WEIN BRIDGE OSCILLATOR USING OP AMP

Name: WEIN BRIDGE OSCILLATOR USING OP AMP
Brand: EDUTEK INSTRUMENTATION
Price: 1200.0 INR
Availability: InStock

Price 1200.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

WEIN BRIDGE OSCILLATOR USING OP AMP Specification

Power Source
Dual DC power supply

Interface
Banana sockets for connections

Output
Sine wave, single channel

Components
Op-amp IC (e.g., IC 741), resistors, capacitors, variable resistor (potentiometer), connectors, PCB, output terminals

Display Type
No inbuilt display

Power Supply
Dual DC supply

Input
No external input required (self-oscillating)

Thermal Conductivity
Standard electronic PCB

Response Time
Instantaneous upon power-up

Operating Temperature
0C to +55C

IP Rating
Not rated (for indoor/lab use)

Features
Frequency adjustable via potentiometer, easy component identification, protected output terminals

Usage
ENGINEERING ELECTRONICS INSTRUMENTS

Product Type
WEIN BRIDGE OSCILLATOR USING OP AMP

Application
ENGINEERING ELECTRONICS INSTRUMENTS

Rated Voltage
12V DC

Supply Voltage
12V DC

Size
Compact (approx. 115mm x 85mm)

Dimension (L*W*H)
115mm x 85mm x 25mm

Function
Generates sine wave oscillations

Color
Green PCB with assorted color components

Weight
Approx. 70g

Current Rating
< 50mA

Capacity
Single oscillator circuit

Thickness
Standard PCB: 1.6 mm

Frequency
Adjustable (typically 100Hz - 1kHz)

Safety
Protected output; low voltage operation

Calibration
Manual frequency adjustment via potentiometer

Op-amp Type
General-purpose (commonly IC 741 or compatible)

Component Mounting
Through-hole

Oscillator Type
Wien bridge

Connectors
4mm banana jack type

Compliance
RoHS compliant

PCB Material
FR4 glass-epoxy

Output Amplitude
Approx. 2V peak-to-peak (depends on power supply)

WEIN BRIDGE OSCILLATOR USING OP AMP Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash on Delivery (COD), Cash Advance (CA), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Packaging Details
Carton Box, Export Quality also Available

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001, CE

About WEIN BRIDGE OSCILLATOR USING OP AMP

The highly recommended WEIN BRIDGE OSCILLATOR USING OP AMP is the latest innovation for engineering electronics. Designed with a top-tier general-purpose op-amp (IC 741 or compatible), it produces radiant sine waves with adjustable frequencies from 100Hz to 1kHz. Its resplendent green FR4 glass-epoxy PCB ensures durability while easy-through-hole component mounting adds convenience. Equipped with protected, low-voltage banana jack outputs, this compact circuit operates safely and efficiently using just a dual 12V DC supply. Perfect for laboratory and educational settings, it promises reliable, self-oscillating performance. Try now to enhance your hands-on engineering experiments!

Ideal Application, Superior Features, Reliable Materials

WEIN BRIDGE OSCILLATOR USING OP AMP is perfectly suitable for use in engineering electronics instruments, both for learning and practical laboratory testing. Special features include manual frequency adjustment via a precision potentiometer, protected output, and easy-to-read component identification. Constructed using high-quality FR4 glass-epoxy for the PCB, it ensures dependable performance. Its through-hole component mounting streamlines assembly, while RoHS compliance guarantees a safe and environmentally friendly product.

Resplendent Arrival, Certifications & Domestic Coverage

This premium Wein Bridge Oscillator boasts compliance with RoHS standards for safety and environmental care. Upon arrival, users can expect immediate operation and robust build quality. The product targets the expansive domestic market and is supplied promptly across India by a trusted manufacturer, exporter, and supplier. Quick delivery times cater to institutional and individual requirements alike, ensuring this oscillator is always within reach for your laboratory or educational needs.

FAQ's of WEIN BRIDGE OSCILLATOR USING OP AMP:

Q: How do I adjust the frequency of the WEIN BRIDGE OSCILLATOR USING OP AMP?

A: You can manually adjust the output frequency by rotating the onboard potentiometer, allowing smooth frequency tuning typically between 100Hz and 1kHz.

Q: What are the main benefits of using this oscillator in a laboratory setting?

A: This oscillator offers stable sine wave generation, protected low-voltage outputs, easy component identification, and robust FR4 PCB construction-ideal for safe and resplendent lab experiments.
