Pulper

Get a Price/Quote

Pulper Specification

Core Components
Rotor, Sieve, Hopper

Model No
PL100

Power Source
Electric

Voltage
220 V

Automation Grade
Semi-Automatic

Temperature Range
Ambient

Frequency
50 Hz

Accuracy
2%

Measurement Range
Up to 100 kg/hr

Capacity
100 kg/hr

Feature
High efficiency pulping

Equipment Materials
Stainless Steel

Type
Fruit and Vegetable Pulper

Usage
Industrial

Display Type
Analog

Dimension (L*W*H)
1200 mm x 500 mm x 900 mm

Weight
120 kg

About Pulper

Pulper Machine

Edutek are manufacturer and Exporter of Pulper.

Features Of Pulper

Easy Operation
Compact design
Hand operation
Convenient with motor work
High working efficiency

Efficient and High-Capacity Pulping

Engineered for industrial use, the PL100 pulper boasts a 2 HP motor and a robust stainless steel build. Designed to handle high volumes, it delivers up to 100 kg/hr throughput with a remarkable 80-85% pulp extraction rate, supporting consistent output for large-scale applications involving a variety of fruits including tomatoes, mangoes, apples, and guavas.

User-Friendly Operation and Maintenance

The machines semi-automatic function and manual feeding system offer reliable control over operations. Cleaning is straightforward thanks to easy-to-detach parts and a polished mirror finish, ensuring hygiene and reduced downtime between batches. The floor-mounted design provides stability and simplifies installation in various industrial settings.

Precision and Consistency

PL100s analog display and accuracy of 2% guarantee precise monitoring of operating parameters. The sieve mesh size of 1-2 mm delivers uniform pulp texture, while its engineered core componentsrotor, sieve, and hopperensure smooth and efficient pulp extraction with every run.

FAQs of Pulper:

Q: How do I operate and feed raw materials into the PL100 pulper?

A: To operate the PL100, simply load fresh fruits such as tomato, mango, apple, or guava manually into the hopper. The semi-automatic system processes up to 100 kg of raw material per hour, extracting pulp efficiently using its core components: rotor, sieve, and hopper.

Q: What steps are involved in cleaning the pulper after use?

A: The PL100 features easy-clean, detachable parts and a mirror stainless steel finish. After use, detach the necessary components, rinse them with water, and allow them to dry before reassembling. Routine cleaning helps maintain hygiene and optimal performance.

Q: When should the pulper be used for maximum efficiency?

A: For best results, operate the pulper at ambient temperatures not exceeding 45C and ensure a consistent supply of raw fruits. Regular maintenance and periodic cleaning will keep extraction rates high and machine performance consistent.

Q: Where is the pulper ideally installed within an industrial setup?

A: The PL100 is designed for floor-mounted installation and requires a flat, stable surface with access to a standard 220 V electric supply. Ensure enough space for loading, operation, and cleaning, as reflected by its dimensions (1200 mm x 500 mm x 900 mm).

Q: What is the exact pulping process in this machine?

A: The raw fruits are fed into the hopper, where the rotating core and sieve mash and filter out seeds and skins. The extracted pulp passes through a 1-2 mm mesh and is discharged via the 6-inch outlet, ensuring high efficiency and uniform consistency.

Q: How does using the PL100 pulper benefit industrial fruit processing operations?

A: Using the PL100 enhances productivity by ensuring fast, high-yield pulp extraction with minimal noise and downtime. Its stainless steel construction supports food safety standards, while the easy-clean system and robust design reduce labor and maintenance costs.
