REYNOLDSS APPARATUS

Price 500.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

REYNOLDSS APPARATUS Specification

Measurement Range
0.0001 to 0.01 m /s

Frequency
50 Hz Hertz (HZ)

Power Source
220V AC Supply

Temperature Range
Ambient to 80 C Celsius (oC)

Usage
Fluid Mechanics Lab Equipment

Automation Grade
Manual

Product Type
REYNOLDS S APPARATUS

Feature
Demonstrates Laminar, Transitional, and Turbulent Flow

Capacity
30 liters Ltr

Accuracy
2% %

Model No

Core Components
Glass Tube, Constant Head Tank, Dye Injector, Measuring Cylinder, Flow Control Valve

Application
Fluid Mechanics Lab Equipment

Voltage
220V Volt (v)

Equipment Materials
Stainless Steel Tank, Glass Tube, Mild Steel Frame

Type
Laboratory Apparatus

Display Type
Visual Observation

Dimension (L*W*H)
Approx. 1000 x 350 x 1100 mm Millimeter (mm)

Weight
33 kg Kilograms (kg)

Glass Tube Diameter
10 mm

Accessories Provided
Measuring Cylinder, Dye Injector Syringe, Instruction Manual

Pump Type
Centrifugal Pump

Dye Reservoir Capacity
100 ml

Mounting
Floor Standing

Paint Finish
Corrosion Resistant Epoxy

Observation Method
Direct Visual Via Glass Tube

Safety Features
Overload Protection for Pump

Power Consumption
20 W

Test Tube Length
1 meter

Dye Used
Potassium Permanganate or Suitable Colored Dye

Flow Regulation
Manual Needle Valve

Calibration
Factory Calibrated

Tank Material
304 Grade Stainless Steel

REYNOLDSS APPARATUS Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash on Delivery (COD), Cash Advance (CA), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Packaging Details
Carton Box, Export Quality also Available

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001, CE

About REYNOLDSS APPARATUS

Specification:

REYNOLDSSAPPARATUS

It is manufactured at our unit byusing highest quality materials under the guidance of the experts. This isextensively used to illustrate laminar, transitional and fully turbulent pipeflows. It also determines the conditions under which the flow occurs. ReynoldsApparatus can be availed by our customers at an economical price.

Features:

Accurate result

Enhanced functional life

Easy to use

Product Specification

Frequency: 50 Hz

Voltage: 220 Volt

Phase: Single Phase

Current: 5-15 amp

Durable Construction and Design

Built using 304 Grade Stainless Steel for the tank and a strong mild steel frame, the apparatus promises longevity and reliability in laboratory environments. The glass observation tube enables direct, clear visualization of fluid flows, making it invaluable for repetitive experimental usage.

Precise and Versatile Measurement

The manual needle valve allows fine flow adjustments, while the system can handle tests from 0.0001 to 0.01 m/s. Factory calibration delivers results with 2% accuracy, and the setup supports experiments with temperatures ranging from ambient up to 80C for comprehensive study.

Comprehensive Fluid Mechanics Demonstration

This apparatus is specifically tailored for fluid mechanics laboratories, enabling users to study laminar, transitional, and turbulent flow behaviors. The provided dye injector and measuring cylinder help facilitate accurate and visual demonstration of fluid dynamics principles.

FAQs of REYNOLDSS APPARATUS:

Q: How is the REYNOLDSS APPARATUS used to demonstrate different flow regimes?

A: The apparatus utilizes a one-meter glass tube and a dye injection system to visually observe the transition between laminar, transitional, and turbulent flows. By adjusting the manual flow control needle valve, users can control water velocity and inject dye to observe how it moves, revealing the flow pattern directly.

Q: What materials are used in the construction of the REYNOLDSS APPARATUS?

A: The tank is made from 304 Grade Stainless Steel, the main frame from mild steel, and the observation tube from high-quality glass. This combination ensures corrosion resistance, durability, and clear visibility for direct observation.

Q: When should calibration of the apparatus be checked or re-done?

A: The REYNOLDSS APPARATUS is supplied factory calibrated for immediate use. For continual accuracy, periodic checks can be performed according to your laboratory quality protocols, but recalibration is usually unnecessary unless the equipment suffers impact or irregularities.

Q: Where should the REYNOLDSS APPARATUS be installed for optimal performance?

A: This laboratory apparatus is designed for floor standing installation in a controlled indoor environment, ideally within a fluid mechanics or engineering laboratory with access to a standard 220V AC power supply.

Q: What is the process for conducting an experiment using this apparatus?

A: Fill the 30-liter tank, set the desired flow rate with the manual valve, and inject a stream of dye using the syringe into the glass tube. The dye pattern indicates the type of flow present. Use the measuring cylinder to collect data, following guidelines from the instruction manual.

Q: What are the main benefits of using the REYNOLDSS APPARATUS?

A: This equipment allows students and researchers to easily visualize and understand fundamental principles of fluid dynamics, including the differences between laminar and turbulent flows. The direct visual observation, reliability, and robust safety features make it ideal for educational settings.

Q: How is safety maintained during operation?

A: Safety is ensured with an overload protection system for the centrifugal pump and a robust design featuring corrosion-resistant epoxy paint, minimizing risks while maintaining long-term performance in the laboratory environment.
