Send InquirySINGLE EFFECT EVAPORATOR APPARATUS
Price 500.0 INR/ Piece
MOQ : 1 Piece
SINGLE EFFECT EVAPORATOR APPARATUS Specification
- Capacity
- 25 Ltrs. Ltr
- Usage
- Heat Transfer Laboratory Equipment
- Warranty
- 1 Year
- Application
- Heat Transfer Laboratory Equipment
- Power Source
- Electricity Supply: 1 Phase, 220 V AC, 50 Hz, 32 amp
- Product Type
- SINGLE EFFECT EVAPORATOR APPARATUS
- Type
- SINGLE EFFECT EVAPORATOR APPARATUS
SINGLE EFFECT EVAPORATOR APPARATUS Trade Information
- Minimum Order Quantity
- 1 Piece
- Payment Terms
- Cash on Delivery (COD), Cash Advance (CA), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)
- Packaging Details
- Carton Box, Export Quality also Available
- Main Export Market(s)
- Asia, Middle East, Africa
- Main Domestic Market
- All India
- Certifications
- ISO 9001, 14001, CE
About SINGLE EFFECT EVAPORATOR APPARATUS
Specification:
SINGLE EFFECT EVAPORATOR APPARATUS
Material: Stainless Steel
Shell Dia: 70 mm, Length-500 mm
Tube ID: 9.5 mm, OD 12.7mm
Length: 500 mm
Feed Circulation: By Gravity feed
Feed Tank: Material stainless steel
Capacity: 25 Ltrs.
Flow Measurement: Rotameters (One each for feed & coldwater).
Steam Generator: Made of stainless steel provided with PressureGauge & Level Indicator, Safety valve and drain etc.
Piping: Stainless Steel and PVC, size 1/4"
Condenser: Shell & Tube typemade of Stainless Steel.
Bottom Product Tank: Made of Stainless Steel, capacity 10Ltrs.
Water Supply Tank: Made of Stainless Steel, capacity 50Ltrs. (For condenser)
Pump: FHP capacity
Heaters: Nichrome wire heater.
Control panel comprises of Digital Temp Controller: PID Controller, 0-199.9 deg C (ForSteam Generator)
Digital Temp Indicator: 0-199.9 deg C, with multi-channelswitch.
Temp Sensors: RTD PT-100, Standard make On/Off switch, MainsIndicator etc.
Electricity Supply: 1 Phase, 220 V AC, 50 Hz, 32 amp
Floor Area: 1.5 m x 1.0 m
