DIGITAL PH METER

Get a Price/Quote

MOQ : 1 Piece

DIGITAL PH METER Specification

Input
pH Electrode Input

Features
Automatic Temperature Compensation, Portable Design, Easy Calibration

Response Time
<5 seconds

Resolution
0.01 pH

Usage
ENGINEERING ELECTRONICS EQUIPMENTS

Operating Temperature
0C to 50C

Power Source
AC Mains or Battery

Sensors Specification
Glass Electrode, Reference Electrode Included

Display Type
Digital LCD Display

Output
Digital Display Output

Power Supply
Main Power Supply or Battery Operated

Interface
Electrode Socket, Power Input

Components
Main Unit, Electrode, Connecting Cable, Instruction Manual

Product Type
DIGITAL PH METER

Application
ENGINEERING ELECTRONICS EQUIPMENTS

Rated Voltage
230V AC

Supply Voltage
230V AC

Size
Handheld/Portable

Dimension (L*W*H)
190 mm x 85 mm x 40 mm

Function
Measures the pH value in liquids accurately

Color
Blue and White

Weight
Approx 500 gm

Thickness
Standard

Capacity
0-14 pH

Current Rating
Approx 100 mA

Frequency
50 Hz

Electrode Type
Standard Glass Body

Protection Class
Standard Laboratory Use

Measuring Range
0-14 pH

Calibration
Manual/Automatic Single or Multi-Point Calibration

Accuracy
0.01 pH

Batteries Required
If Battery Operated, uses 9V battery

Display Size
Available in 2-inch LCD

Storage Condition
Store Electrode in pH 4.0 Buffer Solution

Display Resolution
0.01 pH

DIGITAL PH METER Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash on Delivery (COD), Cash Advance (CA), Cheque, Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Letter of Credit (L/C)

Packaging Details
Carton Box, Export Quality also Available

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001, CE

About DIGITAL PH METER

DIGITAL PHMETER

pH metersare stable test instruments used to measure acidity or alkalinity of asolution.

Findingextensive usage in chemical, medical, biology and physics laboratories thesemeters have been provided with advanced features for enhanced performance.

Our pHmeters have digital LED screen which displays the exact pH value of a solutionpromptly.

Model		Deluxe pH Meter	Digital pH Meter	Portable Model
Display		3 1/2-digit LED	3 1/2-digit LED	3 1/2-digit LCD
Range	Ph	0 to 14.00	0 to 14.00	0 to 14.00
Range	mV	0 to + 1999	0 to + 1999	-
Resolution	Ph	0.01	0.01	0.01
Resolution	mV	1	1	-
Accuracy	Ph	0.01	0.01	0.01
Accuracy	mV	1	1	-
Temperature		Auto 0 to 100^o	-	-
Compensation		Manual 0 to 100^o	Manual 0 to 100^o	Manual 0 to 100^o
Slope Correction		80 to 120%	80 to 120%	80 to 120%
Power		230V + 10%	230V + 10%	1 x 9V Battery
Dimensions		76 x 275 x 175	76 x 275 x 175	85 x 28 x 165

Salient features of pH meters:

Ruggedconstruction

Highlystable and accurate

Digitaldisplay

Autotemperature compensation

Autopolarity & decimal indication

Detailedspecifications of our range of digital pH meters are mentioned below:

Incomprehensible:Accuracy pH mV 0.01 1 0.01 1 0.01 -

Accessory combinations:

pH Electrode

BufferTablets 4pH & 7pH

OperationManual

ElectrodeStand

Dust Cover

The range offer by us includes the followingequipment:

PhotoColorimeters

Spectrophotometers

Digital pHMeters

Conductivity/TDS Meters

TurbidityMeters

Digital D.O.Meters

Water &Soil Analysis kits

Cyber ScanpH meter 510

pH range =0-14 number

Temperaturerange = 0-100C

Precision & Reliability

This digital pH meter offers exceptional accuracy with a resolution of 0.01 pH and a highly responsive display, delivering results in less than five seconds. The robust glass electrode and reference electrode guarantee consistent, dependable measurements for engineering electronics projects and laboratory analysis.

Easy Calibration & Versatile Power Options

The device supports both single and multi-point manual or automatic calibration, making it adaptable to varying standards and requirements. Use it wherever needed, powered by AC mains or a 9V battery, ensuring uninterrupted operation in the lab or on the move.

Portable, User-Friendly Design

Engineered in a compact, handheld form factor, this blue and white meter fits comfortably in your hand. Its large 2-inch LCD digital display enhances readability, while intuitive controls and automatic temperature compensation streamline usage for professionals and students alike.

FAQs of DIGITAL PH METER:

Q: How do I calibrate the digital pH meter?

A: Calibration can be done manually or automatically using single or multi-point calibration. Simply follow the instructions in the manual provided, using standard buffer solutions according to the required accuracy.

Q: What is the process for storing the electrode when not in use?

A: To maintain accuracy and extend electrode lifespan, store the electrode in pH 4.0 buffer solution as recommended. Avoid letting the electrode dry out during storage.

Q: Where can this pH meter be used effectively?

A: This digital pH meter is optimized for engineering electronics equipment but is suitable for any laboratory or field application requiring accurate liquid pH measurement, thanks to its portable design and flexible power options.

Q: When should I replace the battery and how is it powered?

A: If battery operated, the meter uses a standard 9V battery. Replace the battery when the display dims or if readings become unstable. Alternatively, connect the unit to 230V AC mains for continuous use.

Q: How does automatic temperature compensation benefit measurements?

A: Automatic temperature compensation ensures accurate, stable results by adjusting for temperature variations in the sample liquid, making your readings more reliable across different conditions.

Q: What components are included with the pH meter?

A: The package contains the main unit, a standard glass-body electrode, reference electrode, connecting cable, instruction manual, and necessary accessories for immediate use.
