Send InquirySeries Rolling Thin Film Oven
Series Rolling Thin Film Oven Specification
- Temperature Range
- Up to 200C
- Automation Grade
- Semi-Automatic
- Measurement Range
- Standard as per ASTM D2872
- Capacity
- 10-15 liters
- Core Components
- Motor, Oven Chamber, Timer, Rotating Assembly
- Voltage
- 220-240 V AC
- Model No
- RTFO-200
- Accuracy
- 1C
- Power Source
- Electric
- Frequency
- 50 Hz
- Feature
- Uniform Heating, Precise Temperature Control, Safety Features
- Equipment Materials
- Mild Steel Powder Coated
- Type
- Rolling Thin Film Oven
- Usage
- Bitumen Testing / Laboratory Testing
- Display Type
- Analog/Digital
- Dimension (L*W*H)
- 650 x 700 x 1150 mm
- Weight
- Approx. 60-75 kg
Series Rolling Thin Film Oven Trade Information
- FOB Port
- Delhi
- Payment Terms
- Letter of Credit (L/C), Telegraphic Transfer (T/T), Cheque
- Supply Ability
- Sample Available
- No
- Main Export Market(s)
- Australia, North America, Eastern Europe, Middle East, Africa, Central America, South America, Western Europe, Asia
- Main Domestic Market
- All India
- Certifications
- AS ISO 9001:2008, ISO 14001:2004 and OHSAS 18001:2007 CO.
About Series Rolling Thin Film Oven
Series Rolling Thin Film Oven
We are manufacturer and exporter of series and rolling thin film oven.
Specification of Series Rolling Thin Film Oven:
- The rolling thin film oven is used to measure the effect of heat and air on a moving film of semi-solid asphaltic material.
- Series rolling thin film Oven (220-240 V AC , 50 Hz, 1 Ph.
Uniform and Reliable Heating Performance
Harnessing a forced air circulation heating method with a premium Nichrome element, this oven guarantees consistent and accurate temperature control up to 200C. The precise 1C accuracy ensures optimal conditions for bitumen sample testing, reducing the risk of uneven results. Its robust chamber design and adjustable racks further optimize sample placement and heating uniformity for every analysis.
Designed with Laboratory Safety in Mind
Key safety features, such as over-temperature protection, door interlock mechanism, and a double-layer toughened glass observation window, allow for safe operation even during extended testing periods. These safeguards, coupled with an epoxy powder coated exterior and user-friendly digital timer, create a reliable and secure testing environment for laboratory professionals.
Convenience and Versatility for Bitumen Testing
With a capacity of 1015 liters and adjustable shelves, the oven accommodates various sample sizes and configurations. The digital timer and clear analog/digital display streamline test set-up, while accessories like sample holders, a power cable, and a user manual support ease of use right out of the box. This makes the RTFO-200 a comprehensive solution for bitumen testing laboratories.
FAQs of Series Rolling Thin Film Oven:
Q: How does the Series Rolling Thin Film Oven ensure uniform heating for bitumen samples?
A: The oven utilizes a high-quality Nichrome heating element combined with forced air circulation, which distributes heat evenly throughout the stainless steel chamber. This design achieves uniform temperature, resulting in reliable test outcomes for each sample.Q: What safety features are integrated into this oven model?
A: Safety is enhanced with over-temperature protection to prevent overheating, a door interlock system that controls chamber access during operation, and a double-layer toughened glass observation window, allowing safe viewing of samples without exposing users to high temperatures.Q: When should I use this oven, and for what testing applications?
A: The Series Rolling Thin Film Oven is intended for laboratory testing of bitumen, specifically for assessing changes in its properties as prescribed by ASTM D2872. It should be used whenever accurate and standardized bitumen aging simulation is required.Q: Where can this oven be installed for optimal operation?
A: Install the oven in a laboratory or testing facility within a well-ventilated space that maintains an ambient temperature between +5C and +40C, ensuring stable operation and safety.Q: What is the process for testing bitumen with the RTFO-200?
A: Samples are placed in designated holders on removable racks inside the stainless steel chamber. After setting the digital timer (up to 999 minutes) and temperature (up to 200C), the ovens rotating assembly moves the samples at 15 RPM, simulating the effects specified in ASTM D2872. Results are then collected after the test cycle completes.Q: How do the removable shelves benefit laboratory users?
A: Removable and adjustable racks provide flexibility to accommodate a variety of sample sizes and configurations, allowing users to optimize the space according to test requirements, thus enhancing efficiency.Q: What accessories are provided with the oven, and how do they enhance usability?
A: Each unit comes with sample holders, a power cable, and a user manual, facilitating immediate operation upon delivery. The included accessories help streamline setup and ensure consistent, accurate testing procedures.
