Tile Abrasion Testing Machine

Price 5000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Tile Abrasion Testing Machine Specification

Voltage
220 V AC Volt (v)

Accuracy
100 % %

Warranty
1 YEAR

Application
Flooring Industry, Material Testing Laboratories, Concrete/Stone Product Manufacturers

Automation Grade
Manual

Feature
Highly Efficient

Core Components
Turn Table, Motor, Counter, Abrasive Charger

Color
Typically Green Disc, Grey or White Frame

Frequency
50 Hz Hertz (HZ)

Model No

Measurement Range
Up to 50 cycles

Capacity
30 kg Kg

Temperature Range
Ambient Celsius (oC)

Product Type
Flooring/Building Material Testing Equipment

Material
Heavy Steel and Cast Iron

Operate Method
A pre-weighed/measured specimen is clamped onto the rotating disc under a standard load. A fixed quantity of abrasive powder (standard sand) is fed onto the disc. After a set number of revolutions, the specimen is removed and re-measured for loss of volume or thickness

Classification
Civil Engineering / Material Testing

Power Source
Electric

Usage
Quality control for flooring materials to ensure durability and wear resistance against pedestrian or vehicle traffic

Equipment Materials
Mild Steel (MS) Body Construction

Type
Tile Abrasion Testing Machine

Display Type
Analog

Dimension (L*W*H)
500 x 400 x 450 mm Millimeter (mm)

Weight
Approx. 45 kg Kilograms (kg)

Abrasive Load Weight
30 kg

Finish Type
Powder Coated

Standards
IS:1237, IS:15622

Sample Size
7.06 x 7.06 cm

Abrasive Disc Diameter
200 mm

Motor Power
0.25 HP

Sample Holder Material
Brass

Noise Level
Low

Counter
Preset Revolution Counter

About Tile Abrasion Testing Machine

Tile Abrasion Testing Machine

This is used for determination of resistance to wear for Cement & Concrete flooring tiles. Tiles specimen of size 7.06 cm x 7.06 cm is pressed face-wise under specific load on a grinding path and abrasive powder is evenly spread on the rotating grinding disc the second parallel side of the tile is subjected to wear for similar number of rotations. The wear of the tile is measured on a thickness gauge specifically made for the purpose. The machine consists of a disc rotating at a speed of 30 R.P.M. in a circular tray. A bracket is provided to hold the specimen. A counter balance lever loads the specimen. Load applied is 30 kgf funnel is fitted to evenly spread abrasive powder on the grinding path. A Preset Counter automatically stops the machine after 22 revolutions.This counter is Re-adjustable. The machine works on 440 V A.C. Three Phase electrical supply. On Request machine to operate on 230 V A.C. Supply can also be supplied.

Superior Abrasion Testing Performance

Engineered to meet rigorous laboratory standards, the Tile Abrasion Testing Machine provides reliable and accurate performance for assessing tile durability. Its sturdy mild steel construction, low noise operation, and powder-coated finish ensure lasting performance and user comfort.

Advanced Features for Precision

Equipped with a preset revolution counter and analog display, the machine helps laboratory technicians achieve consistent results. The brass sample holder, turntable, and efficient motor work together to deliver repeatable and highly accurate abrasion measurement up to 50 cycles.

Compliant with International Standards

Conforming to IS:1237 and IS:15622 standards, this machine is an indispensable tool for tile manufacturers, exporters, and laboratories. Its precision and reliability make it ideal for both quality assurance and research applications.

FAQs of Tile Abrasion Testing Machine:

Q: How does the Tile Abrasion Testing Machine function for tile wear assessment?

A: The machine operates by placing a tile sample in a brass holder, applying a 30 kg abrasive load using the 200 mm diameter disc, while the turntable rotates the sample. This process simulates surface wear, allowing users to measure abrasion resistance over preset cycles.

Q: What is the measurement range and accuracy of this testing machine?

A: It can measure tile abrasion up to 50 cycles with 100% accuracy, ensuring precise results for laboratory testing and compliance with IS:1237 and IS:15622 standards.

Q: When should laboratories use this machine for tile testing?

A: Laboratories employ this machine when evaluating the durability and wear resistance of tiles, especially for quality control in manufacturing or research environments where standardized abrasion tests are required.

Q: Where is the Tile Abrasion Testing Machine typically installed or used?

A: The machine is designed for use in laboratory settings, manufacturing plants, or research institutes focusing on construction materials, especially tiles.

Q: What benefits does this machine offer over conventional abrasion testers?

A: It provides enhanced efficiency, quieter operation, and greater accuracy thanks to its powder-coated finish, robust MS body, brass sample holder, and reliable analog display. Its compliance with recognized standards further ensures trustworthiness.

Q: How do you operate and process a test using this machine?

A: Begin by securing a 7.06 x 7.06 cm tile in the sample holder, setting the required cycles on the preset counter. Start the machine, allowing the motor to rotate the sample under abrasive load. Results are observed on the analog display once the test is complete.

Q: What are the main usage and benefit for exporters, manufacturers, and suppliers?

A: By utilizing this machine, exporters, manufacturers, and suppliers can certify tile products per global standards, enhance their quality control processes, and offer proof of durability to clients and regulatory bodies.
