STEERING AND PINION STEERING MODEL

Get a Price/Quote

MOQ : 1 Piece

STEERING AND PINION STEERING MODEL Specification

Equipment Type
Educational Demonstration Model

Humidity
Room Ambient

Measuring Range
Full range of steering movement

Interface Type
Mechanical Interface

Temperature
Room Temperature

Number of Specimens
1 Assembly per Test

Port Size
Standard Coupling

Mounting Type
Bench/Tabletop

Hardness
Standard Metal/Plastic Parts

Automation Grade
Manual

Features
Transparent Working Model, movable components

Accuracy
Model for visual and functional accuracy

Power Supply
Not Required (Manual)

Max Height
approx. 400 mm

Resolution
Manual (by eye/hand)

Response Time
Instantaneous

Test Range
Full Rack Travel

Application
Demonstrating Steering and Rack Mechanism

Display Type
Analog/Model Representation

Specimen Size
Automotive Steering Assembly

Usage
Laboratory teaching, Mechanical demo

Capacity
Suitable for Passenger Car Models

Machine Weight
12 kg

Test Speed
Manual Operation

Test Width
Custom Steering Rack Width

Test Stroke
150 mm

Control Mode
Manual

Demonstration Capability
Steering Mechanism, Ackermann Principle Visualization

Accessories
Assembly Manual Included

Rack and Pinion Type
Standard Module

Visual Components
Transparent Parts for Internal View

Material
Acrylic, Metal Components

Finish
Powder Coated/Polished

Packaging
Box Packed, Foam Cushioned

Service Life
Designed for Multiple Demonstrations

Educational Level
Engineering Institutes, Technical Schools

Maintenance
Low

STEERING AND PINION STEERING MODEL Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About STEERING AND PINION STEERING MODEL

Explore the top-ranking STEERING AND PINION STEERING MODELan outstanding educational tool designed for Engineering Institutes and Technical Schools. Featuring grandiose visual components with transparent parts for a clear internal view, this manual model allows thorough demonstration of steering mechanisms and the Ackermann principle. Crafted with high-grade acrylic and metal, and finished for long-lasting performance, its foam-cushioned box guarantees secure delivery. Purchase this special demonstration model for precise, hands-on learning experiences in mechanical engineering, offering low maintenance and a comprehensive do-it-yourself assembly manual for seamless setup.

Ideal for Educational Demonstrations

Widely used by engineering faculties and technical trainers, the STEERING AND PINION STEERING MODEL serves as an excellent application method for illustrating the complexities of rack and pinion steering systems. Its transparent, movable components provide clarity during laboratory teaching sessions. Other features include instant visual feedback, standard automotive capacity, and easy tabletop mounting, ensuring learners effectively grasp steering mechanics in real-time environments.

Domestic Market Coverage and Sample Details

This outstanding model enjoys substantial demand in the Indian domestic educational market. Institutions can request samples with a minimal outlay, supporting informed decisions pre-purchase. Samples are swiftly dispatched, enabling users to evaluate quality and demonstration accuracy before committing to a larger order. The special sale price and reliable packaging underscore our commitment as a leading exporter, manufacturer, and supplier, making educational equipment procurement seamless and transparent.

FAQs of STEERING AND PINION STEERING MODEL:

Q: How does the STEERING AND PINION STEERING MODEL assist in visualizing the Ackermann principle?

A: The model features transparent and movable components, allowing users to observe and understand the Ackermann principle in real-time as they manipulate the steering system manually. This facilitates a clear grasp of the mechanisms behavior and geometry.

Q: What is included in the packaging of this demonstration model?

A: Each unit is box packed with foam cushioning for protection and comes with an assembly manual, ensuring both safety during transportation and ease of setup for users.

Q: Can this model be used for passenger car steering assemblies?

A: Yes, the model has the capacity to accommodate standard automotive steering assemblies, making it suitable for passenger car steering demonstration and teaching.

Q: When is maintenance required for the model?

A: The STEERING AND PINION STEERING MODEL requires minimal maintenance due to its robust build with powder-coated and polished finishes, and it is designed for multiple demonstration cycles.

Q: Where is the best place to use this model in an educational setting?

A: It is ideal for laboratory teaching, mechanical demonstrations, and classroom sessions, and can be conveniently mounted on benches or tabletops in engineering institutes and technical schools.

Q: What are the benefits of manual operation in this model?

A: Manual operation gives users hands-on experience, enabling them to directly engage with the steering mechanism, adjust test widths, observe instantaneous response, and learn mechanical processes effectively without reliance on external power sources.
