RADIAL ARM CROSSCUT SAW

Get a Price/Quote

MOQ : 1 Piece

RADIAL ARM CROSSCUT SAW Specification

Automation Grade
Manual

Mounting Type
Floor Standing

Operating Voltage
415V

Interface Type
Manual operating controls

Accuracy
±0.5 mm

Power Supply
415V, 3 Phase, 50 Hz

Application
Wood Cutting / Crosscutting

Equipment Type
Radial Arm Crosscut Saw

Max Height
Cutting Height up to 90 mm

Measuring Range
Up to 600 mm stroke

Frequency
50 Hz

Specimen Size
Up to 90x250 mm

Features
Heavy-duty structure, adjustable arm, tilting head, manual feed

Usage
Industrial, woodworking

Capacity
3 HP motor

Machine Weight
Approx. 220 kg

Test Width
600 mm / 750 mm (optional)

Test Stroke
600 mm

Control Mode
Manual

Color
Industrial Green

Operation Mode
Manual cutting

Table Size
1200 mm x 800 mm

Assembly
Pre-assembled main frame

Blade Diameter
350 mm

Material of Construction
Mild steel body with cast iron arm

Cutting Angle
0 to 45

Dust Extraction Port
Included

Lubrication Type
Grease lubricated bearings

Suitable Materials
Hardwood, plywood, MDF

Safety Features
Blade guard, Emergency stop switch

Noise Level
Less than 80 dB

RADIAL ARM CROSSCUT SAW Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About RADIAL ARM CROSSCUT SAW

RADIAL ARM CROSSCUT SAW

Voltage : 220V
Phase : single
Wavelength : 700mm
Tungstencarbide tipped saw blade
Wavelength : 700mm
Sawblade size : 250-300mm
Rotationalspeed : 2800rpm(max cutting)
Width : 510mm (max cutting)
Height : 210mm
Voltage : 220V
Phase : single
Wavelength : 700mm
Tungstencarbide tipped saw blade
Wavelength : 700mm
Sawblade size : 250-300mm
Rotationalspeed : 2800rpm(max cutting)
Width : 510mm (max cutting)
Height : 210mm

Heavy-Duty Construction & Performance

Designed for industrial woodworking tasks, the saw incorporates a mild steel body and a cast iron arm to deliver both stability and longevity. The robust 3 HP motor offers reliable cutting power, while the blade diameter of 350 mm accommodates deep, accurate cuts up to 90 mm in height and 250 mm in width.

Precision and Adjustable Operation

The adjustable arm and tilting head provide flexibility, allowing cutting angles between 0 and 45 for various project needs. With an accuracy of 0.5 mm and a stroke of up to 600 mm, every cut meets rigorous standards required by professionals in the woodworking industry.

Safety and User-Friendly Features

Operator safety is ensured with essential features, including a blade guard and an emergency stop switch. The main frame comes pre-assembled and equipped with grease-lubricated bearings, facilitating easy setup and smoother operation, while the integrated dust extraction port helps maintain a cleaner work environment.

FAQs of RADIAL ARM CROSSCUT SAW:

Q: How do I operate the RADIAL ARM CROSSCUT SAW safely?

A: To ensure safe operation, always make use of the blade guard and familiarize yourself with the emergency stop switch before cutting. Double-check that the workpiece is securely positioned, set your cutting angle (0 to 45), and operate the saw using the manual controls provided.

Q: What materials can be cut with this crosscut saw?

A: This machine is suitable for hardwood, plywood, and MDF. The sturdy construction and powerful 3 HP motor allow it to efficiently crosscut a variety of wood materials up to a height of 90 mm and width of 250 mm.

Q: When is it necessary to lubricate the bearings?

A: The bearing housings are grease-lubricated for minimal maintenance. Check lubrication levels periodically as per your operational schedule, or if you notice any increase in operational noise or resistance during arm movement.

Q: Where should the saw be installed for optimal performance?

A: This floor-standing saw should be installed on a flat, solid surface in a well-ventilated industrial workshop. Access to a 415V, 3 Phase, 50 Hz power supply is required. Ensure sufficient space around the 1200 mm x 800 mm table for handling longer workpieces.

Q: What is the assembly process for this crosscut saw?

A: The main frame of the saw is pre-assembled, minimizing setup time. You need only to connect electrical power and affix any additional accessories, such as the dust extraction port, before commencing operation.

Q: How does the dust extraction port benefit woodworking operations?

A: The integrated dust extraction port helps in maintaining a cleaner workspace by efficiently capturing sawdust and debris generated during cutting. This not only improves visibility but also enhances the overall air quality in your workshop.

Q: What are the main benefits of choosing this radial arm crosscut saw?

A: This saw provides precise, consistent crosscuts with minimal noise (<80 dB) and high operational safety. Its heavy-duty construction ensures durability for industrial use, while features like adjustable angles, pre-assembly, and dust extraction contribute to efficiency and user comfort.
