Send InquiryTray Dryers
Tray Dryers Specification
- Automation Grade
- Semi-Automatic
- Capacity
- 100 kg/batch
- Warranty
- 1 Year
- Core Components
- Heater Thermostat Motor
- Measurement Range
- Ambient to 150C
- Power Source
- Electric
- Voltage
- 220V
- Frequency
- 50 Hz
- Accuracy
- High
- Temperature Range
- Ambient to 150C
- Feature
- Uniform Drying Energy Efficient
- Model No
- EDUTEK-TD100
- Equipment Materials
- Stainless Steel Mild Steel
- Type
- Industrial Tray Dryer
- Usage
- Food Pharmaceutical Chemical Industries
- Display Type
- Analog
- Dimension (L*W*H)
- 600x700x800 mm
- Weight
- 150 kg
About Tray Dryers
Tray Dryers has a double walled construction. Thermostat control knob and indicator.Gap filled with glass wool for temp. Insulation. Inner and outer walls made out of thick mild steel sheet on stout mild steel angle with motorized air circulation. Power requirement: 220V AC 50Hz. Dial type thermometer has been provided. Temperature range ambient to 50 Degree C - 250 Degree C
Technical Specifications:
Suitable tray size: 32 x 16 x 1 1/4 inch
|
Chamber sizes |
Rating |
No. of trays |
|
33 x 33 x 12 |
3.0 kw |
6 |
|
33 x 33 x 17 |
5.0 kw |
12 |
|
33 x 33 x 34 |
7.5 kw |
24 |
|
68 x 39 x 36 |
12.0 kw |
48 |
|
72 x 77 x 36 |
18.0 kw |
96 |
|
36 x 24 x 22 |
3.0 kw |
2 |
Optional with additional cost
Digital temp. indicator-cum-controller.
Digital temp. indicator-cum-controller with computer data logger
