ZENER VOLTAGE REGULATOR

Name: ZENER VOLTAGE REGULATOR
Brand: EDUTEK INSTRUMENTATION
Price: 1200.0 INR
Availability: InStock

Price 1200.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

ZENER VOLTAGE REGULATOR Specification

Input
Unregulated DC Supply

Usage
ENGINEERING ELECTRONICS INSTRUMENTS

IP Rating
Not rated

Interface
Terminal Block

Output
Regulated DC Voltage

Power Source
External DC Power

Components
Zener Diode, Resistor, Terminal Block, PCB

Power Supply
DC

Operating Temperature
-55C to +150C

Response Time
Instantaneous (as per diode characteristic)

Thermal Conductivity
Standard for PCB materials

Features
Easy installation, Compact Design, Reliable operation

Product Type
ZENER VOLTAGE REGULATOR

Application
ENGINEERING ELECTRONICS INSTRUMENTS

Rated Voltage
5V, 9V, 12V (as per model)

Supply Voltage
Up to 24V DC (depending on model)

Size
Standard PCB size - 3 cm x 2 cm

Dimension (L*W*H)
30mm x 20mm x 10mm

Function
Voltage Regulation using Zener Diode

Color
Black and Silver

Weight
Approx 15g

Thickness
2 mm

Current Rating
20mA - 100mA

Capacity
0.5W to 1W (depends on Zener rating)

Frequency
DC (No Frequency)

Ripple Rejection
High

Polarity Protection
No

Compatible Devices
Breadboards, General PCB Assemblies

Lifespan
10,000+ hours (typical)

Storage Temperature
-65C to +175C

Mounting Type
Through Hole

Compliance
RoHS Compliant

Insulation Resistance
>100 M

Lead-Free
Yes

ZENER VOLTAGE REGULATOR Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash on Delivery (COD), Cash Advance (CA), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Packaging Details
Carton Box, Export Quality also Available

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001, CE

About ZENER VOLTAGE REGULATOR

The ZENER VOLTAGE REGULATOR is an ephemeral yet must-have component engineered for immaculate voltage regulation in engineering electronics instruments. Crafted for through-hole mounting and compliant with RoHS standards, it boasts marvelous reliability with high ripple rejection and over 10,000 hours of lifespan. Its pivotal function is to provide stable DC output at rated voltages-5V, 9V, or 12V-according to the model, accommodating up to 24V input. At a reduced price, this compact, lead-free design excels in breadboards and general PCB assemblies, truly a standout for exporters, manufacturers, and suppliers in India.

Versatile Usage and Competitive Edge

This ZENER VOLTAGE REGULATOR is specifically tailored for engineering electronics instruments, utilized prominently in breadboards and PCB assemblies. Its competitive advantages include instantaneous response, robust insulation resistance, and a high degree of compatibility with various devices. Commonly used as a pivotal voltage regulation solution, it offers marvelous operational reliability and is designed to meet the highest standards in the electronics industry, making it a must-have for professional and educational projects alike.

Sample Policy, Payment Terms, and Delivery Time

Our sample policy allows clients to rate the product's suitability prior to bulk orders, ensuring minimal expenditure and anticipated outlay. Transparent payment terms facilitate easy transactions, accommodating various business needs. The typical delivery time is prompt, ensuring that your project timelines remain uninterrupted. All aspects of procurement are designed to be seamless and efficient, supporting manufacturers, suppliers, and exporters across India with timely fulfillment and support.

FAQ's of ZENER VOLTAGE REGULATOR:

Q: How do I install the ZENER VOLTAGE REGULATOR on my PCB?

A: Installation is straightforward-simply mount the regulator onto the PCB using the through-hole terminals and connect the input and output via the terminal block. Ensure the correct orientation before soldering.

Q: What devices are compatible with this voltage regulator?

A: This regulator is compatible with breadboards, general PCB assemblies, and a wide range of engineering electronics instruments that require regulated DC voltage.

Q: When should I use a ZENER VOLTAGE REGULATOR in my project?

A: You should use this regulator when stable DC voltage is crucial, such as in sensitive electronics where voltage fluctuations could impact performance or component longevity.

Q: Where is this voltage regulator most beneficially applied?

A: It is ideally used in educational labs, prototyping setups, and commercial electronic instruments requiring dependable voltage regulation.

Q: What is the process for obtaining a sample and what are the payment terms?

A: Contact our sales team to request a sample. Payment terms are flexible and can be discussed to suit your procurement process, with pricing adjusted for larger orders.

Q: How does using this regulator benefit my electronic circuits?

A: It ensures an immaculate, stable voltage supply, preventing damage from overvoltage and enhancing the reliability and lifespan of your electronic components.
