DC MICRO AMMETER 0-250A or 0- 300A

Get a Price/Quote

MOQ : 1 Piece

DC MICRO AMMETER 0-250A or 0- 300A Specification

Components
Moving coil, shunt, dial scale, pointer, protective casing

IP Rating
IP20 (typical, not water-resistant)

Power Source
Current circuit

Operating Temperature
0C to 50C

Processor Speed
N/A (Analog Device)

Features
Rugged construction, clear analog display, external shunt capability, panel mounting

Usage
ENGINEERING ELECTRONICS INSTRUMENTS

Resolution
Fine, depending on dial graduation

Sensors Specification
Moving coil mechanism

Input
DC Current (with shunt arrangement for high current)

Output
Analog needle indication

Interface
Panel mounting terminals

Display Type
Analog (Pointer/Scale)

Response Time
Instantaneous (analog response)

Power Supply
Self-powered via measured current

Product Type
DC MICRO AMMETER 0-250A or 0- 300A

Application
ENGINEERING ELECTRONICS INSTRUMENTS

Rated Voltage
Up to 75mV (via external shunt)

Supply Voltage
No separate supply (current-driven analog meter)

Size
96 mm 96 mm

Dimension (L*W*H)
96 mm 96 mm 38 mm

Function
Measures direct current (DC) in microamperes up to selected range (0-250A or 0-300A)

Color
Black (Panel), White (Dial), Marked Red/Black Indicators

Weight
Approx. 450 g (varies by model)

Capacity
0-250A or 0-300A (microammeter with external shunt for high current)

Current Rating
0-250A or 0-300A

Thickness
Approx. 38 mm

Frequency
DC Only (0 Hz)

Calibration
Factory calibrated, recalibration possible as per IS/IEC standards

Compliance Standards
IS 1248/IEC 60051

Service Life
Over 50,000 operations under standard conditions

Dielectric Strength
2 kV for 1 minute between terminals and casing

Accuracy Class
Class 1.5 or better

Shock Resistance
Standard mechanical protection for industrial use

Shunt Compatibility
External shunt required for measurement above internal microammeter capacity

Pointer Type
Knife-edge pointer to minimize parallax error

Scale Graduation
Precisely marked for 0-250A or 0-300A full scale

Mounting Type
Flush panel mount with rear terminal connections

Case Material
ABS plastic with transparent acrylic front cover

DC MICRO AMMETER 0-250A or 0- 300A Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash on Delivery (COD), Cash Advance (CA), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Packaging Details
Carton Box, Export Quality also Available

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001, CE

About DC MICRO AMMETER 0-250A or 0- 300A

Introducing the exceptional DC Micro Ammeter 0250A or 0300A, designed for engineering electronics instruments and built for unparalleled reliability. Enjoy instant checkout on this brilliant new device, offering competitive pricing, preeminent shock resistance, and robust construction for industrial environments. Featuring precisely marked scale graduations, ABS housing with an acrylic cover, and knife-edge pointer for accurate analog readings. Compatible with external shunt for high current measurement, factory calibrated, and compliant with IS 1248/IEC 60051 standards. Experience unmatched accuracy and over 50,000 operation cycles with this rugged, self-powered analog instrument.

Utility and Versatility Across Engineering Electronics

The DC Micro Ammeter 0250A or 0300A excels in rigorous industrial settings, ideally suited for engineering electronics instrumentation. Its flush panel mounting and robust design make it perfect for control rooms, process monitoring, and test benches. The exceptional surface application includes black panels and clear dial display with red/black indicators, optimizing visibility and integration in technical environments. Designed to measure direct current via external shunt, it offers reliability across diverse engineering projects.

Order Processing and Delivery Details

Order processing for the DC Micro Ammeter is streamlined for efficiency. With competitive list prices and prompt sample policy, units are dispatched from the designated FOB port in India after swift order confirmation. Our sample policies accommodate genuine inquiries, ensuring product suitability before full shipment. Standard delivery time ensures that your brilliant meter reaches you promptly, facilitating seamless integration into your engineering system and minimizing operational delays.

FAQs of DC MICRO AMMETER 0-250A or 0- 300A:

Q: How is the DC Micro Ammeter installed on a panel?

A: The ammeter is designed for flush panel mounting with rear terminal connections, ensuring secure and visible integration into industrial control panels and measuring systems.

Q: What kind of applications can use the DC Micro Ammeter 0250A or 0300A?

A: This device is ideal for engineering electronics instrumentation, monitoring DC current in control rooms, process systems, and test benches within industrial environments.

Q: When is an external shunt required for the measurement?

A: An external shunt is necessary when measuring currents beyond the internal capacity of the microammeter, specifically to handle ranges up to 250A or 300A as per your selection.

Q: Where are the competitive advantages of this ammeter most evident?

A: Its preeminent shock resistance, clear scale graduations, and IP20-rated rugged design make it especially viable in demanding industrial and laboratory settings.

Q: What is the process for recalibration as per IS/IEC standards?

A: Recalibration can be performed by authorized technicians in accordance with IS 1248/IEC 60051 standards, ensuring continued accuracy and compliance throughout the meters service life.

Q: How does using this ammeter benefit operational efficiency?

A: Its instantaneous analog response, precise indication, and factory calibration provide reliable, real-time measurements, supporting improved monitoring, faster diagnostics, and safer control over electrical installations.
