TOUCH BIO CHEMISTRY ANALYZER

Price 100.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOUCH BIO CHEMISTRY ANALYZER Specification

Classification
Laboratory Analytical Instrument

Power
Power : 50 Watts / 115-230 Volts 10%, 60-50 Hz Volt (v)

Application
Clinical Chemistry Testing

Color
White with Blue Accents

Usage
Wave Length : 340, 405, 510, 546, 578 and 630 mm

Dimension (L*W*H)
465 mm x 345 mm x 320 mm

Voltage
220 V AC, 50 Hz

Material
High-grade ABS Plastic and Metal

Operate Method
Touch-Screen Interface

Weight
11 Kg

Product Type
TOUCH BIO CHEMISTRY ANALYZER

Capacity
120 Sample Positions

TOUCH BIO CHEMISTRY ANALYZER Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C), Cash Advance (CA)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Eastern Europe, Western Europe, Middle East, Asia, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About TOUCH BIO CHEMISTRY ANALYZER

TOUCH BIO CHEMISTRY ANALYZER ETA-33

Human Machine Interface : TOUCH PANEL/KEYPAD
Linear Measurement Range : 0.000 to 3.000 Absorbance Unit (A)
Photometric Accuracy : 2% or 0.007 whichever is higher, from 0 to 1.5A, 3% from 1.5A to 3.0 A.

Filters

Type of Filter : High Quality, Narrow band interface
Wave Length : 340, 405, 510, 546, 578 and 630 mm & two Optional flow cell.
0 Dry Block Incubator : 15 positions at 37 C.
0 0 0 Temp. of Cuvette/Flow Cell Block : 25 C, 30 C and 37 C by Peltier effect.
Light Source : Tungsten Halogen
Display : 5" Graphics LCED, Nagative Blue, STN
Printer : Built in Thermal Printer, 20 Column
Storage Capacity : Open tests with 30 QC results/test & 2500 Patient results.
Analysis Mode : Absorbance End point Fixed Time Kinetic Differential Ratio Coagulation
Power : 50 Watts / 115-230 Volts 10%, 60-50 Hz

Features :

Direct access to Test by Touch of key.
Sophisticate software for kinetic graph with built in delta calculation for saturated (high) samples from graphic display without diluting and rerunning the samples.
Reliable peristaltic pump with maintenance free operations.
Unique circuitry for long lamp life.
Triple cuvette system.
Robust system with built in stabilizer.
Monochromatic, Bichromatic Measurement.
Levy Jennings and standard deviation graphs.
Editing of saved tests.
Patient report with PID & Name.
USB Interface.

User-Friendly Operation

With its 7-inch full color touchscreen display and intuitive touch-screen interface, the analyzer ensures seamless navigation through sample programming, data retrieval, and maintenance. Automation of mixing and error detection assists users in performing routine laboratory tasks efficiently and reduces the potential for operational setbacks.

Advanced Measurement Capability

The system boasts six fixed wavelengths340, 405, 510, 546, 578, and 630 nmenabling a broad spectrum of clinical chemistry assays. Absorbance photometry, combined with an advanced halogen lamp light source, underpins high-precision results for a variety of analytes, maximizing flexibility in clinical diagnostic applications.

Robust Data Management and Connectivity

This analyzer stores up to 10,000 results and integrates with laboratory information systems via USB, RS232, and LAN. Built-in software with quality control and calibration tools enhances laboratory workflow, ensuring data integrity and valid reporting for both small and large-scale operations.

FAQs of TOUCH BIO CHEMISTRY ANALYZER:

Q: How does the TOUCH BIO CHEMISTRY ANALYZER ensure reliable testing in clinical environments?

A: It combines precise absorbance photometry across six fixed wavelengths, automated mixing, built-in quality control software, and error detection systems, ensuring accurate and reproducible results.

Q: What is the process for running a test sample on this analyzer?

A: Samples are loaded into the disposable reaction tray, appropriate reagents are added, and parameters are set through the touchscreen. The automated mixing system prepares samples, and the instrument measures absorbance as per selected wavelength. Results are then displayed, stored, and can be printed via the integrated thermal printer.

Q: When should the analyzers quality control and calibration features be used?

A: Quality control and calibration routines should be performed prior to daily testing sessions, after any major maintenance or software updates, or when results appear inconsistent, to maintain accuracy and compliance with laboratory standards.

Q: Where can the TOUCH BIO CHEMISTRY ANALYZER be installed within a laboratory?

A: It is best placed in a stable, temperature-controlled space (10-35C, 85% humidity), with access to a power source (220V AC, 50Hz), avoiding direct sunlight and areas prone to high dust or moisture.

Q: What are the main benefits of using disposable reaction trays with this analyzer?

A: Disposable trays minimize cross-contamination risks, reduce manual cleaning needs, and help laboratories comply with best practices for hygiene and efficiency.

Q: How can data from the analyzer be exported or integrated with laboratory systems?

A: Lab personnel can connect via USB, RS232, or LAN ports to export data or transmit sample results directly to lab information systems for streamlined reporting and storage.
