Automatic Compression Testing Machine

Get a Price/Quote

MOQ : 1 Piece

Automatic Compression Testing Machine Specification

Warranty
1 year

Temperature Range
Ambient to 50 C Celsius (oC)

Automation Grade
Automatic

Measurement Range
0 2000 kN

Feature
Automatic Load Application, Safety Features, Data Storage

Voltage
230 V AC Volt (v)

Power Source
Electric

Core Components
Hydraulic Pump, Load Cell, Control Panel, Cylinder

Accuracy
1 % %

Capacity
2000 kN Kg

Frequency
50 Hz Hertz (HZ)

Equipment Materials
Heavy-duty Steel Body

Type
Automatic Compression Testing Machine

Usage
Testing Compressive Strength of Concrete Cubes & Cylinders

Display Type
Digital/Touch Screen

Dimension (L*W*H)
900 mm x 700 mm x 1500 mm Millimeter (mm)

Weight
Approx. 500 kg Kilograms (kg)

Loading Rate
1 kN/sec to 20 kN/sec (programmable)

Resolution
0.1 kN

Control System
Microprocessor-based closed loop with touch control

Piston Stroke
100 mm (approx.)

Safety Feature
Emergency stop button, Load limit safety

Frame Type
Welded steel with rigid baseplate

Data Output
USB and RS232 interface for printer and PC connectivity

Power Consumption
1.5 kW

Ambient Humidity
85% RH

Test Standards
IS 516, ASTM C39, BS EN 12390-4

Oil Tank Capacity
30 Liters

Automatic Compression Testing Machine Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit (L/C)

Delivery Time
2 Week

Sample Available
No

Sample Policy
If order is confirmed we will reimburse the sample cost

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India, South India, Central India, North India, East India

Certifications
AS ISO 9001:2008, ISO 14001:2004 and OHSAS 18001:2007 CO.

About Automatic Compression Testing Machine

Automatic Compression Testing Machine

The Automatic Compression Testing Machine is a fully automated version of the manual / semi automatic Compression Testing Machine. The machine is available in 500kN, 1000kN, 2000kN, 3000kN, 5000kN Ranges. It has provision for automatically turning the pump on and off, controlling the set pace rate and switching the machine off under predetermined conditions. The Control release the pressure at the end of every run and reinitializes the machine at the beginning of every test. The pace rate is maintained by means of full three term PID feedback control using high torque stepper motors and drivers sets. Data acquisition, storage, management and analysis are all fully automated. The load resolution is for is 0.1kN for machines upto 1000kN capacity & 1.0kN for the 2000kN, 3000kN & 5000kN Machines.

Specification :

P-IV and above, 1.9Ghz.
256 Mb RAM.
Intel Chipset with on-board graphics card.
40 GB HDD1.
.44MB FDD & CD ROM DRIVE.
Standard Keyboard.
1 Serial Port.
1 Parallel Port.
Printer HP 5550 or latest.
UPS APC 500 VA or equivalent.

Precision Testing for Concrete Strength

Designed to meet international standards, the Automatic Compression Testing Machine delivers reliable evaluation of compressive strength in concrete specimens. The programmable loading rate (120 kN/sec) and high-resolution digital touch screen ensure testing is both user-friendly and highly accurate.

Advanced Data Management and Connectivity

Equipped with USB and RS232 interfaces, the machine simplifies data transfer and reporting. Test results can be seamlessly exported to printers or PCs, facilitating analysis, record-keeping, and compliance documentation with IS 516, ASTM C39, and BS EN 12390-4 testing requirements.

Safety and Durability Engineered for Laboratories

Safety features like the emergency stop button, load limit settings, and robust steel construction provide a secure testing environment. The 30-liter oil tank and heavy-duty frame guarantee reliable performance and longevity, even under continuous laboratory or plant use.

FAQs of Automatic Compression Testing Machine:

Q: How does the programmable loading rate benefit compression testing?

A: The programmable loading rate (1 kN/sec to 20 kN/sec) allows users to set the desired speed for applying load, complying with different international standards and test procedures. This flexibility provides optimal control over the experiment, ensuring comparative and reproducible results.

Q: What types of test samples can this machine handle?

A: This machine is designed to test both concrete cubes and cylinders, evaluating their compressive strength as per IS 516, ASTM C39, and BS EN 12390-4 standards. Its robust structure accommodates various sample sizes typically used in construction quality assurance.

Q: When should the emergency stop or load limit safety feature be used?

A: The emergency stop button and load limit safety should be engaged immediately if any abnormality or unsafe condition arises during testing. These features prevent equipment damage and ensure operator safety in case of unexpected test events.

Q: Where can the data from the test be stored or exported?

A: Test data can be stored digitally and exported via USB or RS232 interfaces. This enables direct connectivity to printers or PCs for detailed analysis, reporting, archiving, or compliance documentation as required by laboratory workflows.

Q: What is the process for conducting a compressive strength test with this machine?

A: To perform a test, place the prepared concrete sample on the rigid baseplate, set the test parameters using the touch control, and initiate the test. The system automatically applies load under controlled conditions, stops upon failure, and records test results digitally.

Q: How does the closed-loop microprocessor-based control system improve accuracy?

A: The microprocessor-based closed-loop system continuously monitors and adjusts the load application in real-time. This ensures stable, precise, and repeatable loading, resulting in reliable test outcomes with high accuracy (1%).

Q: What are the main benefits of using this automatic compression testing machine in labs or industries?

A: Key benefits include automated operation for efficiency, high testing accuracy, safety features that protect users and equipment, comprehensive data management options, and durability for sustained useall supporting rigorous quality control and compliance in concrete testing.
