Shaking Machines Rotary

About Shaking Machines Rotary

Shaking Machines Rotary ETL-111B

Shaking Machine Rotary (horizontal) :

Continuous shaking of flasks from 100 to 500 ml capacity. Bench type table top model with platform with rubber discs/steel clamps mounted on ball-bearing crank-shafts to give an orbital motion to flasks within a diameter of2". Motor is coupled with v-belt with a pitch pulley and mounted on heavy angle iron frame. Machine supplied with fixed or variable speed controlled by mechanical speed controller. To work on 220VAC 50Hz single phase.

Specifications:

Platform sizes	Holding Capacity	H.P. Motor
45 x 45 cms	25 flasks of 100 ml	0.25
45 x 45 cms	36 flasks of 50 ml	0.25
45 x 45 cms	16 flasks of 250 ml	0.25
55 x 55 cms	25 flasks of 250 ml	0.25
65 x 65 cms	36 flasks of 250 ml	0.5
100 x 100 cms	81 flasks of 250 ml	1
100 x 100 cms	81 flasks of 500 ml	1

 Note : Other sizes and capacities can be fabricated on demand



Effortless Laboratory Mixing

This table-top rotary shaking machine streamlines sample mixing for laboratories handling biological and chemical analyses. Equipped with a universal platform and adjustable flask holders, it caters to various vessel sizes, optimizing experiment flexibility and reliability. The heavy-duty induction motor and belt-driven system ensure consistent, low-noise operation, even under maximum loads.


User-Friendly Controls and Safety

Take command of your shaking protocols with a variable speed regulator and an analog display for precise adjustments between 40180 rpm. The mechanical timer ranges up to 120 minutes or continuous operation. Built-in overload and fuse protection safeguards both the user and equipment, while the robust epoxy-coated finish enhances longevity in demanding lab environments.
