SINGLE TANK SYSTEM APPARATUS

About SINGLE TANK SYSTEM APPARATUS

Specification:

SINGLE TANK SYSTEM APPARATUS

Description

The setup is for study of behavior ofsingle tank system. It consists of supply tank, pump for water circulation,Rotameter for flow measurement, and one process tanks with scale. Thecomponents are assembled on frame & base plate.

 Experimentation/LearningObjectives:

To obtain the step response of asingle tank liquid level system to a step change in input flow and compare itwith the theoretical response.

To calculate valve resistance.

To determine the time constant of thesystem from the step response curve and compare it with the theoretical value

Utilities Required

Electric supply: Single Phase, 220 V AC, 5-15-amp combined socketwith earth connection. Earth voltage should be less than 5 volts.

Water supply

Floor Drain

Floor area: 1.0 m x 1.0 m
