Cone Penetrometer .

Price 2000.0 INR/ Set

Get a Price/Quote

MOQ : 1 Set

Cone Penetrometer . Specification

Frequency
50 Hz Hertz (HZ)

Automation Grade
Manual

Core Components
Dial Gauge, Cone Assembly, Release Mechanism

Voltage
230V AC Volt (v)

Feature
Highly Efficient

Measurement Range
0 150 mm

Power Source
Manual

Model No

Accuracy
100 % %

Temperature Range
0 C 70 C Celsius (oC)

Capacity
0 150 gm/0.1 gm Pcs/hr

Equipment Materials
Stainless Steel/Brass

Type
Cone Penetrometer

Usage
Laboratory

Display Type
Analog

Dimension (L*W*H)
240 300 400 mm Millimeter (mm)

Weight
Approx. 6-8 kg Kilograms (kg)

About Cone Penetrometer .

CONE PENETROMETER

Use: Performing liquid limit and other penetration tests; for testing a wide variety of materials such as grease, petroleum,bitumen, tar, asphalt, wax, polish, food stuffs, rubber, cement, pharmaceutical creams and soils

Standard:

BS 1377, 1924-2, EN DD ENV 1997-2

Specifications:

Dial Indicator: 150 mm diameter graduated in 400 x 0.1 mm divisions.Indicator incorporates a friction/gear system.
Height: Adjustable using rapid integral clamping mechanism.
Cone Release: Manual.
Cone: 1 x 30, 35 mm test cone included.
Base: Cast aluminum with adjustable levelling feet.
Evaporating/mixing dish,
Test Gauge for checking the condition of the cone point.
Penetration test cup: 55 mm diam. x 40 mm deep with rim parallel to the flat base.
Penetration test cone: Stainless steel; 35 mm long with smooth surface at an angle of 30.

Accessories

Ground glass plate 305x305x10mm (12x12x3/8in) with seamed edges,
24 aluminum containers 51x22mm (2in dia. x 0.9in H) with snug-fitting lids,
Wash pan
Wooden-handled spatula with stainless steel blade 19x102mm, WxL, 24 250ml polyethylene squeeze wash bottle

Accurate Consistency Measurement

Designed for laboratory use, the Cone Penetrometer CP-150 delivers highly accurate assessment of material consistency. Its precision dial gauge, coupled with a stable cast iron base and adjustable stainless steel/brass components, ensures reliable penetration results for soil, grease, or wax samples. The 30 cone angle and magnetic clutch release mechanism contribute to repeatability and accuracy in each test cycle.

Efficient and User-Friendly Operation

Ease of operation stands at the core of the CP-150. The magnetic clutch allows for swift, consistent cone release, while the analog dial gauge provides clear, direct measurement readings. Manual operation eliminates complex set-up, making this instrument suitable even for users with minimal training. Its compact dimensions optimize lab bench space, and the powder-coated/polished finish enhances durability.

Versatile and Durable Design

Engineered to meet diverse laboratory requirements, the CP-150 is constructed from premium materials ensuring long-lasting performance. The heavy cast iron base maintains stability during tests, while stainless steel and brass assemblies offer corrosion resistance. It operates efficiently across a temperature range of 0C to 70C, blending versatility with robust build quality for dependable use in various analytical scenarios.

FAQs of Cone Penetrometer:

Q: How does the Cone Penetrometer determine consistency in semi-solid materials?

A: The Cone Penetrometer assesses consistency by measuring the depth of penetration of a standardized cone under controlled conditions into the test material. The instant magnetic release mechanism ensures accurate and repeatable readings shown on the analog dial gauge.

Q: What materials is the Cone Penetrometer suitable for testing?

A: This penetrometer is designed to determine the consistency of soil, grease, wax, and other semi-solid materials, making it suitable for a range of laboratory applications in material analysis and quality control.

Q: When should I use the Cone Penetrometer in laboratory testing?

A: Use the Cone Penetrometer when you need precise consistency measurements of semi-solid samples, for instance during soil classification, lubricant assessment, or wax quality evaluation, especially in quality assurance or research settings.

Q: Where can the Cone Penetrometer be used?

A: The is ideal for use in laboratories, including soil testing labs, petroleum and lubricant labs, academic research institutes, and industrial quality control departments.

Q: What is the process of operating the Cone Penetrometer ?

A: To operate, position the sample on the base plate, set the cone above the material, and secure the dial gauge at zero. Activate the magnetic clutch for instant release, then record the penetration depth from the dial after a set time.

Q: What are the main benefits of using this specific model?

A: The offers high accuracy (100%), rapid and repeatable measurements thanks to the magnetic clutch, a durable construction using stainless steel, brass, and cast iron, and a versatile temperature operation range, making it highly efficient for laboratory use.

Q: How is the maintained and cleaned?

A: Maintenance involves regular cleaning of the cone and dial gauge with a soft cloth, checking for residue on moving parts, and ensuring the magnetic clutch and mechanical assemblies are free of corrosion or debris after each use.
