RHEOMETER DIGITAL

Get a Price/Quote

MOQ : 1 Piece

RHEOMETER DIGITAL Specification

Power
50 W

Voltage
220 V AC, 50 Hz

Material
Powder Coated Metal & ABS body

Classification
Laboratory Instrumentation

Dimension (L*W*H)
Approx. 450 x 220 x 280 mm

Product Type
Digital Rheometer

Operate Method
Digital Control Interface

Application
Research, Quality Control, Industrial Laboratories

Capacity
Up to 500,000 mPas

Weight
16 Kg (Approx)

Color
White and Blue

Usage
Measurement of viscosity and flow properties

Safety Features
Overload protection, Error alerts

Sample Volume
Minimum 10 ml

Torque Range
0.1 to 13 mNm

Display Type
Digital LCD

Operating Temperature
Up to 50C

Number of Spindles
4 Standard (More optional)

Data Output
USB/RS232 Port (if fitted)

Accuracy
1% of Full Scale

Speed Range
0.1 to 60 rpm

Calibration
Auto or Manual Calibration

RHEOMETER DIGITAL Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About RHEOMETER DIGITAL

RHEOMETER DIGITAL ETP-202A:

Feature :

Sophisticated Rheometer with continuous sensing and display.
Stand-alone programming: Enter data, temperature requirements, start program, see results on built-in display.
Computer programmable using optional Rheocalc 32 software lets you control all aspects of rheological testing directly from the computer.
The tool to easily predict a materials flow, spray opumping behaviour by studying shear rate profiles.
Has built-in math models for data analysis in stand-alone mode, eg. Casson.
Complete with appropriate spindles, Rheoloader program, power base, guard leg and carrying case.
Accuracy: 1.0% of range Repeatability: 0.2%

Advanced Digital Viscosity Measurement

Featuring 4 standard spindles and optional additional attachments, the RHEOMETER DIGITAL is engineered for comprehensive viscosity analysis. The digital LCD interface gives clear, real-time readings, while USB/RS232 data output (if fitted) streamlines data logging and transfer for your laboratory workflows.

Robust Construction and User-Friendly Control

Constructed from powder coated metal and ABS, this instrument combines durability with ergonomic operation. The digital control panel simplifies adjustments, and the instrument weighs approximately 16 kg, making it both sturdy and manageable for laboratory use.

Enhanced Safety and Calibration

Operational confidence is ensured through features like overload protection, error alarms, and selectable auto or manual calibration. These elements help maintain precise, reliable performance while minimizing operational risk in any laboratory environment.

FAQs of RHEOMETER DIGITAL:

Q: How do I set up and operate the RHEOMETER DIGITAL in a laboratory environment?

A: Setting up the RHEOMETER DIGITAL is straightforward: connect it to a 220 V AC power source and evenly place it on a stable surface. Use the digital control interface to select your spindle (4 standard included), set the desired speed (0.1 to 60 rpm), and begin measurements. Follow the display instructions for calibration and ensure sample volumes of at least 10 ml.

Q: What applications is this rheometer best suited for?

A: This rheometer is designed for precise viscosity and flow property measurements in research, quality control, and industrial laboratories. Its wide capacity range (up to 500,000 mPas) makes it ideal for sectors such as chemicals, pharmaceuticals, food processing, and materials science.

Q: When should I perform calibration and how is it done?

A: Calibration should be conducted upon installation, after maintenance, or when accuracy verification is required. The rheometer offers both automatic and manual calibration via the digital control interface, with prompts guiding you through the process to ensure precision.

Q: Where can I view and manage the measurement data collected by the instrument?

A: Measurement data can be monitored in real-time on the digital LCD display. For further analysis, data output is available via USB or RS232 ports (if fitted), allowing easy transfer to computers and laboratory data systems.

Q: What safety measures are integrated into the operation of this rheometer?

A: Safety is emphasized through overload protection that prevents mechanical stress, error alerts for operational anomalies, and sturdy construction materials. These features help protect both the operator and the instrument during routine use.

Q: How does the design benefit overall laboratory efficiency?

A: Its compact dimensions (approx. 450 x 220 x 280 mm) and digital automation streamline sample handling and measurement processes, minimizing manual errors and enhancing throughput. Automatic calibration and error notifications further contribute to a smooth workflow.
