Universal Profile Projector

Name: Universal Profile Projector
Brand: EDUTEK INSTRUMENTATION

Get a Price/Quote

MOQ : 1 Piece

Universal Profile Projector Specification

Accuracy
100 %

Test Range
0-300 mm (Diameter)

Automation Grade
Manual

Product Type
Universal Profile Projector

Max Height
150 mm workpiece

Usage
Laboratory

Operating Voltage
220V

Measuring Range
0-300 mm

Frequency
50 Hz

Display Type
Digital/Analogue

Equipment Type
Universal Profile Projector

Temperature
10°C to 40°C

Number of Specimens
1

Mounting Type
Floor/Bench Mounted

Humidity
Up to 85% RH, Non-Condensing

Application
Precision Measurement, Laboratory, Engineering Inspection

Response Time
Instantaneous

Resolution
0.001 mm

Interface Type
RS232 / USB (Optional)

Features
Highly Efficient

Specimen Size
Up to 300 mm Diameter

Power Supply
220V AC, 50Hz

Capacity
Depends on Model

Machine Weight
Approximately 120 Kg

Control Mode
Manual

Cooling System
Built-in Fan

Stage Size
350 x 150 mm

Light Source Life
2000 hours (Halogen), 30000 hours (LED)

Travel (X/Y)
150 x 100 mm

Magnification Accuracy
0.08%

Optical Path
Horizontal

Screen Diameter
300 mm

Illumination
Halogen & LED (Surface and Profile Light)

Lens Turret
3 Position (Standard Lenses 10x, 20x, 50x)

Data Output
Digital Readout System (DRO); Printer Port (Optional)

Focusing
Fine Adjustable

Optional Accessories
Digital Edge Sensor, DRO, Printer, Additional Lenses

Universal Profile Projector Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Letter of Credit (L/C), Telegraphic Transfer (T/T)

Sample Available
No

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Western Europe, Middle East, Africa, Asia, Eastern Europe

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Universal Profile Projector

Universal Profile Projector

Edutek Instrumentation are Manufacturer and Supplier Company in India,We are Exporter in India and other country. Technical Specification of Universal Profile Projector

Magnifications : 10X, 25X & 50X
Resolution : Linear : 0.001mm,
Angular : 1 min of arc
Functions : Inspection of profiles, templates, precision measurement of length and angle.

Precision Meets Versatility

This project brings together high-accuracy measurement (magnification accuracy of 0.08%) and adaptability for different specimen sizes, supporting precise results for both laboratory and industrial settings. The 3-position turret and a choice of illumination modes make it suitable for varied inspection tasks.

Adaptable for Diverse Applications

Designed for a wide range of precision measurement tasks, the Universal Profile Projector is ideal for engineering inspections, laboratory analyses, and quality control. Its large measurement capacity (up to 300 mm diameter specimens) supports numerous engineering and research needs.

Dependable Performance & User-Friendly Operation

Equipped with fine focusing, digital/analogue display options, and instant response times, the profile projector ensures both meticulous measurement and easy operation. The durable construction, efficient cooling, and long-life lighting systems (LED up to 30,000 hours) contribute to reliable day-to-day use.

FAQs of Universal Profile Projector:

Q: How is the Universal Profile Projector operated and what is its control mode?

A: The Universal Profile Projector operates in manual mode, requiring the user to adjust the lenses, illumination, and specimen positioning for optimal results. Controls are intuitive, designed for laboratory and inspection environments.

Q: What types of illumination does this projector support and how does it benefit measurement tasks?

A: It features both halogen and LED illumination (surface and profile lighting), allowing users to choose the most suitable lighting for each inspection, enhancing visibility and measurement accuracy across different specimen types.

Q: When should I use the different standard lenses (10x, 20x, 50x) on the projector?

A: Choose the 10x lens for general overview measurements, the 20x lens for intermediately detailed inspection, and the 50x lens for high-magnification analysis of fine features. The 3-position turret allows for quick switching based on your inspection needs.

Q: Where can the Universal Profile Projector be installed?

A: It is suitable for both floor and bench mounting, making it ideal for laboratory benches or dedicated inspection stations in engineering workshops.

Q: What is the measurement process using this equipment?

A: Place the specimen (up to 300 mm diameter, 150 mm height) on the stage, adjust the focal settings, select the required lens, and use the digital readout system for precise measurement. The protractor and X/Y travel facilitate comprehensive dimensional analysis.

Q: How does the digital readout system (DRO) and optional printer interface enhance usage?

A: The DRO provides accurate, instantaneous readings, while the optional printer port allows measurement data to be directly printed or exported via RS232/USB, streamlining documentation and reporting during inspections.

Q: What are the main benefits of using this profile projector for laboratory or engineering inspections?

A: Key benefits include high measuring accuracy (0.08%), versatile mounting and illumination, accommodation of large workpieces, long-lasting light sources, and user-friendly operationensuring reliable, repeatable results for precision measurement tasks.
