Send InquirySwenson Walker Crystallizer
MOQ : 1 Piece
Swenson Walker Crystallizer Specification
- Voltage
- 220V/380V/415V customizable Volt (v)
- Frequency
- 50 Hz / 60 Hz Hertz (HZ)
- Core Components
- Rotor, Trough, End Seals, Motor, Drive System
- Measurement Range
- Crystal size 0.1 mm to several mm
- Accuracy
- High crystal size control and purity %
- Capacity
- Custom as per requirement (commonly 1-50 TPD or more) Pcs/hr
- Feature
- Efficient heat transfer, low maintenance, robust construction
- Temperature Range
- Ambient to 95 C Celsius (oC)
- Power Source
- Electric
- Automation Grade
- Semi-Automatic / Automatic
- Equipment Materials
- Stainless Steel / Carbon Steel / Special Alloys
- Type
- Continuous Crystallizer
- Usage
- Industrial crystallization for chemicals, salts, and pharmaceuticals
- Display Type
- Analog, Visual Inspection
- Dimension (L*W*H)
- Customized to application Millimeter (mm)
- Weight
- Variable as per design Liter (Ltr)
- Seal Type
- Packed gland or mechanical seal at ends
- Fluid Handling
- Single or multi-stage capability
- Transportability
- Modular construction available
- Application Examples
- Sodium Sulphate, Potassium Chloride, Ammonium Nitrate, etc.
- Internal Cleaning Provision
- Available for ease of maintenance
- Rotation Speed
- Variable 1-10 RPM
- Crystallizer Shape
- Open Trough
- Length Range
- 2 meters to 20 meters and above
- Product Suitability
- Suitable for cooling and evaporative crystallization
Swenson Walker Crystallizer Trade Information
- Minimum Order Quantity
- 1 Piece
- Payment Terms
- Cash Against Delivery (CAD), Cash on Delivery (COD), Delivery Point (DP), Letter of Credit at Sight (Sight L/C), Letter of Credit (L/C), Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA)
- Delivery Time
- 2 Week
- Sample Available
- No
- Main Export Market(s)
- Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
- Main Domestic Market
- All India
- Certifications
- AS ISO 9001:2008, ISO 14001:2004 and OHSAS 18001:2007 CO.
About Swenson Walker Crystallizer
Swenson Walker Crystallizer:The set-up is designed to demonstrate and stimulate the phenomena of crystallization. Swenson Walker crystallizer is a continuous type crystallizer. This operation involves both heat and mass transfer. Crystallization is the formation of solid particles within a homogeneous phase. Its wide use has a two-fold basis; a crystal formed from an impure solution is itself pure.
The setup consists of a top open jacketed round bottom trough. A ribbon mixer is provided in crystallizer trough, which rotates at low rpm for agitation of saturated solution. The saturated solution is prepared in a tank fitted with heater and a stirrer. This hot saturated solution is fed at one end of the crystallizer and flows slowly towards the other end while being cooled and is allowed to flow back in hot feed tank making the process continuous. The crystals sediments at the bottom of the trough, and can be washed out at the end of process. Arrangement for Cooling water circulation and flow measurement in jacket is made by using storage type water tank, a pump and a rotameter. Necessary instrumentation is done for temp measurement
Experiments
- To study the performance of a Swanson Walker Crystallizer
- To determine the crystal yield and the efficiency of crystallizer
- Superb Painted structure
- Simple to operate & maintain
- Compact & stand alone set up
- Chemicals commercial grade material as per choice
Exceptional Flexibility and Customization
Swenson Walker Crystallizers are highly adaptable, offering a length range from 2 to over 20 meters and customizable dimensions to precisely meet specific application requirements. Whether handling small or large-scale operations, their modular design and adjustable rotation speed ensure optimal process performance for various crystallization needs.
Superior Performance and Maintenance
These crystallizers are built with robust construction and efficient heat transfer capabilities, enabling high purity and precise control over crystal sizing. Internal cleaning provisions and choice of packed gland or mechanical seals simplify maintenance and operation, minimizing downtime in continuous industrial processes.
Proven Reliability Across Industries
Trusted by chemical, pharmaceutical, and salt processing industries, Swenson Walker Crystallizers are suited for a wide range of materials including sodium sulphate, potassium chloride, and ammonium nitrate. Available in both stainless steel and special alloy constructions, their durability makes them an ideal choice for demanding environments.
FAQs of Swenson Walker Crystallizer:
Q: How does the Swenson Walker Crystallizer ensure consistent crystal size and purity?
A: The crystallizer is designed for high precision in temperature and rotational control, coupled with efficient heat transfer mechanisms. This enables accurate control of supersaturation and crystal growth conditions, resulting in consistent crystal size distribution and high purity across batches.Q: What types of applications can the Swenson Walker Crystallizer handle?
A: This equipment is suitable for both cooling and evaporative crystallization processes, making it ideal for chemicals, salts, and pharmaceuticals. Common application examples include sodium sulphate, potassium chloride, ammonium nitrate, and other similar compounds.Q: When is modular construction particularly beneficial for this crystallizer?
A: Modular construction is especially advantageous when the installation site has space limitations or if transportation and assembly need to be streamlined. It allows for easier handling, relocation, and future expansion if capacity or process requirements change.Q: Where can the Swenson Walker Crystallizer be installed?
A: The units customizable design and range of construction materials (stainless steel, carbon steel, or special alloys) make it suitable for many industrial environments, including chemical plants, pharmaceutical facilities, and salt processing factories worldwide.Q: What process monitoring and maintenance features are included?
A: The crystallizer features analog, visual inspection options for straightforward monitoring. Internal cleaning provisions, along with packed gland or mechanical seals, simplify maintenance and ensure continued hygienic operation and reliability.Q: How is the crystallizer powered and what are the available automation options?
A: Powered by an electric motor, the Swenson Walker Crystallizer can be configured for semi-automatic or fully automatic operation, supporting diverse process control needs and integration with industrial automation systems.Q: What are the key benefits of using the Swenson Walker Crystallizer in industrial crystallization?
A: Key advantages include reliable and efficient crystallization, high product purity, low maintenance needs, robust construction, customizable features, and the flexibility to process a variety of materials under ambient to moderately elevated temperatures.
