and exporter of hemoglobin meter for testing lab.

Specification of Hemoglobin Meter

Display 16X2 Lines LED Display.
Measuring Range 0-40 gm/di of HB.
Zero Adjustment Automatic .
Dilution ratio 1.251.
Key Board Soft touch 4 days.
Calibration Automatic.
Wavelength 530 nm.
Detector High sensitive silicon photodiode.

Cutting-Edge Hemoglobin Measurement

Engineered for accuracy and efficiency, the Hemoglobin Meter employs advanced photometric technology and a sensitive silicon photodiode detector. Automatic calibration and zero adjustment processes reduce human error, while the bright LED display ensures clear results. Its compact design and robust ABS plastic body make it reliable for various clinical environments.

User-Friendly Interface and Operation

This hemoglobin analyzer features a soft touch, 4-key keyboard, and a straightforward display for ease of use. Operators can measure hemoglobin levels rapidly with a minimal 10 l blood sample, making it ideal for busy clinical and laboratory settings.

FAQs of Hemoglobin Meter:

Q: How does the Hemoglobin Meter measure hemoglobin levels?

A: The Hemoglobin Meter uses spectrophotometric analysis at a wavelength of 530 nm with a high-sensitive silicon photodiode detector to provide accurate hemoglobin readings from blood samples.

Q: What is the operating process for measuring a sample?

A: To measure a sample, prepare a dilution (1:251 ratio), apply 10 l of the diluted sample, and operate the device using the soft-touch keys. The meter automatically calibrates and adjusts to zero, then displays the results in under 10 seconds.

Q: Where can this hemoglobin analyzer be used?

A: This device is suited for clinical and laboratory settings, including hospitals, pathology labs, and diagnostic centers, offering quick and reliable hemoglobin testing.

Q: What are the main benefits of using this hemoglobin meter?

A: The meter provides rapid and accurate results, requires minimal sample volume, is easy to operate, and has automatic calibration and zero adjustment, reducing the chance of errors and streamlining workflow.

Q: When should the equipment be calibrated or adjusted?

A: The Hemoglobin Meter features automatic calibration and zero adjustment, so manual calibration is typically not required. This ensures ongoing measurement accuracy and reliability.
