Send InquiryEdutek Digital Tissue Processor
MOQ : 1 Piece
Edutek Digital Tissue Processor Specification
- Usage
- Laboratory Heating and Cooling Instrument
- Classification
- Laboratory Equipment
- Operate Method
- Digital Microprocessor Controlled
- Capacity
- 12 Tissue Stations, 400 ml Each Pcs/hr
- Product Type
- Edutek Digital Tissue Processor
- Color
- White and Blue
- Application
- Laboratory Heating and Cooling Instrument
- Power
- 220 W Watt (w)
- Dimension (L*W*H)
- 610 x 300 x 450 mm Millimeter (mm)
- Weight
- 26 kg (Approx.) Kilograms (kg)
- Voltage
- 220V AC, 50 Hz Volt (v)
- Material
- Mild Steel (Epoxy Powder Coated)
- Paraffin Wax Bath Volume
- 400 ml Each
- Timer
- Programmable Up to 99 Hours
- Display
- Large LCD Display for Programming and Monitoring
- Reagent Jars
- 9 Reagent Jars + 3 Wax Bath Jars
- Safety Features
- Automatic Stop, Audible Alarm, Overheating Protection
- Wax Bath Temperature Control
- Digital Thermostat
- Cover Type
- Transparent Acrylic Cover for Viewing and Safety
- Basket Agitation
- Automatic with Gentle Oscillation
- Battery Backup
- Yes, for Program Memory (Auto Restart on Power Failure)
- Processor Programmability
- Up to 9 Programs, Programmable Time and Temperature
- Heating Range
- Up to 70C
Edutek Digital Tissue Processor Trade Information
- Minimum Order Quantity
- 1 Piece
- Packaging Details
- carton box, export quality also available
- Main Export Market(s)
- Middle East, Africa, Asia
- Main Domestic Market
- All India
- Certifications
- ISO 9001, 14001 ,CE
About Edutek Digital Tissue Processor
Isa compact and versatile equipment for staining process atomization from stageone of fixation of tissue and dehydration process to paraffin wax saturation.Glass door with locking arrangement provides easy viewing and safety fromtempering. Continuous agitation is provided by rotating S.S. Tissue basket tomake process more effective. A superior thermostat maintains desiredtemperature of wax bath.
Accessories:
1- S.S. Basket rotor
Tissuebasket
24- S.S. Tissue capsules
10- 1 litre glass beakers
11- beaker covers
2- S.S. Wax baths each fitted with thermostat, 5-24 hrs.
Calibratedtiming discs
One-notchplier for programming time discs
Itworks suitably on 220V ac 50Hz single phase
Intuitive Programming & Monitoring
Easily program and monitor all procedures with the large LCD display, making workflow management straightforward. Up to 9 custom programs may be set, with programmable time and temperature, providing flexibility for varying laboratory protocols and tissue types. The digital microprocessor-controlled operation ensures high precision and consistent results every time.
Safety and Reliability Built-In
Multiple safety mechanisms, including automatic stop, audible alarms, and overheating protection, help safeguard samples and users. The transparent acrylic cover further enhances operational safety and allows for real-time observation, while battery backup safeguards your work even during unexpected power interruptions.
Efficient Design & Versatile Application
Accommodating 12 tissue stations with 400 ml capacity per station, plus 9 reagent jars and 3 wax bath jars, this processor supports high-volume and diverse tissue processing. Designed for laboratory use, its suitable for histological heating and cooling applications, ensuring uniform results across samples in a compact and durable mild steel frame.
FAQs of Edutek Digital Tissue Processor:
Q: How does the Edutek Digital Tissue Processor ensure reliable processing during power failures?
A: The processor features a battery backup system that retains program memory. In case of a power failure, it automatically restarts the program, minimizing disruption to tissue processing and safeguarding your ongoing work.Q: What safety features are incorporated into this tissue processor?
A: This model includes several safety mechanisms such as automatic stop if an error occurs, audible alarms for issues or process completion, and built-in overheating protection. These features help protect both laboratory personnel and specimens.Q: When should I use the programmable timer on this processor?
A: Utilize the programmable timeradjustable up to 99 hoursto set precise processing durations for different tissue samples or protocols. This helps in customizing cycles according to experimental or diagnostic requirements.Q: Where is the Edutek Digital Tissue Processor primarily used?
A: The processor is chiefly used in laboratories for histological applications that require controlled heating and cooling, such as tissue fixation, dehydration, clearing, and embedding.Q: How does automatic basket agitation benefit tissue processing?
A: The systems automatic gentle oscillation of the tissue basket ensures even reagent exposure to all specimens, which improves uniformity in processing and enhances the overall quality of results.Q: What is the capacity of this processor and its reagent jars?
A: It accommodates up to 12 tissue stations, each with a 400 ml volume, complemented by 9 reagent jars and 3 wax bath jars also holding 400 ml each, supporting bulk and varied sample processing needs.
