Spectrophotometer Uv/Vis

Name: Spectrophotometer Uv/Vis
Brand: EDUTEK INSTRUMENTATION
Price: 3500.0 INR
Availability: InStock

Price 3500.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Spectrophotometer Uv/Vis Specification

Power Supply
AC 220 V 10%, 50 Hz

Control Type
Digital control

Glass Type
Optical glass cuvette (quartz cuvette supported)

Temperature Resistance
Ambient to 40C

Shape
Rectangular

Accuracy
0.5% T

Features
Wavelength auto-setting, automatic calibration, wide wavelength range, high resolution, microprocessor controlled

Display Type
LCD digital display

Type
Spectrophotometer UV/Vis

Dimension (L*W*H)
415 x 280 x 160 mm

Equipment Type
Analytical Instrument

Equipment Materials
Metal and high-grade plastic

Power
40 W

Voltage
220 V AC

Material
Stainless steel and ABS plastic

Application
Quantitative and qualitative analysis in laboratories

Photometric Range
-0.3-3.0 A

Spectral Bandwidth
2 nm

Wavelength Accuracy
0.3 nm

Wavelength Range
200-1000 nm

Net Weight
8.5 kg

Operating Humidity
80% RH (non-condensing)

Detector
Silicon photodiode

Interface
USB/RS232

Light Source
Tungsten halogen and deuterium lamp

Sample Holder
4-position cell holder

Wavelength Repeatability
0.2 nm

Spectrophotometer Uv/Vis Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Letter of Credit (L/C), Cash Advance (CA), Telegraphic Transfer (T/T), Cash in Advance (CID), Cheque

Supply Ability
Piece

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Spectrophotometer Uv/Vis

SPECTROPHOTOMETER UV/VIS (DOUBLE BEAM)

DOUBLE BEAM UV-VIS Spectrometer with more accuracy and flexible requirement. The two detectors are used to measure sample and reference respectively and simultaneously for satisfying of requirement of various fields, Such as biochemical research and industry, Pharmaceuticals analysis and productions, Environments productions, food industry Etc.

Wavelength range 190 to 1100 nm
Spectral bandwidth 1 nm (190 to 1,100 nm)
Wavelength display 0.1nm increments
Wavelength setting 0.1nm increments
Dimension (L*W*H) 625*430*206nm
Net Weight 26 Kg

SPECTROPHOTOMETER (ET-2800D)

Computer Controlled Operation,
Display Mode: 4 digit LED

Lamp:

Hamamatsu L2D2 long life (over 3000 hours)
Deuterium Lamp and RoYal long life (over 10000 hours)
Halogen-Tungsten Lamp with patent technical combination
Interface: RS232 Serial
Measurement: 15 - 12 9 Inches
Weight: 22lb
Wavelength Range 200~1000nm
Wavelength Accuracy 2nm
Wavelength Repeatability 0.5nm
Photometric Range 0.0~199.9%T, 0.3~2.999A, 1~9999F, 0~999C
Spectral Slit Width 2nm
Transmittance Accuracy 0.5%T(NBS930D)
Stray Light < 0.3%T(220nmNal)

Advanced Wavelength Control

This UV/Vis spectrophotometer features auto-setting and automatic calibration, allowing users to effortlessly select wavelengths within the 2001000 nm range. High accuracy and repeatability are ensured by microprocessor control, making it ideal for consistent laboratory results across a spectrum of analyses.

Durable Design and Versatile Application

Manufactured from metal and high-grade plastic, this instrument is built for longevity and reliability. Its broad applicability spans both quantitative and qualitative laboratory analyses, including chemical, pharmaceutical, and environmental testing operations. The rectangular shape design maximizes bench space and accommodates up to four cells for simultaneous measurements.

Digital Precision and User-Friendly Interface

Featuring a digital LCD display and intuitive controls, the spectrophotometer offers clear readouts and simplified operation. Interfaces for USB and RS232 connectivity enable seamless integration with laboratory networks, while the sample holder supports optical and quartz cuvettes for enhanced flexibility.

FAQs of Spectrophotometer Uv/Vis:

Q: How does the spectrophotometer auto-set the wavelength during analysis?

A: The spectrophotometer utilizes a microprocessor-controlled system to automatically set and calibrate the wavelength within the 2001000 nm range. This ensures precise positioning for your selected measurements and reduces manual errors.

Q: What types of samples can be measured using the four-position cell holder?

A: The spectrophotometer accommodates optical glass and quartz cuvettes in its sample holder, allowing simultaneous analysis of multiple liquid samples, including biological, chemical, and environmental specimens.

Q: When is it recommended to use the deuterium lamp versus the tungsten halogen lamp?

A: The deuterium lamp is optimal for measurements in the ultraviolet range (200350 nm), while the tungsten halogen lamp provides reliable performance in the visible spectrum (3501000 nm), ensuring accurate results across diverse wavelength requirements.

Q: Where can this spectrophotometer be installed for best results?

A: It should be placed in laboratory environments with operating temperatures up to 40C and relative humidity not exceeding 80%. The robust design and moderate size (415 x 280 x 160 mm) make it suitable for bench-top use in research or industrial labs.

Q: What is the process for performing calibration on this instrument?

A: Calibration is performed automatically by the spectrophotometers built-in software. Users simply initiate the process via the digital interface, and the device uses reference standards to ensure accurate wavelength and photometric alignment.

Q: How does digital control improve measurement accuracy and user experience?

A: Digital control allows precise setting of operational parameters and minimizes human error, enhancing accuracy ( 0.5% T) and repeatability ( 0.2 nm). The LCD display provides clear feedback, making navigation and data interpretation straightforward.

Q: What are the benefits of using a UV/Vis spectrophotometer for laboratory analysis?

A: This spectrophotometer offers high resolution, automatic calibration, versatility in sample handling, and rapid data acquisition. These features yield reliable, reproducible results, improving efficiency and supporting comprehensive research workflows.
