TRAINING EQUIPMENT IN INDUSTRIAL HYDRAULICS

Get a Price/Quote

TRAINING EQUIPMENT IN INDUSTRIAL HYDRAULICS Specification

Voltage
220V240V AC

Power Source
Electric Powered

Measurement Range
016 MPa (Pressure)

Capacity
Demonstration of Hydraulic Circuits

Feature
Modular Design, Transparent Panels for Observation, Leak-proof Construction, Quick Coupling Connectors

Automation Grade
Manual / Semi-Automatic

Frequency
50 Hz

Core Components
Hydraulic Pump, Directional Control Valves, Pressure Relief Valve, Flow Control Valve, Reservoir, Actuators (Cylinders), Pressure Gauges, Hose & Pipe Connections

Accuracy
Pressure Gauge Accuracy 1.6%

Temperature Range
0C to 60C

Model No
IHT-01 (or as per supplier)

Equipment Materials
Mild Steel Frame with Powder Coating, Acrylic Observation Panels, Stainless Steel Fittings

Type
Hydraulic Training System

Usage
Industrial Hydraulics Skill Development, Training & Demonstration

Display Type
Analog and Digital Gauges

Dimension (L*W*H)
Approx. 1500 800 1800 mm

Weight
Approx. 80-120 kg

TRAINING EQUIPMENT IN INDUSTRIAL HYDRAULICS Trade Information

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About TRAINING EQUIPMENT IN INDUSTRIAL HYDRAULICS

TRAINING EQUIPMENT IN INDUSTRIAL HYDRAULICS

Specification:

Universal Testing Frame constructed of a twinned steel channel frame fastened with high tensile fixings.
This creates an overall structure size of 4.61m long, 2.53m high and 1.2m wide and a working space of 4.0m long x1.6m high.
The 0.60m spacing between the verticals allows for wide test specimens to be tested. The base feet distribute the self weight of about 1 tonne to four anti-vibration leveling feet.
The top channel members are used to carry either a single or double acting hydraulic ram Carriage.
All these accessories enable specimens to be set up quickly and easily in a variety of arrangements.
A set of hollow steel dial gauge support bars should also be included.

Robust Training Platform

Engineered for industrial skill development, this hydraulic training system provides a platform for hands-on learning, simulation of faults, and maintenance procedure practice. Its mild steel frame, stainless steel fittings, and acrylic panels offer durability, safety, and clear visualization of hydraulic operations.

Versatile and Modular Design

Featuring exchangeable modules and transparent panels, learners can assemble a wide variety of hydraulic circuits. The mobile frame with lockable wheels and quick coupling connectors ensures easy relocation and setup, making it suitable for classrooms, training labs, or industrial workshops.

Accurate Measurements and Controls

The system includes analog and digital gauges, capable of precise pressure readings (1.6% accuracy), and accommodates a broad measurement range (016 MPa). Overload protection, emergency stop, and clear observation panels support a safe learning environment while mastering hydraulic technologies.

FAQs of TRAINING EQUIPMENT IN INDUSTRIAL HYDRAULICS:

Q: How does this hydraulic training system facilitate skill development?

A: This training equipment offers a hands-on approach for understanding both fundamental and advanced hydraulic circuits. By enabling users to assemble, operate, and troubleshoot various setups, it supports comprehensive learning, including fault simulation and maintenance procedures, which are essential for industrial hydraulics proficiency.

Q: What safety features are integrated into the hydraulic training equipment?

A: The system includes overload protection and an emergency stop switch to prevent accidents during practical sessions. Leak-proof construction, acrylic observation panels, and lockable wheels further ensure a secure environment while handling hydraulic equipment.

Q: When is it suitable to use this hydraulic training system?

A: Ideal for training and demonstration purposes, this equipment suits technical institutes, industrial training centers, and on-site skill development workshops. It can be used for regular classes, refresher courses, maintenance training, or practical assessments.

Q: Where can the training unit be installed or used?

A: Thanks to its mobile frame with lockable wheels and moderate dimensions (approx. 1500 800 1800 mm), the training system can be conveniently situated in laboratories, classrooms, or industrial workspaces, allowing flexible adaptation to different settings.

Q: What is the process for assembling and operating basic hydraulic circuits?

A: Users connect componentssuch as the hydraulic pump, control valves, actuators, and gaugesusing standard 1.5-meter hoses and quick coupling connectors. Under supervision, learners can safely operate the system with either gear or vane pumps and monitor system performance via analog/digital gauges.

Q: How is the benefit of modular and transparent design realized in training?

A: The modular design allows quick swapping or reconfiguration of circuit components, which helps demonstrate a variety of hydraulic functions. Transparent acrylic panels let learners directly observe fluid flow and component interactions, aiding visual and practical understanding.
