Modified Marshal Stability Test Apparatus

Get a Price/Quote

Modified Marshal Stability Test Apparatus Specification

Stroke Length
100 mm

Weight
Approx. 70 kg

Phase
Single Phase

Features
Digital display, Automatic peak load hold, User-friendly operation

Screw Size
25 mm

Power Consumption
300 W

Dimension (L*W*H)
550 mm x 350 mm x 800 mm

Application
Laboratory testing of bituminous mixtures

Frequency
50 Hz

Machine Speed
50.8 mm/min

Accuracy
1% of indicated value

Control System
Digital electronic

Operating Temperature
10C to 40C

Capacity
0-50 kN

Speed Range
50.8 mm/min fixed

Power
230V, 1 Phase AC

Sensor
Load cell type

Voltage
230 V AC

Power Source
Electric

Product Type
Modified Marshal Stability Test Apparatus

Color
Grey/Blue

Load Capacity
50 kN

Resolution
0.01 kN

Automatic Grade
Semi-Automatic

Material
Mild Steel, powder coated

Modified Marshal Stability Test Apparatus Trade Information

Payment Terms
Letter of Credit (L/C), Telegraphic Transfer (T/T), Cash in Advance (CID), Cheque, Cash Advance (CA)

Delivery Time
2 Week

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Eastern Europe, Western Europe, Africa, Middle East, Asia

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Modified Marshal Stability Test Apparatus

Modified Marshal Stability Test Apparatus

The test is intended for the measurement of the resistance to plastic flow of cylindrical specimens of bituminous paving mixture loaded on the lateral surface. For use with hot mixture containing asphalt or tar and aggregate upto 25.4 mm maximum sizes.

The marshal stability test apparatus consists of following:

Marshal Load Frame 100 k N capacity, Electrically Operated, with platen rate travel of 50.8 mm/min. Safety cutoff switch is provided with the machine to avoid from overloading 1 No.
Marshal Compaction Pedestal for compaction of 152.4 mm (6) diameter specimen 1 No.
Breaking head assembly to accommodate specimen of 152.4 mm diameter with dial gauge 0.01 x 25 mm travel 1 Set.
Specimen Extractor (Platen, Steel Ball & Extracting Rod) 1 Set.
Marshal Specimen Mould 101.6 mm dia complete with collar and base plate 3 Nos.
Modified Marshal Compaction Hammer 10.2 kg (22.5 lbs) 149.4 mm dia x 457 mm (18) drop height 2 Nos.
Proving Ring, 25 k N or 30 k N or 50 k N (as per requirement) capacity fitted with dial gauge with set of loading pads and calibration certificate in a nice wooden carrying case.
The Machine is fitted with ½ HP motor. Suitable for Operation on 220 V, Single Phase, 50 Hz, AC Supply.

Precision Testing for Bituminous Mixtures

Engineered for laboratory environments, this apparatus enables reliable and repeatable stability testing of bituminous samples. Its digital display and automatic peak load hold facilitate precise data capture, ensuring compliance with global testing standards. The durable, mild steel construction with epoxy powder coating guarantees long service life.

User-Friendly Design with Enhanced Safety

The apparatus is equipped with an intuitive push-button interface and a protective screen for operator safety. Factory calibration ensures accuracy out-of-the-box, and overload/overtravel safeguards prevent accidental damage. With ambient cooling and operation at less than 60dB noise level, it is ideal for laboratory use.

Seamless Data Capture and Storage

The system offers optional USB data output, enabling efficient recording and transfer of test results. Its semi-automatic controls and digital electronic system simplify operation and boost productivity during materials testing in research, quality control, and industrial labs.

FAQs of Modified Marshal Stability Test Apparatus:

Q: How does the Modified Marshal Stability Test Apparatus ensure precise measurements during testing?

A: The apparatus uses a digital load cell sensor and a digital dial gauge to provide high-accuracy measurements, with a resolution of 0.01 kN and an overall accuracy of 1% of the indicated value, ensuring reliable results for every test.

Q: What type of samples and standards is this apparatus compatible with?

A: It is designed to test bituminous mixtures with a sample diameter of 101.6 mm, and is compliant with ASTM D6927 and IS:1203 standards, making it suitable for standard laboratory applications worldwide.

Q: Where is the ideal operating environment for this equipment?

A: The ideal environment is a dry, dust-free laboratory setting, with ambient humidity up to 90% RH and temperatures between 10C to 40C, ensuring stable performance and longevity.

Q: What is the process for conducting a stability test using this apparatus?

A: Samples are prepared and placed in the split mold fixture. The rigid side plate clamps secure the mold, and the direct vertical movement mechanism applies load. The digital display records and holds peak load, while optional USB output enables data export.

Q: How does the apparatus safeguard against operational errors or damage?

A: Overload and overtravel protections are built-in to prevent excessive force or movement, and a protective screen shields the operator during testing. The device is factory calibrated for immediate safe use.

Q: What benefits does the digital LCD and USB connectivity provide?

A: The digital LCD offers clear, real-time display of readings, minimizing manual errors. USB connectivity (optional) simplifies digital data collection and transfer, improving workflow efficiency and data management.

Q: When should calibration be repeated, and is on-site calibration possible?

A: The device is factory calibrated; however, periodic recalibration may be required according to lab protocols or following heavy use. On-site calibration services are available to maintain measurement accuracy.
